- Page 1 AUDI A4/A5 non-MMI Model: QVL-A4L-V6 Specification & Installation www.emeraldintegrations.com...
- Page 2 -AUDI A4/A5 Feature - Control DVD, NAVI by touch (Optional) t l DVD NAVI b t h (O ti - Remote button value copy function (Refer to page no. 24) (O l (Only available in models with remote) il bl i - More convenient installation via sub-board.
- Page 3 -Precaution - You must keep the car key taken off from the car while you work this and finally connect power of the interface this and finally, connect power of the interface. - When to connect the interface cable, you must keep the power cable taken off.
- Page 4 -Main Spec. 1. Input Spec. (MULTI VIDEO INTERFACE) - 1 x Analog R G B Sync . 1 x Analog R,G,B,Sync -. 1 x CVBS(REAR CAMERA) Input. (Rear camera source) - 3 x A/V (NTST & PAL) Input. -. 1 x LCD Input (Car system Input) 2.
- Page 5 -System Composition Remote Control Switch for source toggle AUDI DISPLAY Original Monitor Navigation Input A/V1 Touch Input A/V2 A/V2 LVDS In/Out VIDEO A/V3 CIRCUIT VIDEO Sub-Board CVBS (Rear Camera) POWER CIRCUIT TOUCH A/V OUT HEADREST MONITOR MONITOR Car Input NAVI DIP S/W Power Input (+8VDC~+24VDC)
-
Page 6: Outline Dimension
- Outline Dimension 130mm * 105mm * 20mm 130mm 105mm 20mm www.emeraldintegrations.com... - Page 7 -External Appearance DIP S/W Touch(Navi) LCD-OUT LCD IN LCD-IN TOUCH TOUCH FROM I/F FROM I/F TOUCH TOUCH POWER/CAN AV(IN/OUT) RGB(IN) MODE www.emeraldintegrations.com...
-
Page 8: External Appearance
External Appearance POWER A/V(IN/OUT) RGB(IN) MODE DIP S/W IP S/W LCD OUT LCD-OUT TOUCH TOUCH www.emeraldintegrations.com... -
Page 9: Connector Pin Assignment
Connector Pin Assignment *Power Connect *RGB-IN Connect ① ② ③ ④ ⑤ ⑥ ⑦ ① ② ③ ④ ⑤ ⑥ ⑦ ① ACC (Red) ① R DATA (Red) ① ② GND (Black) ② G DATA (Green) ③ CAN-H (Green+Brown) ③ B DATA (Blue) ④... - Page 10 Connector Pin Assignment *TOUCH Connect ① ② ③ ④ ① X+ (Blue) ② Y+ (White) ② Y+ (White) ③ X- (White) 1 2 3 4 ④ Y- (White) <CIRCUIT DIAGRAM> <CIRCUIT DIAGRAM> www.emeraldintegrations.com...
- Page 11 Connector Pin Assignment * Power Cable FILTER FILTER & FUSE BOX ACC : 12v~24V CAN(H) CAN(L) F-CAM-DET SAFE REAR-C www.emeraldintegrations.com...
- Page 12 -DIP SW DIP SW ※DIP S/W Use Example FUNCTION DIP S/W Selection #PIN ON : Skipping RGB Mode [AUDI A4/A5] RGB INPUT MUTE OFF : RGB Display -. Use Input Mode : A/V3(DVD), ON : Skipping A/V 1 A/V 1 MUTE Navigation (RGB) OFF : A/V1 Display OFF : A/V1 Display...
- Page 13 -REMOTE CONTROL REMOTE CONTROL POWER & PIP: N.C MENU : OSD operation OK : Select ▲ : Up ▼ : Down ◀ : Left, Long press - Factory Mode operation ▶ : Right *FACTORY MODE (Interface setting) Operated by long press with ◀ button or Pressing UP→DOWN→UP→MENU in order www.emeraldintegrations.com...
- Page 14 -OSD Menu : OSD Menu : DVD (Optional) DVD (Optional) ※ For DVD OSD Menu operated, DVD must be connected with AV1 and DVD IR wire of RGB cable has to be wired with DVD’s remote sensor. On AV1 mode, once touch the screen, Menu window appears like left picture.
- Page 15 -OSD Menu: OSD Menu: DMB, NAVI DMB, NAVI On AV2 mode, once touch the screen, Menu window appears like left picture. If no action for 5 sec or touch any other parts of the screen, this will disappear. When selecting “INPUT”, Menu window for mode switching appears like the below picture.
-
Page 16: Video Mode
-OSD(On Screen Display) p y) ※OSD Menu : Operated by Menu button on Remote. · Analog RGB Mode · Video Mode IMAGE Menu - BRIGHTNESS - CONTRAST - SATURATION - HUE - SHARPNESS - USER IMAGE www.emeraldintegrations.com... - Page 17 OSD(On Screen Display) p y) · Analog RGB Mode · Video Mode OSD Menu - LANGUAGE : Language select (English, Chinese) - TRANSPARENT - H_POSITION - V POSITION V_POSITION www.emeraldintegrations.com...
- Page 18 OSD(On Screen Display) p y) · Analog RGB Mode · Video Mode UTIL Menu - FACTORY RESET : Initializing all set values of navi or DVD www.emeraldintegrations.com...
- Page 19 -Factory Mode · Factory Mode- Operated by long press with ◀ button or Pressing UP→DOWN→UP→MENU in order Factory Mode IMAGE – H-POSITION : Horizontal Image position adjustment - V-POSITION : Vertical Image position adjustment - PARK - PARK ENABLE : Rear parking Guide line setting - PARK SETUP : Rear parking guide line position adjustment (Refer to page no 22) PARK SETUP : Rear parking guide line position adjustment (Refer to page no.
-
Page 20: Factory Mode
-Factory Mode : Rear parking guide line Factory Default : PARK ENABLE – OFF ① ① As left picture, Set “Park Enable” to “ON” in Factory Mode. (Default – OFF) ② ② ② After the setting done, rear parking guide line will appear in rear gear position. - Page 21 Factory Mode : Rear parking guide line ③ ③ ③ After H_POS, when pressing “OK” button again, V_POS appears. ※ FACTORY MODE : Operated by long press with ◀ button or Pressing UP→DOWN→UP→MENU in order www.emeraldintegrations.com...
- Page 22 -Factory Mode : Touch Calibration - Set “TOUCH CALIBRATION” to “YES” from “NO” www.emeraldintegrations.com...
- Page 23 -Factory Mode : IR Memory Function IR Memory Function? If user would like to control DVD or DMB by touch, User can get interface memorize DVD or DMB’s remote button value via this function. Step 1.) On Factory menu, select “IR MEMORY” and one of DVD, DMB you desire to set.
- Page 24 Factory Mode : IR Memory Function 3. As soon as pressing the button, the remote button value displays at the right corner and it is saved automatically. 4. Do other buttons as the same procedure. Step 5.) After all remote input finished, select “INPUT”...
- Page 25 -Factory Mode : DVD, DMB Type Selection Factory Default : DVD TYPE – NECVOX/SANYO (For Chinese DVD) DMB TYPE – CMMB (For Chinese DMB) UTIL – DVD TYPE (DMB TYPE) : If your desired DVD or DBM is not NECVOX or SANYO, you have to do IR MEMORY and “DVD TYPE”...
-
Page 26: Product Composition
-Product Composition Remote : 1 Ea Power Cable : 1 Ea LCD Out Cable : 1 Ea A/V Cable : 1 Ea Navi(RGB) Cable : 1 Ea IR Cable : 1 Ea Toggle Switch : 1 Ea LCD Cable : 1Ea TOUCH Cable for board : 1 Ea TOUCH Screen Cable : 1 Ea www.emeraldintegrations.com... - Page 27 Provided LCD-OUT Cable -Installation Structure ※ Be careful with connector contact Monitor TO LCD LCD-IN FROM I/F TOUCH Touch Cable Touch Navigation Screen Provided LCD cable TOUCH DIP S/W LCD-OUT Factory LCD Cable (NAVI) VIDEO INTERFACE (A4) Control Box Control Box POWER A/V(IN/OUT) RGB(IN)
-
Page 28: Installation Guide
-Installation Guide 1. Air-Con box removal Remove the Air-Con. Box with proper tools as the left picture. Remove the indicated part under Remove the indicated part under the head unit with proper tools like the picture. www.emeraldintegrations.com... - Page 29 -Installation Guide 2. Disassembling LCD Remove the LCD case with a proper tool, be careful of the proper tool, be careful of the cable connected with the case. Remove the screws with a proper tool and monitor like the left picture.
- Page 30 -Installation Guide 3. Connect the LCD Cable Connect the original LCD cable from monitor to “LCD-IN” of provided sub-board. Connect the provided LCD-OUT cable between behind of LCD monitor and provided sub-board like left pictures. www.emeraldintegrations.com...
- Page 31 -Installation Guide 4. Connect Touch Screen Cable (Optional) Connect the provided Touch Screen Cable to “Touch” of the sub-board and Touch Screen. Connect the provided LCD cable between the sub-board and interface board. www.emeraldintegrations.com...
- Page 32 -Installation Guide 5. Connect TOUCH(NAVI) cable (Optional) As the pictures, connect the provided Touch(NAVI) cable to provided Touch(NAVI) cable to “TOUCH(NAVI)” Connector of interface board and Navigation’s Touch part. * We provide Touch(Navi) cable with plug&play. www.emeraldintegrations.com...
- Page 33 -FAQ Q 1. When can not change mode. -. Check if the IR Cable (Remote) is connected or not. - Check if LED is turned on or not If it is not turned on Check if power cable is connected or not -.
