Features & Connections
It's easy to find and use the features and connections on your
Intel® studybook. They are numbered in the front, back, and side
views displayed here.
2
1
Front View
1
2
Back View
1. Home Button
2. LCD Display
3. Front Camera
4. Status Indicator
3
5. Microphone
4
5
1. Rear Camera
3
2. Volume Controls
3. Speaker
Left View
1 2 3 4
Right View
1 2
Battery Charger
You can recharge the battery by connecting the Power Cable to the
Power Input on your Intel studybook. Then, plug the Power Adapter
into an electrical outlet.
1
2
Battery Power Status Indicators
You can check your battery power status at any time, by looking at
the colors of the indicator lights.
Blue light: When you see a blue
light, the battery is fully charged
and the AC adapter is plugged in.
1. Micro SD Reader
2. 3G (optional)
3. HDMI (optional)
4. Audio Out Port
5
5. Power Button
1. Power Port
2. USB 2.0 Port
1. Power Input
3
2. Power Adapter
3. Power Cable
Orange light: When you see
an orange light, the battery power
is low.
