Pool Blaster iVac M3 Installation Manual

Your new kit includes:
Motor Box with ON/OFF Button (P30X003LI)
Charger (LC099-3S-US-EU)
STEP 1: Place the unit on a workbench
with the ON/OFF knob facing up. Note the
screw locations shown above. 4 screws on
the main body and 1 small screw on the
bottom right.
Installation Guide - NiMH to Lithium
®
No cover needed
Need Help? Contact Customer Care at (732) 967-9888
Upgrading the Pool Blaster® iVac M3 Motor Box
Why did my new motor box kit come with a charger?
This complete kit replaces all of the electronics for the Pool
Blaster® iVac M3 and will guarantee that your machine will
be repaired and increase the longevity of your battery.
Your old charger will not work. Please dispose of
your original charger.
You will need the following tools:
Phillips screwdriver or battery
powered screwdriver and a cutting tool
(set drill at
STEP 2: Using cutters, cut the lanyard and
unscrew the ON / OFF Knob. Discard it as it
won't be needed anymore.
low
torque setting)
1
