  • Page 2 All Rights Reserved This document contains information that is proprietary to LUMANTEK.CO., LTD. The information in this document is believed to be accurate and reliable; however, LUMANTEK assumes no responsibility or liability for any errors or inaccuracies that may appear in this document, nor for any infringements of patents or other rights to third parties resulting from its use.

  • Page 3: Table Of Contents

    ・ Avoid wearing loosened clothes or accessories during installation/Operation. ・ Avoid any unnecessary actions that may damage/harm system or personnel. (1) HDMI Multiview Interface ・ Do NOT open the system unless advised by Lumantek representative. Lumantek takes (2) Console Interface no responsibility on units with broken RMA seals.

  • Page 4: Introduction

    1. Introduction INTRODUCTION ez-Liveshow is a brand born through combination of LUMANTEK’s encoding and video switching technology especially designed for small studio size event. VS10 is one of the main product of ez-Liveshow brand. It is a stand-alone video switcher with scaler installed giving the ability to set the outgoing resolution from 480i to 1080p60.

  • Page 5: Vs10 Interface

    1. Introduction 1. Introduction (1) VS10 Interface (2) VS10 BLOCK DIAGRAM Front SDI OUTPUT IN 1 (SDI) Scaler (AUX1) IN 2 (SDI) Scaler SDI OUTPUT (AUX2) IN 3 (SDI) Scaler PIP1 SDI OUTPUT PIP2 (AUX3) IN 4 (SDI) Scaler Chroma SDI OUTPUT Luma (AUX4)

  • Page 6: Product Configuration

    2. Product Configuration 3. Interface (1) HDMI Multiview Interface Monitoring Monitoring PREVIEW PROGRAM Stand-alone type Adaptor SDI1 SDI2 SDI3 SDI4 SDI5 SDI6 SDI7 SDI8 VS10 Input Monitoring Manual...

  • Page 7: Console Interface

    3. Interface [AUX1-4] Changes AUX outputs (2) Console Interface [F1],[F2] Undefined [PIP1] Go to PIP1 menu [PIP2] Go to PIP2 menu [KEY] Go to KEY menu Menu PIP1,PIP2, AUX Source AUX1-4 F1,F2 Screen WIPE, DSK Enter, Menu Key, Audio Joy Stick [WIPE] Go to WIPE menu [DSK] Go to DSK menu [AUDIO] Go to AUDIO menu...
  • Page 8 3. Interface [Power Switch] Power On / Off (2) Console Interface [DC 12V IN] [IN1-8(BNC)] Connects SDI signal [IN 9-10(HDMI)] Connects HDMI signal [LAN] Used for debug [USB] Used for updates (Firmware update/Multiview/Button Map/Media AUX 1-4 IN7-8 IN9-10 Player) [AUDIO IN(XLR)] Audio input socket [AUDIO OUT(XLR)] Audio output socket [AUX 1-4, PGM(BNC)] SDI signal output [REF IN(BNC)] Connects reference signal...

  • Page 9: Lcd Screen

    4. LCD Screen HOME MENU [Wipe1] [Wipe2] Shows WIPE1, WIPE2 type [Chroma/Luma] Shows selected KEY Background: [Transition Rate] Shows AUTO TIME SDI/ HDMI/ [System] Shows VS10 SYSTEM RESOLUTION PIP1 MEDIA/ [Inputs] Shows the source given to the button TEST Pattern PIP2 (Color Bar, Color BG)
  • Page 10 KEYER MENU [Chroma] CHROMA Key Mode [Source Aux] Go to CHROMA source selection menu Green Blue (PIP1, PIP2 also selectable as CHROMA source) 0° 60° 120° 180° 240° 300° 360° [XY] Select if to simultaneously set values of XY or not [Hue Center, Hue Width, Hue Gain] Opaque Gain 0% =120...
  • Page 11 LUMA Key Mode Wipe Menu * Select WIPE type used in WIPE1, WIPE2 16(64) 235(940) * To select, use: AUX button 100% Touch-screen Rotate jog button to select and select by pressing Gain 0%= Maximum semitransparent region Opaque Minimum Transparent DSK Menu Gain 100%= No semitransparent region Opaque...
  • Page 12 AUX Menu Menu> System Resolution * Select system resolution * Select AUX output source * Press OK button to apply and save * VW, PGM, CLEAN, MVW can be selected as AUX by pressing blue arrow on the top right-hand corner * CLEAN is the video without DSK(Fill, Key) ] Go to next page ] Go to previous page...
  • Page 13 Menu> System Resolution Data saved in USB disk can be retrieved in USB menu (Supported USB format is FAT) * Shows LAN information * Change IP address by turning OFF DHCP 3 types of data can be used * Save by pressing OK 1.

  • Page 14: Vs10 Utility

    5. VS10 Utility [Labeling] [Multiview] Select desired port in LABELING tap and change the input name as desired. Multiview layouts are even more customizable at INPUT SOURCE tap (Select the source and drag-n-drop to change positions) [Layout] Select preferred Multiview layout. SDI 6...
  • Page 15 [Mapping] [Save] Map the input port to desired button on the console. Save the setting to the USB. [Media] [Channel] Select the image to save in Media 1 and 2. Select size. Select the desired ColorBG.

  • Page 16: System Specification

    6. System Specifications ・ 3G/HD/SD-SDI Input : BNC 75Ω 8ea (with Scaler) ・ HDMI Input : 2ea (with Scaler) ・ 3G/HD/SD-SDI Output : BNC 75Ω 6ea (AUX1/AUX2/AUX3/AUX4/PGMx2) ・ HDMI Output : 2ea (PGM/MULTIVIEW) ・ Remote: 1ea Connections ・ Reference Input: 1ea ・...
  • Page 17 1. Download recent version of the manual from the following link. (http://www.lumantek.co.kr/index/download/product/40/q/type/~M~) 2. Features of this product can be added, removed, changed.
