Code 3 C3900 Installation And Operation Instructions

Introduction:
The C3900 compact, slim profile speaker uses a (patent
pending) dual speaker driver design to produce all the familiar
siren tones (WAIL and YELP), as well as low frequency tones
with the Code 3 Banshee siren. It is designed to be easily
installed using both universal and vehicle specific mounting
brackets and comes with a 5-year warranty. It meets SAE
J1849 and California Title 13 requirements when used with
Code 3 sirens. Code 3 speakers are certified with Code 3
Sirens as a system and different siren Manufactures could
cause component damage or reduce sound pressure.
Contents:

Specifications.........................................................01

Installation and Mounting..................................02-03
Warranty.................................................................04
Specifications*:
*specification as for a single C3900 speaker
Power:
Impedance:
Weight:
Dimensions:
IMPORTANT! Read all instructions before installing and using. Installer: This manual must be delivered to the end user.
WARNING!
Failure to install or use this product according to manufacturers recommendations may result in property damage, serious injury,
and/or death to those you are seeking to protect!
Do not install and/or operate this safety product unless you have read and understand the safety information con-
tained in this manual.
1. Proper installation combined with operator training in the use, care, and maintenance of emergency warning devices are essential to
ensure the safety of emergency personnel and the public.
2. Emergency warning devices often require high electrical voltages and/or currents. Exercise caution when working with live electrical
connections.
3. This product must be properly grounded. Inadequate grounding and/or shorting of electrical connections can cause high current arcing,
which can cause personal injury and/or severe vehicle damage, including fire.
4. Proper placement and installation is vital to the performance of this warning device. Install this product so that output performance of the
system is maximized and the controls are placed within convenient reach of the operator so that s/he can operate the system without losing
eye contact with the roadway.
5. It is the responsibility of the vehicle operator to ensure daily that all features of this product work correctly. In use, the vehicle operator
should ensure the projection of the warning signal is not blocked by vehicle components (i.e., open trunks or compartment doors), people,
vehicles or other obstructions.
6. The use of this or any other warning device does not ensure all drivers can or will observe or react to an emergency warning signal. Never
take the right-of-way for granted. It is your responsibility to be sure you can proceed safely before entering an intersection, drive against
traffic, respond at a high rate of speed, or walk on or around traffic lanes.
7. This equipment is intended for use by authorized personnel only. The user is responsible for understanding and obeying all laws regarding
emergency warning devices. Therefore, the user should check all applicable city, state, and federal laws and regulations. The manufacturer
assumes no liability for any loss resulting from the use of this warning device.
920-0669-00 Rev. B
w/o Bracket w/ Bracket
100 Watt
11 Ohm
2.8 lbs 4.5 lbs
1.61 in(L) 2.78 in(L)
5.86 in(W) 8.28 in(W)
5.96 in(H) 8.19 in(H)
Installation and Operation Instructions
C3900 SPEAKER MOUNT - 2015+ DODGE CHARGER
FOR SINGLE AND DUAL SPEAKERS
WARNING!
Sirens produce loud sounds that may damage hearing
• Wear hearing protection when testing
• Use siren only for emergency response
• Roll up windows when siren is operating
• Avoid exposure to the siren sound outside of vehicle
Page 1 of 4
