PARTS LIST

TROUBLE SHOOTING
Rotary Arm doesn't spin:
1
• Remove, inspect and clean nozzles.
Replace if damaged
• Ensure there is no water leaking
excessively from the weep holes on
the rotary head (water will normally
seep out of these holes).
All components of the surface cleaning system have a 90-day warranty against manufacturer's defects only.
1
Ref. # Description
1 Rotary Head
2 Cover
3 Nozzle
4 Rotary Arm
5 14" Brush
2
AW-7020-8009
Part #
33-0598
33-0597
18-0298
33-0596
33-0595
2
WARRANTY
3
4
5
Qty.
1
1
2
1
1
Leaves striping:
• Ensure nozzles aren't damaged or
plugged.
• Ensure rotary arms are straight.
• Ensure nozzle groove is in align-
ment with arm.
