Bircher Reglomat PrimeTec A Translation Of The Original Instructions

EN ISO
9001
Quality
international
PrimeTec A
level
PrimeScan A
Translation of the original instructions
General
PrimeTec A
PrimeScan A
Safety instructions
1
Observe the national and international regulations on door safety.
Only trained, qualified personnel may mount and start up the detector.
The unit may only be opened and repaired by Bircher Reglomat.
The unit may only be operated from a safety extra-low voltage (SELV) system with safe electrical separation.
Always consider the safety functions of your application as a whole, never just in relation to one individual section of the system.
The installer is responsible for carrying out a risk assessment and installing the detector and the door system correctly.
Avoid touching any electronic components.
The door drive and transom profile must be earthed correctly.
Start-up
Recommended start-up sequence: I. Mounting
Mounting
2
1. Remove cover hood
I
2. Set AIR field width (see chapter 2.1)
Setting the AIR field width
2.1
The width of the AIR field can be set using the click-in plastic cover in front of
the detector's lens. (Dimensions at 2.2 m mounting high)
*
Detector without cover:
All light beams are active
Possible field width settings:
A, B, G, H covered
A, D covered
Mounting of the detector
2.2
1. Position drill template
2. Drill the holes, remove drill template
3. Lay cable and mount detector
PrimeScan
PrimeTec
II. Connection
(PrimeTec / PrimeScan)
Field width:
1.
2.3 x 0.2 m
2.
E, G, H covered
A, B, D covered
Combined detector AIR/Radar for opening and
protecting automatically controlled sliding doors
a
Hood Microwave module
LED display optics-cover
AIR light window Detector electronic
Detector without hood Mounting holes
LCD display Cable bushing
III. Initialisation
3. Lay and connect cable
4. Mount detector
A B
1. Slide
2. Push & click!
C, D covered
E, F covered
b
a Button Mode (red)
b Button Data (black)
AIR adjusting device
LED1 AIR: red (left)
LED2 Microw.: green (rig.)
C D
F G
E H
A. B, G, H covered
A, B, G, H covered
*Factory setting
1
