Bluedri BD AXIAL-25 Operation, Safety, Service And Maintenance Manual

Pro axial air mover 1/4 hp
Hide thumbs
Table of Contents

Advertisement

Quick Links

BD AXIAL-25
1/4 HP
Please READ and UNDERSTAND this MANUAL
carefully before using the product in order to REDUCE
the RISK of INJURY. SAVE this manual for instructions.
PRO AXIAL
AIR MOVER
OPERATION
SAFETY
SERVICE
WARRANTY
CONTACT
SPECIFICATIONS
TROUBLESHOOTING
STACKABLE
2 SPEEDS
LOW 3 AMPS
POWERFUL
SEALED MOTOR
25 FOOT
CORD

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BD AXIAL-25 and is the answer not in the manual?

Questions and answers

Related Manuals for Bluedri BD AXIAL-25

Summary of Contents for Bluedri BD AXIAL-25

  • Page 1 PRO AXIAL AIR MOVER BD AXIAL-25 1/4 HP OPERATION SAFETY SERVICE WARRANTY CONTACT SPECIFICATIONS TROUBLESHOOTING STACKABLE 2 SPEEDS LOW 3 AMPS POWERFUL SEALED MOTOR Please READ and UNDERSTAND this MANUAL carefully before using the product in order to REDUCE the RISK of INJURY. SAVE this manual for instructions.

  • Page 2: Table Of Contents

    BLUEDRIPRO.COM Table of Contents Safety GFCI Protection and the On-Board Duplex Outlet Operator Panel Features Introduction BD AXIAL-25 Air Mover Power Requirements Item & Description Specifications Service Limited Warranty Troubleshooting Warranty Registration...

  • Page 3: Safety

    BLUEDRIPRO.COM Safety • Do not operate any fan with a damaged cord or plug. Discard fan or return to an authorized service facility for examination and/or repair. • Never place your face, hands, or other susceptible body parts in the air stream, inlets, or outlet of this device.

  • Page 4: Operator Panel Features

    A tripped G.F.C.I. can be reset only when the unit is connected to a wall outlet pro viding standard voltage. Reset the tripped G.F.C.I. by pressing the “RESET” button. Warning! The total amperage of the BD AXIAL-25 Air Mover plus all other devices plugged into the receptacle must not exceed 12 amps.

  • Page 5: Introduction

    Your new BD AXIAL-25 Air Mover is engineered for maximum performance through innovative design, space efficiency and low amperage draw. The built-in adjustable feet allow the BD AXIAL-25 to be used at a level horizontal angle or to be positioned at a downward 6 degree angle for more concentrated air-flow.

  • Page 6: Item Description

    BLUEDRIPRO.COM ITEM DESCRIPTION Screw Outlet Grill Capacitor Plate for Cord Connector Power Cord Fan Housing Motor Switch Control Panel Over Current Switch GFCI Hour Meter Inlet Grill Blade Cover Blade Rubber Rubber Cord Connector...

  • Page 7: Specifications

    BLUEDRIPRO.COM SPECIFICATIONS Motor 1/4 HP Amps 3 AMPS Speeds 2 Certification C-ETL-US Stackable Yes Voltage 115V Cycle 60Hz Wheel Speed (RPM) L 1650 / H 1750 Attached Cord 25’ (FT) 14 AWG Service In order to receive service or replacement parts under warranty, you must: A.

  • Page 8: Warranty Registration

    BLUEDRIPRO.COM Thank you for your purchase. Warranty Registration ONLINE Please fill out and submit your warranty form at: www.bluedripro.com/register BY MAIL Please complete, mail or fax your product registration card. For multiple units, please list serial numbers on a seperate sheet. This warranty card and your bill of sale must be presented for warranty service.
  • Page 9 BLUEDRIPRO.COM 550 S Ayon Ave Azusa, CA 91702 844-240-0444 Email: info@bluedripro.com Website: www.bluedripro.com SENDER AFFIX ADRESS STAMP HERE HERE MAIL TO BLUE DRI PRO WARRANTY REGISTRATION 550 South Ayon Ave AZUSA, CA 91702...
