XDesignerPlus Ver2.0 외부 장치 접속 매뉴얼
SEWHA CNM CO., LTD
SI Digital Indicator Series
Support version
XDesignerPlus
CONTENTS
Thank you for using TOP series of M2I corporation.
Please read this manual carefully to know connection methods and
procedures of "TOP to External device".
1.
A section for showing connectable external devices, serial signal
types, connection configurations. Refer this section to select the
right system configuration.
2.
A section for selecting a Top model and the external device.
3.
A section for explaining examples to connect communications of
TOP to External Device.
Select the correct example in your case according to "1. System
configuration"
4.
A section for Communication setting.
The setting should be the same with the external device.
5.
A section for cable to connect to external device.
Select a suitable cable diagram for your system.
6.
Usable address
A section for usable address to communicate with external
device.
OS
V3.0 and over
2.1.0.0 and over
Page 2
Page 3
Page 4
Page 8
Page 11
Page 13
1 / 22
Advertisement
Related Manuals for SEWHA CNM SI Digital Indicator Series
Summary of Contents for SEWHA CNM SI Digital Indicator Series
-
Page 1: Table Of Contents
SEWHA CNM CO., LTD SI Digital Indicator Series Support version V3.0 and over XDesignerPlus 2.1.0.0 and over CONTENTS Thank you for using TOP series of M2I corporation. Please read this manual carefully to know connection methods and procedures of “TOP to External device”. -
Page 2: System Configuration
1. System configuration System configurations of TOP and “SEWHA CNM – SI Digital Indicator Series” Indicator Model Link I/F Com type Setting system Cable RS232C I/F 3.1 setting ex 1 5.1 Cable diagram 1 RS–232C (D-sub 9 pin) ( Page 4 ) -
Page 3: Selection Of Top, External Device
Select vendor of the external device which is communicated with the TOP. Device Select “SEWHA CNM”. Select a model name of the external device which is communicated with the TOP. Select “SI Digital Indicator Series”. XDesignerPlus Ver2.0 외부 장치 접속 매뉴얼 3 / 22... -
Page 4: Example Of System Setting
Set the Menu of “F-FUNCTION” as below by the keys of front panel and reboot external device after setting. If you need details of setting, please read manual of external device. (1) Communication/Extended mode “SI Digital Indicator Series” of are both available to use. This section explains about setting of communication mode. - Page 5 Set the Menu of “F-FUNCTION” as below by the keys of front panel and reboot external device after setting. If you need details of setting, please read manual of external device. (1) Communication/Extended mode “SI Digital Indicator Series” of are both available to use. This section explains about setting of communication mode.
- Page 6 Set the Menu of “F-FUNCTION” as below by the keys of front panel and reboot external device after setting. If you need details of setting, please read manual of external device. (1) Communication/Extended mode “SI Digital Indicator Series” of are both available to use. This section explains about setting of communication mode.
- Page 7 Set the Menu of “F-FUNCTION” as below by the keys of front panel and reboot external device after setting. If you need details of setting, please read manual of external device. (1) Communication/Extended mode “SI Digital Indicator Series” of are both available to use. This section explains about setting of communication mode.
-
Page 8: Communication Setting
Set [project property] of XDesignerPlus as below and download it to TOP. ■ [Project > Project property > project > TOP Setting > TOP’s Name] Set communication interface of TOP.. ■ External device setup Set [PLC Comm. Info] of SI Digital Indicator Series. ■ Setting communication Interface Item Description Serial Baud Rate Setup [communications Baud rate] of PLC connected with COM2/1 port. - Page 9 4.2 Setting TOP Main Menu [In to the Main Menu] While the power of TOP is turned on and the buzzer beeps once, Touch the screen’s upper part under the TOP logo on the front sheet. Note: When turn on the power while pressing the touch, it does not convert into the Menu mode. When the buzzer sound is unable to confirm because of the noise surroundings, the power of touch shall be allowed while continuously press and off on the lower part of the logo.
- Page 10 4.3 Communication Diagnosis ■ TOP – Check interface setting of external device and TOP - Touch the top of screen to go into the Main Menu after reset the power of TOP. - Check [Comm. Setup] whether it is the same of external device’s setup or not. ■...
-
Page 11: Cable Diagram
5. Cable diagram This Chapter introduces cable wiring guidance for communication between TOP and PLC concerned. (The cable diagrams in this section may differ from the recommendations of SEWHA CNM) 5.1 Cable Diagram Table 1 ■ 1 : 1 Connection... - Page 12 5.1 Cable Diagram Table2 ■ 1 : 1 Connection (A) XTOP COM 2 Port(9Pin) XTOP COM2 “SI Digital Indicator Series” Cable Wiring Pin Assignment *1 Signal Pin No. Signal Pin Assignment *1 Serial I/F Front View of, Terminal Block (3 pin) D-SUB 9 Pin (male) *.1)
- Page 13 5.3 Cable Diagram Table3 ■ 1 : 1 Connection (A) XTOP COM 2 Port(9pin) XTOP COM2 “SI Digital Indicator Series” Cable Wiring Pin Assignment *1 Signal Pin No. Signal Pin Assignment *1 T– R– Serial I/F Front View of ,...
- Page 14 6. Available Address ■ The available address of device are as below. Maybe the device(address) range could be different according to product. TOP Series are capable of supporting maximum address range which is available in external Device. ■ SI 580 Device Bit Address Word Address...
- Page 15 ■ SI 480 Device Bit Address Word Address Command Address Remarks Current Weight ––––– CWT:W ––––– State 1 CWT:S1.00 – CWT:S1.02 CWT:S1 ––––– *1), 3) State 2 CWT:S2.00 – CWT:S2.01 CWT:S2 ––––– *1), 4) Total Count of Weighing ––––– GRD:C –––––...
- Page 16 ■ SI 4500 Device Bit Address Word Address Command Address Remarks Current Weight ––––– CWT:W ––––– State 1 CWT:S1.00 – CWT:S1.02 CWT:S1 ––––– *1), 3) State 2 CWT:S2.00 – CWT:S2.01 CWT:S2 ––––– *1), 4) Input State WRS:I.00 – WRS:I.03 WRS:I –––––...
- Page 17 ■ SI 4410 Device Bit Address Word Address Command Address Remarks Current Weight ––––– CWT:W ––––– State 1 CWT:S1.00 – CWT:S1.02 CWT:S1 ––––– *1), 3) State 2 CWT:S2.00 – CWT:S2.01 CWT:S2 ––––– *1), 4) Total Count of Weighing ––––– GRD:C –––––...
- Page 18 ■ SI 4400 Device Bit Address Word Address Command Address Remarks Current Weight ––––– CWT:W ––––– State 1 CWT:S1.00 – CWT:S1.02 CWT:S1 ––––– *1), 3) State 2 CWT:S2.00 – CWT:S2.01 CWT:S2 ––––– *1), 4) Total Count of Weighing ––––– GRD:C –––––...
- Page 19 ■ SI 4300 Device Bit Address Word Address Command Address Remarks Current Weight ––––– CWT:W ––––– State 1 CWT:S1.00 – CWT:S1.02 CWT:S1 ––––– *1), 3) State 2 CWT:S2.00 – CWT:S2.01 CWT:S2 ––––– *1), 4) Total Count of Weighing ––––– GRD:C –––––...
- Page 20 ■ SI 4200 Device Bit Address Word Address Command Address Remarks Current Weigh ––––– CWT:W ––––– State 1 CWT:S1.00 – CWT:S1.02 CWT:S1 ––––– *1), 3) State 2 CWT:S2.00 – CWT:S2.01 CWT:S2 ––––– *1), 4) Total Count of Weighing ––––– GRD:C –––––...
- Page 21 ■ SI 4100 Device Bit Address Word Address Command Remarks Address Current Weight ––––– CWT:W ––––– State 1 CWT:S1.00 – CWT:S1.02 CWT:S1 ––––– *1), 3) State 2 CWT:S2.00 – CWT:S2.01 CWT:S2 ––––– *1), 4) Total Count of Weighing ––––– GRD:C –––––...
- Page 22 ■ SI 4000 Device Bit Address Word Address Command Address Remarks Current Weight ––––– CWT:W ––––– State 1 CWT:S1.00 – CWT:S1.02 CWT:S1 ––––– *1), 3) State 2 CWT:S2.00 – CWT:S2.01 CWT:S2 ––––– *1), 4) Total Count of Weighing ––––– GRD:C –––––...
