Summary of Contents for Harris XL-185P
-
Page 1: Table Of Contents
Pairing a G1 SCBA and Harris XL-185P | XL-200P Radio Using the G1 SCBA and Harris XL-185P | XL-200P Radio Clearing Radio Pair Info from the G1 SCBA Clearing SCBA Pairing Info from the Harris XL-185P | XL-200P Radio Troubleshooting... -
Page 2: Harris Xl-185P | Xl-200P Configuration Settings
Harris Harris XL-185P | XL-200P Configuration Settings Step 1. Obtain Radio Personality Manager 2 (RPM2) software from the Harris Technical Assistance Center (TAC): 1-800-528-7711 (Opt.3) PSPC_TAC@harris.com Step 2. Open the Harris RPM2 Software Step 3. Connect the programming cable to the portable radio: Hook the pin side of the connector in the radio’s notch. - Page 3 Check “PTT” Select “Accessory Only” If the Harris radio is equipped with a Harris FSM Speaker, the Rx audio will always be routed to BOTH the Harris FSM speaker AND the MSA G1 lapel speaker. If desired, the firefighter can turn off the G1 Lapel Speaker (in order to only play audio through the FSM speaker) by depressing the G1 Lapel Speaker’s button for 3 seconds.
- Page 4 G1 SCBA Radio Pairing Guide | Harris Step 13. Back under the “Options” Section: Scroll down to, and: • Select “Bluetooth Settings” o Enable Bluetooth o Disable MITM Protection Soft OPTION: Program a button or softkey to turn Bluetooth ON/OFF.
-
Page 5: Creating A G1 Scba Configuration Tag (For Bluetooth Pair Save Preferences)
G1 SCBA Radio Pairing Guide | Harris G1 Bluetooth Creating a G1 SCBA Configuration Tag (for Bluetooth Pair Save Preferences) Settings Tag The purpose of this section is to: (1) enable the Bluetooth radio on the G1 SCBA and (2) to set Bluetooth Pair Save behavior based on the department’s preference. -
Page 6: Creating A Harris Xl-185P | Xl-200P Radio Pairing Tag
G1 SCBA Radio Pairing Guide | Harris Radio ID Creating a Harris XL-185P | XL-200P Radio Pairing Tag Pair Tag To pair the radio to the G1 SCBA, a “Bluetooth Audio Pairing Tag” needs created in the A2 Software. Once the Pairing Tag is created, it can be applied to the SCBA, which “programs” the SCBA to connect to that specific radio. - Page 7 Step 7. Make the Radio Bluetooth Discoverable: Note: Every time you power on the Harris XL-185P | XL-200P, it starts up with Discoverability set to OFF. Follow this procedure to turn it ON. If you left the Bluetooth Utility Menu, navigate back to it using the procedure found on Page 6, Step 6.
-
Page 8: Pairing A G1 Scba And Harris Xl-185P | Xl-200P Radio
Pairing a G1 SCBA and Harris XL-185P | XL-200P Radio Radio Ensure the Harris Radio is programmed correctly to connect with the G1 SCBA. Necessary and recommended settings are listed in the “Harris Configuration Settings” page. Consult with your Radio Technician. - Page 9 G1 regulator & breathes. If you encouter difficulty pairing the radio: • Clear the pair information stored on the radio, as described in the “Clearing SCBA Pairing Info from the Harris XL- 185P | XL-200P Radio” section in the pages hereafter. •...
-
Page 10: Using The G1 Scba And Harris Xl-185P | Xl-200P Radio
If the regulator is shut off, the G1 SCBA will not remain connected to the radio, and the radio is available for non-Bluetooth use. The G1 SCBA will automatically re-connect to the Harris radio when breathing on the G1 regulator. -
Page 11: Clearing Radio Pair Info From The G1 Scba
G1 Pairing Removal Method 2 – Pair New Radio Step 1. Pair a different Bluetooth Harris Radio with the G1 SCBA using the new radio’s Bluetooth Audio Pairing Tag, as described in the “Pairing a G1 SCBA and Harris XL-185P | XL-200P Radio” section. -
Page 12: Clearing Scba Pairing Info From The Harris Xl-185P | Xl-200P Radio
G1 SCBA Radio Pairing Guide | Harris Clearing Radio Clearing SCBA Pairing Info from the Harris XL-185P | XL-200P Radio Pair Step 1. Press the button in the Center of the arrow pad to enter the radio’s settings menu sets. -
Page 13: Troubleshooting
Bluetooth. connected Green = enabled/connected Radio is a not a G1 is compatible with To use G1 Bluetooth Harris XL-185P | XL- Harris XL-185P | XL-200P audio, pair with a Harris 200P Bluetooth Radio Bluetooth Radios. XL-185P | XL-200P...
