SoundLogic XT RAINBOW Instruction Manual page 3

Description of Parts
Item
1 DC Charging Port
2 LED indicator
3 Power Switch
4 Prev / Volume - /
Next / Volume + /
play/pause / phone
button
5 Built-In Mic
6 Auxiliary port
Function
DC Charging Port – To charge the speaker
Red light stays on during charging, and turns off when
speaker is fully charged.
Bluetooth mode - Blue LED indicator blinks.
To turn ON/OFF the speaker.
Push the button to right will move to the previous track,
and long push to right will decrease the volume.
Push the button to left will move to the next track, and long
push to left will increase the volume.
Play / pause button - Short press will pause or restart the
music.
Phone button - Answer / end call / redial last number
For Hands-Free Conversation
Auxiliary mode playing
Operation
3
