- Page 1 HERCULES (Alliance 5W Remote Unit) User Manual SOLiD, Inc 10,9th Floor, SOLiD Space220 Pangyoyeok-ro, Bundang-gu, Seongnam-si, Gyeonggi-do, Korea 393-400 Tel : +82-31-627-6290 Fax : +82-31-627-6209 Confidential & Proprietary 1/39...
-
Page 2: Revision History
The serial numbers are located on the back of the unit, as well as on the box in which they were delivered. Additional support information may be obtained by accessing the SOLiD Tehcnology, Inc. website at www.solid.co.kr... -
Page 3: Table Of Contents
2.1 Purpose ......................10 2.2 HERCULES ...................... 11 Section3 Functional Description ................12 3.1 General ......................13 3.2 Component of HERCULES Remote Unit ............. 14 3.3 Dimension ..................... 16 Section4 System Installation ................... 17 4.1 Remote Unit Installation ................. 19 4.1.1 Remote Unit Enclosure installation .............. - Page 4 Contents of Figure Figure 3.1 – Remote Unit Block Diagram ............13 Figure 3.2 – Inside of Remote Unit ..............14 Figure 3.3 – Remote Unit Dimension ..............16 Figure 4.1 – Exterior of Remote Unit ..............19 Figure 4.2 – Dimension used to install REMOTE UNIT on the WALL ......20 Figure 4.3 –...
-
Page 5: Safety & Certification Notice
Section1 Safety & Certification Notice Confidential & Proprietary 5/39... - Page 6 - Any DAS system or Fiber BDA will generate radio (RF) signals and continuously emit RF energy. Avoid prolonged exposure to the antennas. SOLiD recommends maintaining a 300cm minimum clearance from the antenna while the system is operating. - Do not operate this unit on or close to flammable materials, as the unit may reach high temperatures due to power dissipation.
- Page 7 - A readyily accessible disconnect device shall be incorporated external to the equipment. - This power of this system shall be supplied through wiring installed in a normal building. If powered directly from the mains distribution system, it shall be used additional protection, such as overvoltage protection device - Only 50 ohm rated antennas, cables and passive equipment shall be used with this remote.
- Page 8 - Access is through the use of a TOOL or lock and key, or other means of security, and is on trolled by the authority responsible for the location. - Maximum antenna gain for downlink antenna after accounting for any cable losses should be less than 2 dBi.
-
Page 9: Section2
Section2 Introduction 2.1 Purpose 2.2 HERCULES Confidential & Proprietary 9/39... -
Page 10: Purpose
2.1 Purpose HERCULES is a coverage system for in-building services delivering voice and data in high quality and for seamlessly. As a distributed antenna system, it provides analog and digital phone systems that are served in multiple bands through one antenna. -
Page 11: Hercules
2.2 HERCULES Hercules is one of series of Alliance DAS and has 5W composite output power every band. RDU that is integrated on package with Duplexer, Power amplifier and RF unit can be mounted up to 6 in the enclosure. -
Page 12: Section3
Section3 Functional Description 3.1 General 3.2 Compoent of HERCULES Remote Unit 3.3 Dimension Confidential & Proprietary 12/39... -
Page 13: General
3.1 General The following figure shows the block diagram of HERCULES Remote Unit. Figure 3.1 – Remote Unit Block Diagram There are many components; R-Optic : Remote Optical Unit RCPU : Remote Central Processor Unit RPSU(AC) : Remote AC Power Supply Unit(When using the AC input power) ... -
Page 14: Component Of Hercules Remote Unit
3.2 Component of HERCULES Remote Unit The following figure shows internal configuration of Remoe Unit with fully RF equipped. Figure 3.2 – Inside of Remote Unit Remote Unit receives TX optical signals from Head-End and converts them into RF signals. The converted RF signals are amplified through High Power Amp in a corresponding RDU, combined with Multiplexer module and then radiated to the antenna port. - Page 15 The following table describes components on Remote Unit Unit Description Remote Drive Unit Filter and amplify TX signals RDU+BPF x6 Filter and amplify RX signals Remove other signals through BPF Remote AC Power Supply Unit RPSU(AC) Input power: 120 VAC +/- 10% Output power: +29 VDC Remote DC Power Supply Unit RPSU(DC)
-
Page 16: Dimension
3.3 Dimension Figure 3.3 – Remote Unit Dimension ITEM SPECIFICATION REMARK Size(Width, Height, Depth) 320 x 1165 x 260mm Including Bracket Weight 62kg / 137lb Fully loaded Power Consumption 510W Fully loaded Operating Temperature -25 to +55°C / -13 to 131°F Ambient Temperature Operating Humidity 0 to 90%, non-condensing... -
Page 17: Section4
Section4 System Installation 5.1 Remote Unit Installation This chapter describes how to install each unit and optical cables, along with power cabling method. In detail, the chapter describes how to install shelves or enclosures of each unit, Power Cabling method and Optic Cabling and RF Interface. - Page 18 refer OPTIC SC/APC Cable (1EA) 4.1.5 For more M6 Screw (1EA) No.2 Screw driver (+) ○ Ground details, Lug (1EA) ○ Connection refer Crimping Tool Max. AWG #6 Cable 4.1.4 2 EA is Antennal required RF Cable (1 or 2EA) Spanner (33mm) Connection in case of...
-
Page 19: Remote Unit Installation
4.1 Remote Unit Installation 4.1.1 Remote Unit Enclosure installation Remote Unit is designed to be water- and dirt-proof. The unit has the structure of one-Body enclosure. It satisfies water-proof and quake-proof standards equivalent of NEMA4(IP66). Basically Remote Unit is attached with wall mountable bracket. Remote Unit can be mounted into either of wall or on a pole. Figure 4.1 –... -
Page 20: Figure 4.2 – Dimension Used To Install Remote Unit On The Wall
Figure 4.2 – Dimension used to install REMOTE UNIT on the WALL Confidential & Proprietary 20/39... -
Page 21: Figure 4.3 – Procedures Of Installation
Remote Unit Wall Mount Installation Remote Unit’s installation bracket is attached on Enclosure when is delivered. It doesn’t need to remove bracket to install enclosure. simply after installing 4 of M12 mounting bolts, secure 4 mounting bolts tightly First, install 2 of M12 mounting bolts roughly half way on the enclosure and install enclosure over the bolts and secure tightly. - Page 22 Remote Unit Components Remote Unit has the following components: Unit Description Remark Enclosure Including Wall mounting bracket RCPU R_OPTIC With SC/ACP adaptor(only Remote Unit) 1EA,optional RPSU AC 120V or DC-48V Power Cable MS Connector with 4 hole MRDU-850CEL MRDU-1900PCS MRDU MRDU-700LTE ANT1 Common Part...
-
Page 23: How To Expand Add On Rou At The Remote Unit
4.1.2 How to expand ADD ON ROU at the Remote Unit Remote Unit can expand ARU up to 1. The three item is needed for connection between Remote Unit and ADD ON ROU. ADD ON ROU’s components additively have 3 item except for enclosure like below Accessories Description Specification... - Page 24 For expanding ADD ON ROU at the Remote Unit within the proper cable length provided. The cables between Remote Unit and ADD ON ROU have each 1.5m length. Figure 4.4 – Connection diagram between Remote Unit and ADD ON ROU (AC type) Figure 4.5 –...
-
Page 25: Remote Unit Power Cabling
4.1.3 Remote Unit Power Cabling AC Power Remote Unit supports only AC120V of input power. Provided outside power cable is only one type. The pin discription of AC port is below. You should connect exact polarity of AC. Port outlook MS Connector numbering Name Description... -
Page 26: Remote Unit Ground Cabling
4.1.4 Remote Unit Ground cabling The Grounding terminal is located at the bottom of Remote Unit enclosure fixed by M6 screw. Compression terminal is attached already when is delivered. The recommended thickness of cable is AWG#6 copper grounding wire Figure 4.6 – Location of Ground Terminal The specification of compression terminal is like below Figure 4.7 –... -
Page 27: Figure 4.8 – How To Install Ground Terminal
The required part number is JOCT 16-6 supporting AWG 6. The way to install the grounding cable comply with below procedures Figure 4.8 – How to install Ground Terminal The procedures are Loosen a two M6 screws and then take compression terminal off Insert AWG#6 Grounding Wire into terminal and then compress a terminal using tool Assemble the terminal which made in step “2”... -
Page 28: Optical Cabling
4.1.5 Optical Cabling The Optical Connector is located at the bottom of Remote Unit enclosure fixed. Optical Cable can be connected by using connectors. Figure 4.9 – Location of Optical Connector The specification of compression Optic Connector is like below Figure 4.10 –... -
Page 29: Figure 4.11 – How To Install Optical Cabling
The way to install the Optical cable comply with below procedures The procedures are Figure 4.11 – How to install Optical Cabling Confidential & Proprietary 29/39... -
Page 30: Mounting Of Mrdu
4.1.6 Mounting of MRDU Remote Unit has slots to enable up to six MRDU modules to be mounted in it. You can mount a MRDU into designated slot surely. It is not possible to provide services with a MRDU module alone; you need to connect MRDU cavity duplexer antenna port with CU’s designated port. -
Page 31: Figure 4.13 – How To Mount Mrdu
The Remote Unit holds a maximum of 6 MRDUs. Guide brackets on the bottom of each MRDU slot simplify installation as described below. MRDU installation requires a +No.1 tip size screwdriver. Figure 4.13 – How to mount MRDU Confidential & Proprietary 31/39... -
Page 32: Figure 4.14 – How To Mount Fan Unit
The procedures are Lift the MRDU onto the guide bracket and ensure the MRDU is level left to right Push the MRDU into the corresponding slot in the direction of the heat sink while levelling the MRDU to guide bracket Make sure the MRDU is firmly inserted into the corresponding slot. -
Page 33: Figure 4.15 – How To Mount Fan Unit
Figure 4.15 – How to mount FAN Unit Confidential & Proprietary 33/39... - Page 34 The procedures are Remove dummy bolt attached at FAN Port Connect internal FAN cable to the FAN Port, and connect with the connector located on the top of PSU. Install fan unit to the bottom of 5W remote with aligning heatsink pin to the guided groove. Secure the fan unit by tightening M6 screw located on the left corner.
-
Page 35: Section5
Section5 System Specifications 6.1 Physical Specifications 6.2 RF Performance 6.3 Certification Confidential & Proprietary 35/39... -
Page 36: Physical Specifications
Physical Specifications Parameter Nominal Impedance(input and output) 50 ohm RF Connectors DIN Female (7/16) Mounting Type Wall Mounting (1) RS-232 9-pin Serial Interface connector D-sub, male Fiber connector (1) SC/APC for ODU Power LED TX LED RX LED LED Alarm and Status Indicator LD LED PD LED ALARM LED... -
Page 37: Rf Performance
RF performance MRDU Specifications Per band Downlink Unit naming Description Gain(dB) Bandwidth(MHz) output power(dBm) Frequency range MRDU 850C Single, 869 - 894MHz 862 - 869MHz MRDU 850IC Dual, 869 - 894MHz MRDU 1900P Single, 1930 - 1995MHz MRDU 700LTE Single, 728 - 756MHz MRDU AWS13 Single,... -
Page 38: Certification
Certification Title Standards Remarks Environmental Temperature range -25°C to +55°C/ -13 to 131°F Ambient Temperature Humidity Range 0% ~ 90% Non-condensing Sealing (Remote IEC 60 529 EN 60 529 IP66 Complaint Unit) RSS-GEN, Sec. 7.1.2 – (transmitters) Under Industry Canada regulations, this radio transmitter may only operate using an antenna of a type and maximum (or lesser) gain approved for the transmitter by Industry Canada. - Page 39 RF Radiation Exposure This equipment complies with RF radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 300 cm between the radiator and your body. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
