  • Page 1 Mobile NVR M1142 Quick Start Guide...

  • Page 3: Table Of Contents

    Network for the 1st Time..........51 Hot-swap a SATA HDD/SSD ...........16 Remove Bottom Cover ............17 Install a WiFi Module ............19 Install a SIM Card ............23 Install a 3G or 4G plus GPS Module (Optional) ....24 Mobile NVR M1142 Quick Start Guide...

  • Page 4: Preface

    If you are not sure about the description herein, consult your vendor before further handling. We recommend that you keep one copy of this document for the quick reference for any necessary maintenance in the future. Thank you for choosing GVD products. Declaration of Conformity This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules.

  • Page 5: Hardware Requirements

    Recording data is one of the most important parts for video surveillance, and hard disk drives are one of the most important components to safely store the recording data. It is always recommended that you use the hard disk drives certified by GVD. Find the list of the GVD- certified hard disk drives at the link below: http://www.gvdigital.com/gvdweb/html/document/Support_Lists/Certified%20HDD%20List.pdf...
  • Page 6 Mobile NVR M1142 Quick Start Guide...

  • Page 7: Introduction

    NVR is verified to be anti-shock and anti-vibration to guarantee more protection to the hard disk drives onboard and ensures reliable video recording. Four PoE LAN ports are featured on the M1142. Each port delivers power up to 25.5W and simultaneously transfers data up to 1000 Mbps over a single CAT-6 cable.

  • Page 8: Accessories

    (for +8~35VDC output) Internal HDD/SSD Screws A number of screws to fix the internal HDD/SSD ■ Stainless-steel round philips screws Outside-accessible HDD/SSD Keys Two keys to the door to the outside-accessible and hot-swappable HDD/SSD SATA port Mobile NVR M1142 Quick Start Guide...
  • Page 9 All regions (Optional) Sierra Wireless® AirPrime™ MC8705 w/ 15cm internal wire A few screws to fix the ■ Operational bands: WCDMA 850, module WCDMA 900, WCDMA 1900, WCDMA 2100 ■ Stainless-steel round philips screws Mobile NVR M1142 Quick Start Guide...

  • Page 10: Take A Tour

    Description Green Lights when the system is powered on. Status LEDs Lights when the SATA HDD is being accessed. Yellow Blinks when the watchdog timer is started. Green Lights when ignition signal is received. Mobile NVR M1142 Quick Start Guide...
  • Page 11 Implemented with industrial-grade ITE8783 Super IO chip (-40 to 85°C) which supports up to 115200 bps data transfer rate. Pinout: Pin# RS232 RS422 (Two-wire) RS485 COM1 & COM2 422 TXD+ 485 TXD+/RXD+ 422 RXD+ 422 RXD- 422 TXD- 485 TXD-/RXD- Mobile NVR M1142 Quick Start Guide...
  • Page 12 Four USB 3.0 ports that run with xHCI (eXtensible Host Control Interface) by default and supports the devices of USB 3.0 port USB 3.0, USB 2.0, USB 1.1 and USB 1.0. Legacy USB is only supported when the xHCI is set to Smart Auto in the BIOS Setup utility. Mobile NVR M1142 Quick Start Guide...

  • Page 13: Rear I/O Ports

    2. The ignition input allows ACC power of car (12Vdc) or bus/truck (24Vdc). Supplying power over 35V to the ignition input will damage the system. Antenna An antenna aperture for WiFi antenna. aperture 1 See also Install a WiFi Module on page for more details. Mobile NVR M1142 Quick Start Guide...
  • Page 14 When the switch is on, the ignition signal is de-asserted to initiate system shutdown. No power-on/off delays are available with this mode. See also Select Ignition Power Mode on page for the pin definition. Mobile NVR M1142 Quick Start Guide...
  • Page 15 Antenna aperture 2 is for 3G or 4G antenna while Antenna aperture 3 is for GPS antenna.. apertures 2 See also Install a 3G or 4G plus GPS Module (Optional) on page for more details. & 3 Mobile NVR M1142 Quick Start Guide...

  • Page 16: Onboard I/O Ports

    SODIMM SATA data mSATA SIM card Mini Card connector 1 socket connector 1 socket socket 1 socket SIM card socket 2 Full-size PCIe Mini Card socket SATA data SATA power connector 2 connector 2 Mobile NVR M1142 Quick Start Guide...
  • Page 17 Full-size mSATA socket & The socket is associated with SIM card socket 1 this status LED, the one that is in the center among the three. See also Front I/O Ports on page 4. Mobile NVR M1142 Quick Start Guide...
  • Page 18 13. A 4-pin SATA power connector for an outside-accessible 2.5" SATA HDD/SSD, with hot-swap SATA power connector 2 supported. To install the outside-accessible SATA HDD/SSD, see Open Pet Door on page 13. Mobile NVR M1142 Quick Start Guide...

  • Page 19: Install Hardware

    NVR. Remove this screw. Part the pet door from the mobile NVR. The inside of the mobile NVR then comes to view. Part the pet door from the mobile NVR. Mobile NVR M1142 Quick Start Guide...

  • Page 20: Install Internal Sata Hdd/Ssd

    A thermal pad Part the pet door from the mobile NVR. Remove the protection films. Place a thermal pad onto the inner side of the pet door. Part the pet door from the mobile NVR. Mobile NVR M1142 Quick Start Guide...
  • Page 21 Plug the SATA SSD to the pet door by fastening 4 screws. connector to the SATA HDD/SSD. Restore the pet door. Pull the SATA connector from the motherboard. Pull the SATA connector from the motherboard. Mobile NVR M1142 Quick Start Guide...

  • Page 22: Hot-Swap A Sata Hdd/Ssd

    Pull at the door handle. Retrieve the key and lock the door by turning The spring-loaded door then auto opens. the key to the lock position as printed on the door. The door auto opens. Mobile NVR M1142 Quick Start Guide...

  • Page 23: Remove Bottom Cover

    Then continue to slide the bottom cover until it is fully apart from the mobile NVR. When the SATA cables for the outside-accessible HDD/SSD come to view, disconnect them from the Mobile NVR M1142 Quick Start Guide motherboard.
  • Page 24 To install a SIM card, see Install a SIM Card on page 23. To install a 3G or 4G plus GPS module, see Install a 3G or 4G plus GPS Module (Optional) on page 24. Mobile NVR M1142 Quick Start Guide...

  • Page 25: Install A Wifi Module

    U.FL connector connectors. the notch exactly as shown. among the Two U.FL connectors module's contact pins should meet the break of the connector. The module has a notch among the contact pins. Mobile NVR M1142 Quick Start Guide...
  • Page 26 SMA connector to meet the flat side of the antenna aperture. 3G/4G +GPS Antenna aperture 1 WiFi 3G/4G Pull the SMA connector jack through Antenna aperture 1 on the rear panel of the mobile NVR. Mobile NVR M1142 Quick Start Guide...
  • Page 27 Then continue to slide util the 13. Restore the pet door. bottom cover cannot be slid anymore. When the SATA cables for the outside-accessible HDD/SSD come in reach, re- connect them to the motherboard. Mobile NVR M1142 Quick Start Guide...
  • Page 28 WiFi. Note If the mobile NVR has more than one wireless modules installed, it is recommanded that you lay out the antenna wires and the external antennas as illustrated below: 3G/4G +GPS WiFi 3G/4G Mobile NVR M1142 Quick Start Guide...

  • Page 29: Install A Sim Card

    GPS module lock the SIM card as described in place. Install a 3G Full-size PCIe or 4G plus Mini Card GPS Module socket for 3G or 4G plus (Optional) page Mobile NVR M1142 Quick Start Guide...

  • Page 30: Install A 3G Or 4G Plus Gps Module (Optional)

    The module is wire to the the break of the connector. a full-size PCIe "GPS" U.FL Mini Card, connector with three U.FL on the module. connectors. The module has a notch among the contact pins. Mobile NVR M1142 Quick Start Guide...
  • Page 31 3 external antennas as illustrated below: Antenna 3G/4G aperture 2 +GPS 3G/4G SMA connector Pull the SMA connectors through the antenna apertures exactly as shown. WiFi 3G/4G Mobile NVR M1142 Quick Start Guide...

  • Page 32: Mobile Nvr M1142 Quick Start Guide

    Then continue to slide util the bottom cover cannot be slid anymore. 13. Restore the pet door. When the SATA cables for the outside-accessible HDD/SSD come in reach, re-connect them to the motherboard. Mobile NVR M1142 Quick Start Guide...
  • Page 33 Note If the mobile NVR has more than one wireless modules installed, it is recommanded that you lay out the antenna wires and the external antennas as illustrated below: 3G/4G +GPS WiFi 3G/4G Mobile NVR M1142 Quick Start Guide...

  • Page 34: Mount The Mobile Nvr

    Place the mobile NVR upside down on a flat and soft surface. Remove the four rubber feet that are sticked to the bottom of the mobile NVR as marked in the illustration below. Remove the four rubber feet. Mobile NVR M1142 Quick Start Guide...
  • Page 35 M4 screws at the tapped holes as illustrated below. 25.2 Use the ➌ other M4 ➎ screws Fasten four M4 ➍ to mount screws to fix the the mobile bracket. NVR. Mobile NVR M1142 Quick Start Guide...

  • Page 36: Wire Dc-In Power Source

    Note the Identify the positive polarities between the wires and and the negative posts of the terminal the terminal block plugs must be block as illustrated below. positive to positive and negative to negative. Mobile NVR M1142 Quick Start Guide...
  • Page 37 Note If the mobile NVR is used on a train, it is recommended that you use an additional EN50155-compliant single- output DC-to-DC converter or let the mobile NVR tap from UPS (uninterruptible power supply). Mobile NVR M1142 Quick Start Guide...

  • Page 38: Manage Ignition Power

    Connect car battery -/GND line to GND. Connect ACC line to IGN. Caution Make sure your DC power source and IGN signal share the same ground. The IGN input accepts max. 35VDC. Supplying power over 35VDC may damage the system. Mobile NVR M1142 Quick Start Guide...

  • Page 39: Select Ignition Power Mode

    5. Modes D to F feature very long power-off delays and "smart off-delay", which auto-detects system status during the power-off delay to cut off the system power if the system powers off before the power-off delay expires. Mobile NVR M1142 Quick Start Guide...

  • Page 40: Set Up Windows

    It takes a while for the wizard to finalize the your locale. settings. ➌ ➍ Once the finalization is through, the system auto- Click the Next button to proceed. restarts to apply the change. Mobile NVR M1142 Quick Start Guide...

  • Page 41: Initialize Hdds

    When the initialization is through, the selected HDDs will display “Online” status. Note For HDD size greater than 2TB, select GPT instead of MBR for initialization. Right-click on a “Non Initialized” HDDs and then click Initialize Disk. Mobile NVR M1142 Quick Start Guide...

  • Page 42: Launch & Log In

    Initialize HDDs on page 35, proceed to launch and log in to GVD HD NVR, a collection of utilities that allow the mobile NVR to control of all the networked cameras. Follow the guide below to launch the HD NVR Manager for the first time: The software then prompts you to confirm.

  • Page 43: Use Installation Wizard

    Name. The Initialize Wizard auto-opens. 3. Enter a desired name for the NVR. Then click The welcome page of the Initialization Wizard. the Next button to proceed. 2. Click the Next button to continue. Mobile NVR M1142 Quick Start Guide...
  • Page 44 Then click the From the Date and Time window that opens, Next button to proceed. click the Change time zone... button and set the time zone. Then click the Next button to proceed. Mobile NVR M1142 Quick Start Guide...
  • Page 45 Yes to proceed. Then click the Next button to proceed. 9. Log in to the NVR again. After login, the wizard reopens Step 5: Network Setting. 10. Click the Next button again to proceed. Mobile NVR M1142 Quick Start Guide...
  • Page 46 The system will use a camera manufacturer's and listed. If after the rescanning the cameras default username & password to add a to discover still cannot be discovered, click camera. button to open the Manually Add Camera tool. Mobile NVR M1142 Quick Start Guide...
  • Page 47 15. Select the camera(s) to enable recording for. Then click the Next button to proceed. The wizard then prompts Step 9: Storage 14. Select the camera(s) you want to import. Automation Declaration. Then click the Next button to proceed. Mobile NVR M1142 Quick Start Guide...
  • Page 48 The HD NVR Manager then launches. (a). If you have selected Yes in step 16, follow the guide below to proceed. (1) Click the Execute button. The wizard then proceeds to install the Mobile NVR M1142 Quick Start Guide...
  • Page 49 (2) Click the OK button to close the prompt. (3) Back to the wizard, click the Finish button to finish the configuration and quit the wizard. Mobile NVR M1142 Quick Start Guide...

  • Page 50: Configure Network Parameters

    Sharing Center | Change adapter press the OK button. settings. Right-click over the active connection to use and click Properties from the context menu that opens. Click Internet Protocol Version 4 (TCP/IPv4). Then click the Properties button. Mobile NVR M1142 Quick Start Guide...

  • Page 51: Create Storage Volumes

    A New Volume dialog box then opens. A prompt then shows and asks for your 5. In the Volume Name field, enter the name confirmation. of the volume to create. 9. Click Yes to continue. Mobile NVR M1142 Quick Start Guide...

  • Page 52: Auto-Add A Camera

    "manually- the Device tab from the Tree Panel. Then add" a camera. click the plus sign button Click An Auto Discovery window then opens. Tree Panel Then click. Mobile NVR M1142 Quick Start Guide...
  • Page 53 11. Click the OK button to finish and quit the setting. 8. To enable the camera to record videos, click the Recording Settings tab on the Configuration Note To set up the schedule recording, see the user’s Page. manual for details. ➑ ➒ Mobile NVR M1142 Quick Start Guide...

  • Page 54: Appendix. Install Wifi Device Driver & Connect Wifi Network For The 1St Time

    Utility or simply Install driver only. Then click the Next button to proceed. Note Since the operating system, Windows 7 Embeded, comes with a WiFi connection utility, it isn't a must to install the connection utility featured by the module. Mobile NVR M1142 Quick Start Guide...
  • Page 55 WiFi network. Then click the icon The Netowrk and sharing center then opens and shows the available WiFi network(s) within reach. When the installation is through, the wizard prompts having succesfully installed the driver. Mobile NVR M1142 Quick Start Guide...
  • Page 56 The utility then opens a Connect to a Network dialog box and tries to connect the WiFi network you clicked. The utility then asks you for the password to access the network. A WiFi network is connected. Mobile NVR M1142 Quick Start Guide...

  • Page 57: Appendix. Install 3G/4G Device Driver & Connect Mobile Network For The 1St Time

    You can also download a copy of the 3G or 4G device driver on Sierra Wireless website or HUAWEI website. The installer then opens. Click the I Agree button to proceed. The driver installation then starts, progresses and finishes. Mobile NVR M1142 Quick Start Guide...
  • Page 58 Click the network you want to use and then click the Connect button. After system restarts, the Notfication Area Double-click the network you want to of the operating system shows an icon use. saying Unidentified network and No network access. Mobile NVR M1142 Quick Start Guide...
  • Page 59 If you are asked for a PIN code, enter the vaild code. The Notfication Area then shows an icon that signifies the signal strength. The mobile network to connect is connected. Mobile network is connected. Mobile NVR M1142 Quick Start Guide...
  • Page 60 June 2016 Genius Vision Digital sales@gvdigital.com support@gvdigital.com www.gvdigital.com...
