RoughRider Wheelchair Assembly
This video shows assembly instructions for the Whirlwind RoughRider wheelchair.
For more detailed assembly instructions and information on service provision, see
whirlwindwheelchair.org/roughrider-support.
Tools.
These tools are useful for assembly of the wheelchairs. (13, 19mm socket; 10, 13,
19mm wrench; + and – screwdrivers; mallet; pump)
Unpacking the Wheelchair
Unpack the box. Notice the cushion, user manual, backrest cover, caster wheels,
accessory kit, pump, two rear wheels, and wheelchair frame.
Caster Assembly
To install the caster wheels, remove the nut from the caster stem and make sure the
washer is installed between the fork and the wheelchair. Thread on the nut and
tighten very firmly with a socket wrench or the socket provided in the toolkit. Make
sure the caster spins freely. Tap the plastic caps in place with a wooden or rubber
mallet.
Rear wheels
Remove the packing from the rear wheels. Be careful not to scratch the hand rim
paint. Make sure the valve stem is straight. Inflate the tires. Inflate between 45 and
55 pounds per square inch (3 – 3.8 Bar). Replace the valve cap. Determine which
axel position is required. Refer to whirlwindwheelchair.org/service for more
information on measurements and wheelchair setup. Remove the axel bolt from the
accessory bag. Remove the nut and spacer and insert the bolt so that the head is
recessed in the hub. Install the spacer over the bolt and install the axel through the
appropriate hole in the axel block. The hand rim should face away from the
wheelchair frame. Install the nut. Tighten firmly with a 19mm wrench and socket.
Make sure the wheel spins freely.
Adjusting the brakes
Remove the wrapping from the brakes. Slide the brake clamp to a position where
the brake engages firmly with the tire, but is still easy to operate. Use a mallet if
needed to move the brake clamp. Tighten the brake clamp with a 13mm wrench and
www.whirlwindwheelchair.org
© 2018 Whirlwind Wheelchair International.
All rights reserved.
Advertisement
Related Manuals for Whirlwind RoughRider
Summary of Contents for Whirlwind RoughRider
- Page 1 RoughRider Wheelchair Assembly This video shows assembly instructions for the Whirlwind RoughRider wheelchair. For more detailed assembly instructions and information on service provision, see whirlwindwheelchair.org/roughrider-support. Tools. These tools are useful for assembly of the wheelchairs. (13, 19mm socket; 10, 13, 19mm wrench; + and – screwdrivers; mallet; pump) Unpacking the Wheelchair Unpack the box. Notice the cushion, user manual, backrest cover, caster wheels, accessory kit, pump, two rear wheels, and wheelchair frame. Caster Assembly To install the caster wheels, remove the nut from the caster stem and make sure the washer is installed between the fork and the wheelchair. Thread on the nut and tighten very firmly with a socket wrench or the socket provided in the toolkit. Make sure the caster spins freely. Tap the plastic caps in place with a wooden or rubber mallet. Rear wheels Remove the packing from the rear wheels. Be careful not to scratch the hand rim paint. Make sure the valve stem is straight. Inflate the tires. Inflate between 45 and 55 pounds per square inch (3 – 3.8 Bar). Replace the valve cap. Determine which axel position is required. Refer to whirlwindwheelchair.org/service for more information on measurements and wheelchair setup. Remove the axel bolt from the accessory bag. Remove the nut and spacer and insert the bolt so that the head is recessed in the hub. Install the spacer over the bolt and install the axel through the appropriate hole in the axel block. The hand rim should face away from the wheelchair frame. Install the nut. Tighten firmly with a 19mm wrench and socket. Make sure the wheel spins freely. Adjusting the brakes Remove the wrapping from the brakes. Slide the brake clamp to a position where the brake engages firmly with the tire, but is still easy to operate. Use a mallet if needed to move the brake clamp. Tighten the brake clamp with a 13mm wrench and www.whirlwindwheelchair.org © 2018 Whirlwind Wheelchair International. All rights reserved.
- Page 2 Special Adjustment Rear Axle Position (5 axle position) To use the rear axle hole, it may be necessary to remove the wedge from the brake clamp. First, install the wheels in the rear axle position. To remove this wedge, first position the clamp between the two curves on the wheelchair frame. Remove the nut from the brake clamp. Slide out the bolt, tapping with a hammer if necessary. Remove the wedge. Reinstall the clamp bolt with the flattened part facing downward towards the wheelchair tube. Adjust the clamp and tighten. Backrest Installation Remove the wrapping from the backrest straps. Swivel the backrest canes outward from the front of the chair towards the back. There are three backrest heights (High backrest; middle backrest; low backrest). The straps must be adjusted for each height. The straps are pre-installed for the high backrest height. To set up the backrest in the highest position, slide the backrest canes up until the bottom hole can be seen through the backrest hole. Install the hook and loop tab onto the backrest bolt, which can be found in the accessory bag. Make sure the softer “loop” part is facing out. Swivel the backrest cane slightly, or tap gently to make the installation easier. Tighten the backrest bolts with a 13mm socket and wrench while holding the backrest tab vertical. Make sure that none of the straps are too tight so as to prevent the wheelchair seat to be stretched tight when opened. Adjust all the back straps to be equally tensioned with the wheelchair fully opened. Backrest Cover Install the backrest cover as shown, with the logo on the back of the wheelchair and the wings fastened around the top of the backrest canes. There is a seam that should be positioned at the top of the wheelchair backrest. The backrest should lie flat and be even on all sides. Secure the two straps from the front and back of the cover, below the bottom backrest strap. Changing Backrest Height Fold the chair slightly. Remove the backrest bolts. There are three backrest height positions. The backrest cane and straps must be moved to change positions. For the highest position, use the bottom hole in the backrest cane and there will be two www.whirlwindwheelchair.org © 2018 Whirlwind Wheelchair International. All rights reserved.
