For more information on specifications and fitting of the RoughRider wheelchair see www.whirlwindwheelchair.org/roughrider
Rider Name
Rider Age
Rider Gender
Rider Reference #
Rider contact information
Distributing Organization
Assessment performed by
Date
Yes
No
1. Rider has head control
2. Rider can maintain upright sitting position
3. Rider does not have significant contractures
4. Rider needs pressure relief cushion. Notes:
____________________________________
If any of the answers are"No" in the grey boxes,
the RoughRider may not be appropriate for this
rider without intermediate-level service.
Seat Width The seat with is measured inside the frame tubes.
The RoughRider backrest width matches the seat width.
Seat heights (and footrest adjustment range) vary slightly
based on seat depth. Seat heights are measured from the
top of the seat tubes of the 14" seat depth to the floor.
Choose Wheelchair Width:
12.5"
(18
/
" Seat height)
1
2
14"
(19"
Seat height)
15.5"
(19
/
" Seat height)
3
4
17"
(20
/
" Seat height)
1
4
18.5"
(20
/
" Seat height)
3
4
Axle Position
Select initial axle position, 1 through 5
#1 is farthest forward and is the most active position
#5 is farthers backwatrds and is the most stable
Axle position (adjustable)
#1 (Farthest forward)
#2 (Second from front)
#3 (Center- a good starting point)
#4 (Second from rear)
#5 (Farthest back-good for double amputees)
Whirlwind Wheelchair
D
B
C

Select Wheelchair Size Options

1
2 3 4
5
http://whirlwindwheelchair.org
RoughRider

Rider Measurements

A
Hip Width
Rider Hip Width (A)
Rider Lower Leg Length (B)
The footrest height is adjustable from 11" to 17"
Actual footrest height range varies with seat height
Rider Upper Leg Lenth (C)
Measured behind knee to back of buttocks
Rider Backrest support Height (D)
Record where backrest should contact riders back with
cushion; Effective height of back support will vary
Backrest Height Select Backrest Height Position
Backrest Height (Adjustable)
14"
16"
18"
Seat Depth Actual length of seat surface.
There is an additional 1
between the back edge of seat and backrest.
Choose Seat Depth (Adjustable)
14"
16"
18"
®
Backrest
D
Height
Upper Leg Length
C
Lower Leg Length
B
/
" space
1
2
Updated 25-Oct-11

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RoughRider and is the answer not in the manual?

Questions and answers

Related Manuals for Whirlwind RoughRider

Summary of Contents for Whirlwind RoughRider

  • Page 1 RoughRider ® For more information on specifications and fitting of the RoughRider wheelchair see www.whirlwindwheelchair.org/roughrider Rider Name Rider Measurements Rider Age Rider Gender Rider Reference # Rider contact information Distributing Organization Backrest Assessment performed by Height Date Hip Width Upper Leg Length 1.
  • Page 2 Are there contractures in hips or knees that would prevent the rider from sitting comfortably in the RoughRider wheelchair? (Contractures: Tight muscles that have become shortened and make it dif- ficult to move the joint) If yes, the RoughRider is not likely an appropriate chair for this rider. 4.Sensation Does rider have full sensation at seat surface? Incomplete sensation increases the likelihood of pres- sure sores.
  • Page 3 Check the backrest height again later if cushion height is changed in the fitting process. The 2010 RoughRider backrest height can be adjusted to 14”, 16”, and 18” from the seat surface. See Support site for more information.
  • Page 4 Ischial tuberosities Top Layer Base Layer Greater trochanters Sub Layer 1 Sub Layer 2 Layers of a Whirlwind Pressure Relief Cushion Pressure Sore Risk Areas Check Pressure Grades: • Adjust footrests (see Fitting Guide). • Detatch the bottom strap of the backrest fabric on the wheelchair, and adjust the footrests to fit the rider while sitting on a pressure relief cushion.
  • Page 5 Using extra cushions to accommodate longer lower leg length: If the rider has a long lower leg length that cannot be accomodated by the RoughRider wheelchair without additional cushioning, add additional foam underneath the cushion to lift the rider higher off the seat fab- ric.
  • Page 6 RoughRider Service Quickstart: Rider Orientation An experienced wheelcair rider should orient new riders to their wheelchair once they have been properly fit. Play a game of “follow the leader” to practice riding skills, and include attendants in the training. See the Whirlwind Basic Guide to Wheelchair Service and Distribution, at www.whirlwindwheelchair.org/service Rider orientation Topics • Wheel-locks/Brakes • Transfers (in and out of chair) • Independent and assisted •...
  • Page 7 RoughRider Service Quickstart: Basic Problem-solving Problem Possible Solution Hips sliding forward Put a cushion between the rider’s back and the backrest if the seat is too long. Tie or velcro the cushion to the seat if the cushion is sliding.
