TELUS Smart Hub Quick Start Manual page 6

Know your Smart Hub
You have two options to connect to Smart Hub:
Option 1. Connect wirelessly through Wi-Fi
Step 1: Find the Wi-Fi icon on your device. On a computer this may be in the top or
bottom right-hand corner of your screen. On a mobile device, this is usually under
Settings. Your Wi-Fi icon may look like one of the following:
Step 2: From your device, select the Wireless network
name (SSID) printed on the sticker at the rear of
the Smart Hub (to view sticker slide open the
battery cover).
Step 3: Type in the password Wi-Fi Key
(Wireless Security Key) then Connect. A "✔" or
"Connected" will indicate you are successful.
8
Set-up Connect
URL: http://telus.ztesmarthub
Login/Connexion: admin
Wireless Network Name (SSID)
Nom de réseau sans-fill (SSID)
ZTE MF279T/2.4GXXXX
ZTE MF279T/5GXXXX
Wireless Security Key
Clé de sécurité sans-fil
XXXXXXXXXX
Data Usage Configurations
Step 4: Test your Internet connection by searching a website from your Internet browser.
If no data connection or Power, Wi-Fi or Network indicator light is red,
go to Troubleshooting section.
Option 2. Connect directly using a cable
An optional way to connect your desktop or laptop computer is directly to the Smart Hub.
Step 1: Using the LAN cable provided in the
box, connect one end to the LAN port
on the Smart Hub and the other end
to the LAN port on your computer.
Desktop or Laptop
Ethernet port
Step 2: Test your Internet connection by searching a website from your Internet browser.
Troubleshoot
!
9
