The 1966 Shelby GT350 is a modi-
fied high performance version of
the 1966 Ford Mustang. The Shelby
Mustangs had funtional brakes
scoops, special quarter panel win-
dows and a high performance engine
that produced 306 horsepower.
Your Monogram Mustang model
features an opening hood with a
highly detailed 289 high-perfor-
mance engine, side body brake
scoops and front bucket seats.
A waterslide decal with authentic
factory markings and optional col-
ored body stripes is also included.
* REPEAT SEVERAL TIMES
REPEAT PROCEDURE
*
` `
* A REPETER PLUSIEURS FOIS
* REPETEZ LE PROCEDE
READ THIS BEFORE YOU BEGIN
* Study the assembly drawings.
* Each plastic part is identified by a number.
* In the assembly drawings, some parts will be
marked by a star (★) to indicate chrome
plated plastic.
* For better paint and decal adhesion, wash
the plastic parts in a mild detergent solution.
Rinse and let air dry.
* Check the fit of each piece before
cementing in place.
* Use only cement for polystyrene plastic.
* Scrape plating and paint from areas
to be cemented.
* Allow paint to dry thoroughly before
handling parts.
* Any unused parts may be discarded.
DECAL APPLICATION INSTRUCTIONS
1. Cut desired decal from sheet.
2. Dip decal in water for a few seconds.
3. Place wet decal on paper towel.
4. Wait until decal is movable on paper backing.
5. Place decal in position on model, face up and
slide backing away.
6. Press out air bubbles with a soft damp cloth.
7. Milkiness that may appear is for better decal
adhesion and will dry clear. Wipe away any
excess adhesive.
8. Do not touch decal until fully dry.
9. Allow the decals 48 hours to dry before
applying clear coat.
NOTE: Decals are compatible with
setting solutions or solvents.
If you have any questions or comments, call our hotline at:
Revell Inc Consumer Service Department, 1850 Howard Street Unit A, Elk Grove Village, Illinois 60007
Be sure to include the plan number (85429300200), part number, description, your return address and phone number.
KIT 4293
'66 SHELBY GT350
* DECAL
* OPTIONAL PARTS
`
`
* DECAL COMANIE
* PIECES EN OPTION
LIRE CE QUI SUIT AVANT DE COMMENCER
* Etudier les schémas de montage.
* Chaque pièce en plastique est identifiée par un numéro.
* Sur les schémas de montage, certaines pièces sont
marquées d'une étoile (★) pour indiquer qu'elles sont en
plastique chromé.
* Pour une meilleure prise de la peinture et des autocollants,
laver les pièces en plastique avec une solution détergente peu
concentrée. Les rincer et les laisser sécher à l'air.
* Vérifier que chaque pièce s'ajuste bien avant
de la coller en place.
* N'utiliser que de la colle pour polystyrène.
* Gratter les parties à coller pour enlever le chrome et la peinture.
* Laisser la peinture bien sécher avant de manipuler les pièces.
* Toute pièce inutilisée peut être jetée.
DIRECTIVES D'APPLICATION DES AUTOCOLLANTS
1. Découper l'autocollant désiré de la feuille.
2. Tremper l'autocollant dans de l'eau pendant quelques secondes.
3. Placer l'autocollant mouillé sur une serviette en papier.
4. Attendez que l'autocollant puisse être déplacé sur son
support en papier.
5. Mettre l'autocollant en position sur le modèle face sur
le dessus et faire glisser le support pour l'enlever.
6. Appuyer avec un chiffon doux humide pour éliminer les bulles d'air.
7. La substance laiteuse qui peut apparaître est destinée à
améliorer l'adhésion de l'autocollant et devient incolore au
séchage. Essuyer pour enlever tout excédent d'adhésif.
8. Ne pas toucher l'autocollant tant qu'il n'est pas bien sec.
9. Laisser l'autocollant sécher pendant 48 heures avant
d'appliquer une couche transparente.
REMARQUE: Les autocollants sont compatibles avec
les solutions de fixage ou les solvants.
or, please write to:
Visit our website: www.revell.com
Revell Inc Elk Grove Village, IL. Copyright © 2010. All rights reserved.
* CEMENT TOGETHER
* ASSEMBLY CAUTION
`
`
* A COLLER
*ATTENTION D ASSEMBLEE
* REMOVE AND THROW AWAY
* A RETIRER ET JETER
This paint guide is provided to complete this kit
as shown on the box.
Ce guide de peintures est fourni pour reproduire le modèle
réduit qui apparaît sur la boîte.
Silver
Argent
Aluminum
Aluminu
Ford Engine Blue
Bleu
Semi Gloss Black
Noir brilliant
Gloss Red
Rouge brillant
Bois
Wood
Steel
Acier
Turn Signal Amber
Ambre
Rouge transparent
Transparent Red
White
Blanc
(800) 833-3570
85429300200
* DO NOT CEMENT
* NE PAS COLLER

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the '66 SHELBY GT350 and is the answer not in the manual?

Questions and answers

Summary of Contents for Monogram '66 SHELBY GT350

  • Page 1 Mustangs had funtional brakes scoops, special quarter panel win- dows and a high performance engine that produced 306 horsepower. Your Monogram Mustang model features an opening hood with a highly detailed 289 high-perfor- mance engine, side body brake scoops and front bucket seats.
  • Page 2: Engine Assembly

    ENGINE ASSEMBLY DISTRIBUTOR ★82 ★81 ★31 ROCKER COVER SEMI GLOSS BLACK ROCKER COVER CARBURETOR (PAINT SHADED AREA ALUMINUM) CHROME CHROME RT. ENGINE HALF CHROME FORD ENGINE BLUE CYLINDER HEAD (PAINT SHADED AREA ALUMINUM) FORD ENGINE BLUE INTAKE MANIFOLD STARTER ALUMINUM SEMI GLOSS BLACK CYLINDER HEAD FORD ENGINE BLUE...
  • Page 3: Body Assembly

    BODY ASSEMBLY ★40 REAR VIEW MIRROR CHROME WINDSHIELD CLEAR REAR WINDOW CLEAR BODY BODY COLOR NOTE: SEE DECAL PLACEMENT GUIDE FOR DECAL LOCATION BEFORE ASSEMBLY SIDE WINDOW CLEAR SIDE WINDOW CLEAR ★91 GAS CAP CHROME (PAINT DETAILS WHITE) ★52 TAILLIGHT BEZEL CHROME TRANSPARENT Kit 4293 - Page 3...
  • Page 4: Interior Assembly

    INTERIOR ASSEMBLY DECAL 26 ★93 INSTRUMENT POD TACHOMETER CHROME SEMI GLOSS BLACK DECAL (PAINT SHADED SEMI GLOSS BLACK) DASH ★8 SEMI GLOSS BLACK DECAL SHIFTER (PAINT TRIM SILVER) CHROME (PAINT SHADED AREA STEERING WHEEL STEERING COLUMN SEMI GLOSS BLACK) WOOD SEMI GLOSS BLACK PAINT SHADED ALUMINUM) ARM REST...
  • Page 5: Suspension Assembly

    SUSPENSION ASSEMBLY EXHAUST ALUMINUM FRONT SUSPENSION SEMI GLOSS BLACK CHASSIS SEMI GLOSS BLACK RT. SHOCK LT. SHOCK ABSORBER ABSORBER SEMI GLOSS BLACK SEMI GLOSS BLACK REAR AXLE SEMI GLOSS BLACK FRONT SPRING SEMI GLOSS BLACK DRIVESHAFT INTO ENGINE ASSEMBLY Kit 4293 - Page 5...
  • Page 6: Wheel / Tire Assembly

    WHEEL / TIRE ASSEMBLY TIRE ★92 INNER WHEEL OUTER WHEEL FLAT BLACK CHROME FINAL ASSEMBLY SEMI GLOSS BLACK BRACE SEMI GLOSS BLACK ★24 MASTER CYLINDER CHROME (PAINT BODY SEMI GLOSS BLACK) RT. SCOOP BODY COLOR DECAL ★51 BACKUP LIGHT CHROME (PAINT SHADED AREA WHITE) DECAL...
  • Page 7 FINAL ASSEMBLY CONTINUED ★80 AIR CLEANER HEADLIGHT LENS CHROME CLEAR (PAINT SHADED AREA WHITE) ★48 HEADLIGHT RADIATOR HOSE BEZEL SEMI GLOSS BLACK ★47 CHROME TURN SIGNAL DECAL CHROME DECAL DECAL ★48 HEADLIGHT BEZEL CHROME HEADLIGHT LENS ★90 ★47 CLEAR GRILLE TURN SIGNAL CHROME CHROME...
  • Page 8: Decal Placement

    DECAL PLACEMENT 17,19 or 22 (Other side decal 2) (Do not dip in water, carefully cut decal out and use white glue to attach) (See step 7A for details) (See step 7A for details) (See step 8 (See step 8 (See step 8 for details) for details) for details)
