- Page 1 GVD HD NVR Hardware Quick Installation Guide...
-
Page 2: Table Of Contents
Content Hardware Installation Recommended HDD for GVD NVR M90 Series M100 Series M150 Series M200 Series M350 Series M600 Series Recording HDDs Initialize Procedures Software Configuration Disable System Protection Date & Time/Time Zone Setup Network Setup Screen Resolution Setup Enable System Protection... -
Page 3: Hardware Installation
It is always recommended to use the hard disk model that GVD certifies, user can find the updated list from the URL below : http://www.gvdigital.com/document/Support_Lists/GVD_Certified_HDD_List.pdf... -
Page 4: M90 Series
Empowering Megapixel * GVD will not be liable for any malfunction of the system if customer installed any non-certified 3rd-party application in the system. * For M90 series, it can support decoding resolution from D1 up to 3M * Please DO NOT plug any USB device other than keyboard &... -
Page 5: M100 Series
Plug in the power cord to the AC power socket of power distribution unit and the system will turn on automatically. * GVD will not be liable for any malfunction of the system if customer installed any non-certified 3rd-party application in the system. -
Page 6: M150 Series
Plug in the all power cords to the AC power socket of power distribution unit and system will turn on automatically. * GVD will not be liable for any malfunction of the system if customer installed any non-certified 3rd-party application in the system. - Page 7 Hardware Installation M150 Series 10 11 12 13 14 15 16 17 18 Reset Step by Step Backward Playback Step by Step Forward Playback HDD Fail On when there is HDD in exception state Playback Backward Off when all HDDs are in normal state Pause Video Loss Playback Forward...
-
Page 8: M200 Series
Plug in the power cord to the AC power socket of power distribution unit and the system will turn on automatically. * GVD will not be liable for any malfunction of the system if customer installed any non-certified 3rd-party application in the system. -
Page 9: M350 Series
Plug in the power cord to the AC power socket of power distribution unit and the system will turn on automatically. * GVD will not be liable for any malfunction of the system if customer installed any non-certified 3rd-party application in the system. - Page 10 Hardware Installation M350 Series 2 3 4 5 6 7 9 10 11 12 13 14 15 Power Step by Step Backward Playback Step by Step Forward Playback Reset Power LED Playback Backward Recording LED Pause On when NVR is recording Playback Forward Off when NVR is not recording Manual Recording...
-
Page 11: M600 Series
Plug in the all power cords to the AC power socket of power distribution unit and system will turn on automatically. * GVD will not be liable for any malfunction of the system if customer installed any non-certified 3rd-party application in the system. -
Page 12: Recording Hdds Initialize Procedures
Recording HDDs Initialize Procedures The newly added Hard Disks need to be initialized before volume creation Log on to Windows ® Right click “My Computer” icon on desktop. Select the “Manage” option. Select the item “Disk Management” under “Storage” node for initializing the newly added HDDs. -
Page 13: Software Configuration
Software Configuration Before configure the system, user need to disable the system protection function first and re-enable it after finishing configuration. Please follow the steps below to configure the system: Disable System Protection ® Log on to Windows Double click on the Windows Toolbar. -
Page 14: Date & Time/Time Zone Setup
Date & Time/Time Zone Setup Log on to Windows ® Go to ‘Start Control Panel Date & Time’. Select the ‘Time zone’ tab, set the correct time zone and apply. Select the Date & Time tab, set the correct date & time and apply. Select the ‘Internet Time’... -
Page 15: Network Setup
Network Setup Go to ‘Start Control Panel Network’. Right mouse click on the active connection icon and select ‘Properties’ from the pop-up menu. Select ‘Internet Protocol (TCP/IP) and then press ‘Properties’. In the ‘General’ tab, set the preferred IP address and the subnet mask then press ‘OK’. -
Page 16: Screen Resolution Setup
Screen Resolution Setup Go to ‘Start Control Panel Display Properties’. Switch to Settings tab. Change the ‘Screen resolution’ to 1680 x 1050 (recommend value). Press ‘OK’ for saved the settings. *The minimum supported screen resolution is 1280 x 1024. Hardware Quick Installation Guide... -
Page 17: Enable System Protection
Enable System Protection After the system has been configured, user needs to re-enable the system protection function in order to keep the system away from harm. Please follow the steps below to re-enable the system protection function: Enable System Protection Double click on the Windows Toolbar. -
Page 18: Create Volume For Recording
Create Volume for Recording ® In Windows desktop, double click the SCM program icon ( Admin 6001 Input default username and password to login. In the SCM program, press the ‘New Volume’ button in the left panel. Input the name of the volume in the ‘Volume Name’ field. Select the preferred hard disk(s) from the available hard disk list. -
Page 19: Add Camera Automatically
Add Camera Automatically In Windows ® desktop, double click the HD NVR Manager program icon ( Log on HD NVR Manager using default username Admin and password 6001. Go to Configuration Mode. Select the ‘Device’ tab, click the ‘Add’ button.‘Add Camera Device’ dialog appears as shown below. - Page 20 Add Camera Automatically (cont’d) Select ‘Auto Discovery’ and the dialog appears as shown below. Click the ‘Vendor’ dropdown box and select the preferred vendor name from the list then pressing ‘Search’ to continue. Input username and password of the vendor camera. The system automatically searches all vendor’s connected IP cameras in the network.
- Page 21 Add Camera Automatically (cont’d) To activate the recording function of the camera, select the ‘Recording Settings’ tab in the Configuration page. Press the ‘Assign Storage’ button. An ‘Assign Storage’ dialog appears. Select the preferred volume and click ‘OK’. Click ‘OK’ in the Configuration page to exit. *To set up the schedule recording, refer to the HD NVR Manager user manual for more details.
-
Page 22: Setup Motion Recording
Setup Motion Recording Motion Recording by Using Simple Alarm Go to Configuration Mode Configuration Mode Select the camera that you want to setup for motion recording then click the modify button. In camera’s Configuration Page, select Motion tab to enable motion detection of the camera and adjust detection sensitivity to the desired level. - Page 23 Setup Motion Recording (cont’d) Select Recording Settings tab and disable camera’s recording. Select Alarm tab to enable recording only when there is motion detected. Click OK button to finish setup. Hardware Quick Installation Guide...
- Page 24 12 & 16 12 & 13 12 & 15 Hardware Quick Installation Guide...
-
Page 25: Troubleshooting Faq
The IP address of camera does not have the same subnet with HD NVR (Ethernet card). The camera may not be supported by HD NVR, please check the supported cameras list at GVD website "http://www.gvdigital.com/support_device.html". Why can't get video after adding camera? - Page 26 Troubleshooting FAQ (cont’d) How to install the Anti-Virus software for GVD HD NVR? Before installing Anti-Virus software, please follow the instructions to disable the system protection function first (refer to page 12) and enable it after finishing software installation and configuration.
-
Page 27: Appendix
Appendix. How to create RAID 5 This appendix chapter for M600 Series NVR only. RAID System Creation Open Areca HTTP Proxy Server GUI Start Areca Technology Corp ArcHttpSrvGUI Areca HTTP Proxy Server GUI Select Controller #01(PCI),HTTP Port #81 and click “Launch Browser” button Hardware Quick Installation Guide... - Page 28 Appendix. How to create RAID 5 admin 0000 Input for username and for password to login. Successfully login to RAID Console page. Hardware Quick Installation Guide...
- Page 29 Appendix. How to create RAID 5 Create RAID Set RaidSet Function Create Raid Set Select from the menu at the left. Check the HDDs to be added in the Raid set (here use 3 HDDs as an example) Confirm The Operation Check checkbox Submit...
- Page 30 Appendix. How to create RAID 5 Create Volume Set Volume Set Functions Create Volume Set Select from the menu at the left. Submit Select the Raid set just created and click the button. Select the Raid level wish to create (here use Raid 5 as an example).
- Page 31 Appendix. How to create RAID 5 Change to Background Initialization Change to Write Through You should see the following message when the Volume set was created successfully. Hardware Quick Installation Guide...
- Page 32 Appendix. How to create RAID 5 After volume set was created, it will start to partition the volume set and show you the completion rate of the process. Normal Volume State After partition completed, you should see in all columns. Hardware Quick Installation Guide...
-
Page 33: Change Boot Priority
Appendix. Change Boot Priority This appendix chapter is for M200-AR only. Change M200’s boot priority after creating RAID set During system boot up, click “Del” key to get into BIOS. Select “Advanced BIOS Features” and press Enter Select “Hard Disk Boot Priority” and press Enter Hardware Quick Installation Guide... - Page 34 Appendix. Change Boot Priority Change the hard disk boot priority and make the DOM device as the first boot device, e.g. Device name: SATA:PS-4G SATA Flash Drive. Press “ESC” key to return to the main menu. Select “Save & Exit Setup” and press Enter.
-
Page 35: Hdd Installation Guide
Appendix. HDD Installation Guide M90 HDD Installation Guide Unscrew the screws to remove the machine’s cover as indicated below. Unscrew the 4 screws to remove the HDD tray and take off the power cord. Hardware Quick Installation Guide... - Page 36 Appendix. HDD Installation Guide Install HDD to the HDD tray and screw the 4 screws as indicated below. Connect HDD with SATA & power cables then install the HDD tray back to the machine. Install the machine’s cover back. Hardware Quick Installation Guide...
- Page 37 Appendix. HDD Installation Guide M100 HDD Installation Guide Unscrew the screws to remove the machine’s cover as indicated below. Take out the power cable as indicated below. Unscrew the screw of the HDD tray and remove it as indicated below. Hardware Quick Installation Guide...
- Page 38 Appendix. HDD Installation Guide Install HDDs to the HDD tray as indicated below. Connect HDDs with SATA and power cables then install the HDD tray back to the machine. Install the machine’s cover back. Hardware Quick Installation Guide...
- Page 39 Appendix. HDD Installation Guide M150/M155 HDD Installation Guide Unscrew the screws to remove the machine’s cover as indicated below. The red rectangles area indicated below is where HDDs will be installed. Hardware Quick Installation Guide...
- Page 40 Appendix. HDD Installation Guide Screw the screws from the bottom side of the case to fix the HDDs. Connect HDDs with SATA & power cables. Install the machine’s cover back. Hardware Quick Installation Guide...
- Page 41 Appendix. HDD Installation Guide M350 HDD Installation Guide Unscrew the screws to remove the machine’s cover. (2 screws at each side and 3 at the back, total 7 screws) Unscrew the screws of CD-ROM & HDD trays as indicated below. Hardware Quick Installation Guide...
- Page 42 Appendix. HDD Installation Guide Lift the trays with care. Install HDDs into both CD-ROM & HDD trays and screw the screws to fix the HDDs. CD-ROM Tray HDD Tray Hardware Quick Installation Guide...
- Page 43 Appendix. HDD Installation Guide Install both CD-ROM & HDD tray back to the machine and connect both CD-ROM & HDDs with SATA & power cables. After all HDDs have been installed, it will look like the picture below. Install the machine’s cover back to finish HDD installation.
