- Page 1 S150 AC DC Smart Charger (1 × 50W) Instruction Manual Bedienungsanleitung Manuel d’utilisation Manuale di Istruzioni...
- Page 2 NOTICE All instructions, warranties and other collateral documents are subject to change at the sole discretion of Horizon Hobby, LLC. For up-to-date product literature, visit horizonhobby.com or towerhobbies.com and click on the support or resources tab for this product. Meaning of Special Language The following terms are used throughout the product literature to indicate various levels of potential harm when operating this product: WARNING: Procedures, which if not properly followed, create the probability...
- Page 3 WARNING: Read the ENTIRE instruction manual to become familiar with the features of the product before operating. Failure to operate the product correctly can result in damage to the product, personal property and cause serious injury. This is a sophisticated hobby product. It must be operated with caution and common sense and requires some basic mechanical ability.
-
Page 4: Table Of Contents
Table of Contents S150 Warnings and Safety Tips ..............4 General Charging Warnings ................5 Specifications ....................6 Layout ......................8 Operating the Charger ..................9 Optional Parts ....................11 Limited Warranty ..................11 Warranty and Service Contact Information ...........15 Compliance Information for the European Union ...........16 S150 Warnings and Safety Tips WARNING: Failure to exercise caution while using this product and comply with the following warnings could result in product malfunction,... -
Page 5: General Charging Warnings
General Charging Warnings • NEVER LEAVE CHARGING BATTERIES UNATTENDED. • NEVER CHARGE BATTERIES OVERNIGHT. • Never attempt to charge dead, damaged or wet battery packs. • Never attempt to charge a battery pack containing different types of batteries. • Never allow children under 14 years of age to charge battery packs. •... -
Page 6: Specifications
WARNING: Never leave charger unattended, exceed maximum charge rate, charge with non-approved batteries or charge batteries in the wrong mode. Failure to comply may result in excessive heat, fire and serious injury. WARNING: Always check charging parameters before initiating the charge process. - Page 7 Charger AC to DC Power Supply 5.5mm x 2.5mm Barrel IEC-320-C5 AC input, Input Connector Connector (center pin Standard IEC-320-C5 positive) AC power cord included 5.5mm x 2.5mm Barrel Output Connector (EC3 compatible) Connector (center pin ™ ™ positive) Input Voltage 19–24V DC 110–120V AC Max.
-
Page 8: Layout
Layout A Update Port G Selection Button B Cooling Fan H Battery Balance Connector DC Power Input IC3 Battery Port D Battery Type DC Power Connector Charge Status AC to DC Power Supply Charge Current AC Power Input Cable LiHV 5.0A LiPo 3.0A... -
Page 9: Operating The Charger
Operating the Charger Charging requires the selection of two settings; battery type and charge current. SMART batteries will automatically load the correct battery type and will only allow current adjustments. 1. Connect the battery power connector and balance connector to the charger. Lithium battery balance connectors must be inserted with the connector shifted toward the center of the charger, as shown. - Page 10 LED Indicator • Battery type indicator is illuminated white. Power On/ Battery • Battery capacity indicator is off. Not Connected • Current indicator is illuminated white. • Corresponding battery type indicator is illuminated white. Battery Connected/ • Battery capacity indicator illuminates solid green to Charging Not Started indicate battery capacity before charge.
-
Page 11: Optional Parts
Optional Parts Part # Description SPMXCA100 Spektrum SMART USB Updater Cable SPMXCA507 IC3 Battery to IC5 Device SPMXCA310 IC3 Battery to JST Device SPMXCA301 IC3 Device and Battery Connectors Limited Warranty What this Warranty Covers – Horizon Hobby, LLC, (Horizon) warrants to the original purchaser that the product purchased (the “Product”) will be free from defects in materials and workmanship for a period of 1 year from the date of purchase. - Page 12 PURPOSE. THE PURCHASER ACKNOWLEDGES THAT THEY ALONE HAVE DETERMINED THAT THE PRODUCT WILL SUITABLY MEET THE REQUIREMENTS OF THE PURCHASER’S INTENDED USE. Purchaser’s Remedy – Horizon’s sole obligation and purchaser’s sole and exclusive remedy shall be that Horizon will, at its option, either (i) service, or (ii) replace, any Product determined by Horizon to be defective.
- Page 13 WARRANTY SERVICES Questions, Assistance, and Services – Your local hobby store and/or place of purchase cannot provide warranty support or service. Once assembly, setup or use of the Product has been started, you must contact your local distributor or Horizon directly. This will enable Horizon to better answer your questions and service you in the event that you may need any assistance.
- Page 14 NOTICE: Do not ship Li-Po batteries to Horizon. If you have any issue with a Li-Po battery, please contact the appropriate Horizon Product Support office. Warranty Requirements – For Warranty consideration, you must include your original sales receipt verifying the proof-of-purchase date. Provided warranty conditions have been met, your Product will be serviced or replaced free of charge.
-
Page 15: Warranty And Service Contact Information
Warranty and Service Contact Information United States of America Contact Horizon Hobby Address Information Horizon Service Center servicecenter.horizonhobby.com/ (Repairs and Repair Requests) RequestForm/ productsupport@ 2904 Research Rd Horizon Product Support horizonhobby.com Champaign, Illinois, (Product Technical Assistance) 877-504-0233 61822 USA websales@horizonhobby.com Sales 800-338-4639 Contact... -
Page 16: Compliance Information For The European Union
FCC Information Supplier’s Declaration of Conformity Spektrum S150 AC Mini Smart Charger SPMXC1070 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. - Page 17 • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. Horizon Hobby, LLC 2904 Research Rd., Champaign, IL 61822...
- Page 18 Compliance Information for the European Union EU Compliance Statement: Horizon Hobby, LLC hereby declares that this product is in compliance with the essential requirements and other relevant provisions of the EMC and LVD Directive. A copy of the EU Declaration of Conformity is available online at: http://www.horizonhobby.com/content/support-render-compliance.
- Page 19 © 2020 Horizon Hobby, LLC. IC3, EC3 and the Smart Technology logo are trademarks of Horizon Hobby, LLC. The Spektrum trademark is used with permission of Bachmann Industries, Inc. All other trademarks, service marks and logos are property of their respective owners. Patents Pending Created 12/19 SPMXC1070, SPMXC1070I...
