Thank you for purchasing our Goal Light. We try hard to ensure that our products
are of high quality and free of manufacturing defects and of missing parts. How-
ever, if you have any problems with your Goal Light, such as a manufacturing
defect or a missing part please contact us at the following:
Toll Free: 1.888.600.8545
Web: www.produnkhoops.com
FAX: (281) 357-4822
Support:
Read this manual all the way through before starting
assembly of your Goal Light. Then read each step
completely before beginning installation.
Patten Pending #62458721
Pro Dunk® Goal Light LED
Lighting System
OWNER'S MANUAL
www.produnkhoops.com/support
Pro Dunk® Hoops
22047 Lutheran Church Rd.
Tomball, TX 77377
1
Advertisement
Related Manuals for Pro Dunk Hoops Goal Light LED
Summary of Contents for Pro Dunk Hoops Goal Light LED
- Page 1 Pro Dunk® Goal Light LED Lighting System OWNER’S MANUAL Thank you for purchasing our Goal Light. We try hard to ensure that our products are of high quality and free of manufacturing defects and of missing parts. How- ever, if you have any problems with your Goal Light, such as a manufacturing defect or a missing part please contact us at the following: Toll Free: 1.888.600.8545...
- Page 2 Bill Of Materials Ref. Qty. Description Bracket A (Connects to Backboard) Bracket B (45 Degree Bracket) Bracket C (Light Mount Bracket) LED Lamps (With Wire) Assortment of Zip Ties 8mm x 3.5cm Hex Bolts (Bolt LED Lamps to Bracket C) 8mm x 4.5cm Hex Bolts (Bolt Bracket A to Backboard) 8mm x 6cm Hex Bolts (Bolt Bracket C to Bracket B) 10mm x 2cm Hex Bolt (Bolt Bracket A to Bracket B)
-
Page 3: Safety Instructions
Safety Instructions Check the Goal Light System on a regular ba- IMPORTANT sis to ensure that there are no signs of dete- It is the responsibility of purchaser to ensure that rioration or corrosion, loose hardware, or all installers and players fully comply with the de- damaged parts. -
Page 4: Installation Overview
Installation Overview In order to have safe fun and a long use of your Goal Light, please note and heed the following: 1) Prior to Goal Light assembly, check for power lines within 35 feet of your basketball system. If power lines are within 35 feet of your basketball system do not install the Goal Light System. -
Page 5: Required Tools
Required Tools (2) Crescent Wrenches Socket/Wrench Sizes (2) 8ft ladders Recommended Scissors (To Cut Zip Ties) 14mm 13mm 17mm Patten Pending #62458721... - Page 6 Assembly 1) Assemble Bracket Start by removing 1 H-bracket bolt from either far side of the top of your backboard as seen below: Now install one bolt for your Bracket (A) using [1] 8mm x 4.5cm hex bolts (G), [2] 8mm Flat Washers (J), [1] 8mm Lock Washer (K), and [1] 8mm Hex Nut (L).
- Page 7 Continue to remove the other 3 H-Bracket bolts and slide the Bracket (A) to line up with the three holes in the backboard. Using [3] 8mm x 4.5cm hex bolts (G), [6] 8mm Flat Washers (J), [3] 8mm Lock Washers (K), and [3] 8mm Hex Nuts (L) secure the bracket to the backboard. Once all 4 bolts are in place tighten down securely.
- Page 8 Using the provided Zip Ties (E) secure the electrical wire to the Bracket (C) and Bracket (B). 3) Assemble Bracket (B) to Bracket (A) Slide the Bracket (B) into the top of the Bracket (A) and use [1] 10mm x 2cm Hex Bolt (I) to secure them together.
- Page 9 5) Check Lights WARNING— Be very carful not to touch the light housing with your hands. It will get very hot! Double check to make sure your LED Lamps (D) are working properly. Using an outdoor rated extension cord plug your Goal Light into a power source. Ensure that the LED Lamps (D) light up.
- Page 10 7) Maintenance Like any piece of hardware, proper maintenance is required. Several factors such as the environment, organic materials, herbicides, pesticides, excessive use or misuse can eventually cause the Goal Light to require maintenance. Failure to do so could result in system failure, property damage, or even personal injury. 1) All organic materials should be kept away from the Goal Light system at all times.
- Page 11 Hoops Inc. Goal Light Limited 90 Day Warranty Hoops Goal Light LED basketball light systems are warranted to the original purchaser to be free from defects in ma- terial or workmanship for 90 days of ownership by the original retail purchaser. The word “defects” is defined as imper- fections that impair the use of the product.
