- Page 1 040200a 6/2/03 9:42 AM Page 1 Sivoia QED seeTouch ™ Keypads for use with Lutron Sivoia QED Motorized Window Treatment System ❑ ❑ SVQ-2W SVQ-2W-IR ❑ ❑ SVQ-2WRL SVQ-2WRL-IR ❑ ❑ SVQ-2WD SVQ-3W ❑ ❑...
-
Page 2: Keypad Configurations
040200a 6/2/03 9:42 AM Page 2 CAUTION Lutron recommends that Keypads be installed by a qualified electrician. Do not connect high-voltage power to low-voltage terminals. Improper wiring can result in personal injury or damage to the control or to other equipment. Keypads must be connected to the Sivoia QED Electronic Drive Unit (EDU) by using Class 2/PELV wiring methods per the National Electrical Code . -
Page 3: Button Functionality
040200a 6/2/03 9:42 AM Page 3 Button Functionality Keypad Wiring Pressing the Open, Close, or Preset button will cause the window — Two #18 AWG (1.0 mm ) wires for power and two treatments to move to the selected position. While pressing the shielded #18 AWG (1.0 mm ) stranded wires for Raise or Lower button, the window treatments will raise or lower. - Page 4 040200a 6/2/03 9:42 AM Page 4 Sivoia QED Link Wiring Using Power Panels Open Preset Close LUTRON Open Preset Close LUTRON Sivoia QED Link Wiring Using Individual Transformers For larger systems, distribute Keypads evenly on the link (maximum one Keypad between EDUs), as seen below. Open Open Preset...
- Page 5 040200a 6/2/03 9:42 AM Page 5 4. Each Keypad terminal will accept up to two #18 AWG (1.0 5. Remove the faceplate from the Keypad. To remove the ) wires. faceplate, pull outward at each corner, one corner at a time. Connect two #18 AWG (1.0 mm ) wires to terminals 1 and 2 of the Keypad’s terminal block.
-
Page 6: Addressing The System
040200a 6/2/03 9:42 AM Page 6 Addressing the System Setting Limits 1. Enter programming mode on the Keypad by pressing and Note: Entering Limit Setup mode may cause the holding the Open and Close buttons simultaneously for 5 window treatments to move approximately 8 inches seconds. - Page 7 040200a 6/2/03 9:42 AM Page 7 4. Store the current position as the Open limit by pressing and 2. Initiate Assignment mode by pressing the Close button. The holding the Open button on the Keypad for 5 seconds. The LED next to the Close button will continue to flash (once per LED next to the Open button will turn on for two seconds.
-
Page 8: Storing Presets
Limited Warranty If you need assistance, call the toll free VIMCO Technical Support Center. Please VIMCO will, at its option, repair or replace any unit that is defective in materials or provide exact model number when calling. manufacture within one year after purchase. For warranty service, return unit to place of (800) 466-1503 (U.S.A., Canada, and the Caribbean)
