- Page 1 Alliance_N2ROU User Manual SOLiD, Inc. 10,9th Floor, SOLiD Space220 Pangyoyeok-ro, Bundang-gu, Seongnam-si, Gyeonggi-do, Korea 393-400 Tel : +82-31-627-6290 Fax : +82-31-627-6209 Confidential & Proprietary 1/17...
- Page 2 Original Technical Support SOLiD serial numbers must be available to authorize technical support and/or to establish a return authorization for defective units. The serial numbers are located on the back of the unit, as well as on the box in which they were delivered. Additional support information may be obtained by accessing the SOLiD Tehcnology, Inc.
-
Page 3: Table Of Contents
Contents Section1 Safety & Certification Notice ..............4 Section2 System Overview ..................8 2.1 Purpose ......................9 2.2 Alliance_N2ROU ................... 9 2.3 Dimension ....................10 Section3 System Installation ................11 3.1 N2ROU Installation ..................11 3.1.1 N2ROU Enclosure installation ............. 11 3.1.2... -
Page 4: Safety & Certification Notice
Section1 Safety & Certification Notice Confidential & Proprietary 4/17... - Page 5 This could cause fires, electric shock or other injuries. - Any DAS system or Fiber BDA will generate radio (RF) signals and continuously emit RF energy. Avoid prolonged exposure to the antennas. SOLiD recommends maintaining a 3-foot minimum clearance from the antenna while the system is operating.
- Page 6 - Certification FCC: This equipment complies with the applicable sections of Title 47 CFR Parts 15,22,24,27 and 90(Class B) UL/CUL: This equipment complies with UL and CUL 1950-1 Standard for safety for information technology equipment,including electrical business equipment ...
- Page 7 - Access can only be gained by SERVICE PERSONS or by USERS who have been instructed about the reasons for the restrictions applied to the location and about any precautions that shall be taken; and - Access is through the use of a TOOL or lock and key, or other means of security, and is on trolled by the authority responsible for the location.
-
Page 8: Section2
Section2 System Overview 2.1 Purpose 2.2 SMDR-NH124 Confidential & Proprietary 8/17... -
Page 9: Purpose
2.1 Purpose Alliance_N2ROU is a coverage system for in-building services delivering voice and data in high quality and for seamlessly. As a distributed antenna system, it provides analog and digital phone systems that are served in multiple bands through one antenna. -
Page 10: Dimension
2.3 Dimension Figure 3.1 – N2ROU Outer Look ROU is designed in a cabinet, and provides the following functions and features. Item Spec. Remark Size(mm) 571 x 450 x260, Including Bracket Weight 39 Kg Full Load Power consumption 260 W -10 to +50°C Ambient Temperature Operating Temperature... -
Page 11: Section3
Section3 System Installation 3.1 N2ROU Installation 3.1.1 N2ROU Enclosure installation N2ROU is designed to be water- and dirt-proof. The unit has the structure of One-Body enclosure. It satisfies water-proof and quake-proof standards equivalent of NEMA4. ROU can be mounted into either of on a Wall. Basically, N2ROU has both of a Wall Mount Bracket. -
Page 12: N2Rou Power Cabling
Optional Part R-OPTIC Optical Cable Assembly Connector Basically, the common part of N2ROU should have an enclosure and it is equipped with RCPU to inquire and control state of each module, R_OPTIC to make both of electronic-optical and optical-electronic conversions, RPSU to supply power for N2ROU and a Multi-Plexer to help share multiple TX/RX signals through one antenna. -
Page 13: Optical Cabling
3.1.3 Optical Cabling N2ROU makes optical-electronic conversion of TX signals from upper ODU and OEU and makes electronic- optical conversion of RX signals. N2ROU has one optical module in it. As WDM is installed in the R_OPTIC module, two pieces of wavelength (TX:1310nm, RX:1550nm) can be sent/received with one optical core at the same time. -
Page 14: Coaxial Cable And Antenna Connection
Take off the GND terminal port from enclosure and connect to ground cable, then fix it the position of enclosure again The opposite end of the ground cable should connect to the communication GND of building 3.1.5 Coaxial cable and Antenna Connection The coaxial cables which are connected to antenna distribued network connect to antenna port of N2ROU. -
Page 15: N2Rdu Specifications Per Band
3.1.7 N2RDU Specifications Per band Frequency range Bandwidth Output Power Unit naming (TX/RX) (dBm) TX(MHz) RX(MHz) 699~716(B1) 700LTEF_FN 39 / 17,21 729~768 777~798(B2) 800IDEN+850Cell 32 / 32 862~894 817~849 1900PCS 65 / 65 1930~1995 1850~1915 AWS13 70 / 70 2110~2180 1710~1780 2300WCS 10 / 10... - Page 16 <FCC Warning Statements> FCC Part 15.105 statement This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
- Page 17 RSS-GEN, Sec. 7.1.2 – (detachable antennas) This radio transmitter (identify the device by certification number, or model number if Category II)has been approved by Industry Canada to operate with the antenna types listed below with the maximum permissible gain and required antenna impedance for each antenna type indicated.
