6.10.2. Module RF Receive Sensitivity

The following table shows the module's conducted receiving sensitivity, it is tested under static condition.
Table 47: Conducted RF receive sensitivity
Frequency
GSM850,EGSM900
DCS1800,PCS1900

6.10.3. Module Operating Frequencies

The following table shows the module's operating frequency range; it is followed by the 3GPP TS 05.05
technical specification requirement.
Table 48: Operating frequencies
Frequency
GSM850
EGSM900
DCS1800
PCS1900
SIM800L(MT6261)_Hardware Design_V1.01
22
20
18
16
14
12
10
8
6
4
2
0
Receive sensitivity（Typical）
< -108dBm
< -108dBm
Receive
869 ～ 894MHz
925 ～ 960MHz
1805 ～ 1880MHz
1930 ～ 1990MHz
