Summary of Contents for Von Racer 8193

  • Page 1 Model:8193...

  • Page 2: Assembly Guide

    ASSEMBLY GUIDE Congratulations, you are now the owner of a brand new Von-racer chair! Before enjoy the comfort chair, you have to put it together.This Assembly Guide will take you through the basic assembly process. To make sure your assembly goes smoothly, please follow the assembly instructions, and especially the important safety information.

  • Page 3: Package List

    .0 2 PACKAGE LIST Casters Star Base Gas Lift Quantity: 5 Quantity: 1 Quantity: 1 Lift Cover Left Plastic Cover Set Right Plastic Cover Set Quantity: 1 Quantity: 1 Quantity: 1 Left Right Angle Adjusters Armrests Seat Plate Quantity: 2 Quantity: 2 Quantity: 1 head pillow...

  • Page 4: Assembly Instruction

    .0 3 ASSEMBLY INSTRUCTION Step 1 : Turn the Star Base upside down, then press the Casters into the holes at the end of each base leg. Step 2 : Turn the Star Base upright and insert the Lift into the center hole of the Star Base, the Lift Cover should be placed over the Lift.
  • Page 5 .0 3 ASSEMBLY INSTRUCTION STEP 3 : Remove All M8x25mm Bolts from the seat and back. M8*25mm STEP 4 : Attach the arms to the seat cushion with eight M8X25mm bolts, using the Wrench. service@vonracer.net www.vonracer.net...
  • Page 6 .0 3 ASSEMBLY INSTRUCTION STEP 5 : Align the seat plate to the bottom of the seat cushion, make sure that the front of the seat plate is facing the front of the seat cushion. Attach the seat plate to the seat cushion using four M8X25mm bolts, tighten all the bolts with the wrench.
  • Page 7 .0 3 ASSEMBLY INSTRUCTION STEP 7: Turn the seat cushion upright and align the center hole of the seat plate over the lift, then push the seat cushion down onto the lift firmly until the connection is secure. STEP 8: Using Adjusters to attach Seat Cushion and Back Cushion, align the adjusters over the pre-drilled holes underneath the seat cushion and back cushion with M8x25mm Bolts, tighten all the bolts with the wrench.
  • Page 8 .0 3 ASSEMBLY INSTRUCTION STEP 9 : Attach Seat Cushion and Back Cushion, align the adjusters over the pre-drilled holes underneath the back cushion with M8x25mm Bolts, tighten all the bolts with the wrench. Note: Please tighten the Bolts to 50%, not to 100%. STEP 10: Adjust balance of the full chair, then tighten all bolts to 100% on each side of adjuster.
  • Page 9 .0 3 ASSEMBLY INSTRUCTION STEP 12: Press the plastic caps into the adjuster holes to cover the bolts. Congratulations!You’ve assembled your Vonracer chair. CAUTION! Do not pull the cable during using. If you have any problems during installation or other issues, please contact us service@vonracer.net, we will reply your email in hours.
  • Page 10 INSTRUCTIONS FOR USE Seat Height: Paddle-shaped lever on right side To raise: While taking your weight off chair, lift lever up. To lower: While seated, lift lever up. At the proper height, your feet should rest flat on the floor. Tilt Tension: Long stem under the seat cushion with knob To increase tension: While seated, turn knob...
  • Page 11 INSTRUCTIONS FOR USE Operating the tilt lockout To let your chair tilt back, pull the control handle out. To stop your chair from tilting, sit forward, then push the control handle in. Backrest Recline Pull the lever FULLY and lean back slowly until desired angle is achieved, then slowly return the lever to its starting position,...
  • Page 12 INSTRUCTIONS FOR USE 1D-Function Armrest Up and Down Relax with footrest Pull out the pole of the footrest, and turn the footrest to the front. service@vonracer.net www.vonracer.net...

  • Page 13: Safety And Maintenance

    SAFETY AND MAINTENANCE Do not stand on the chair, Do Not use the chair as stepladder. Use this product for seating one person at a time. Do not use the chair unless all bolts and screws are firmly secured. Avoid contact with sharp objects to prevent puncturing the fabric. Every 6 months, check all bolts and screws to ensure they are tight.

  • Page 14: Limited Warranty

    LIMITED WARRANTY Von racer promises to repair or replace any Von racer chair that is found to be defective in material or workmanship within one (1) and year from the date of original purchase so long as you, the original purchaser, still owns it.
  • Page 15 LIMITED WARRANTY Returned products must be returned in the same condition as they were sent and they must be sent in its original packaging. If the product is not faulty, (i.e. if you changed your mind or if you are unhappy with the product for some other reason), the cost of shipping will fall on you.
  • Page 16 E-mail: service@vonracer.net Web: www.vonracer.net...
