- Page 1 9 8 - 1 3 R O A D G L I D E / U LT R A INSTA L LATION INS TRUCTI O N S P A G E ! O F ! R E V 0 0 1...
-
Page 2: Table Of Contents
98-13 ROAD GLIDE/ULTRA INSTALLATION INSTRUCTIONS Kit Parts ....................Base Kit Parts: ..................... With Amplifier ....................With Head Unit ....................Prepare the Bike ..................Installation oF SinisterSound Fairing kit ........... Installation of Head unit ..............Installing the PAC Handle-bar Audio Control Interface ...... -
Page 3: Kit Parts
KIT PARTS BASE KIT PARTS: 1 - SinisterSound speaker enclosure, Clutch side 1 - SinisterSound speaker enclosure, Brake side 1 - Fairing speaker bracket, Clutch side 1 - Fairing speaker bracket, Brake side 8 - Thread cutting nuts 2 - Speaker covers 1 - Fairing brace bracket, Clutch side 1 - Fairing brace bracket, Brake side 4 - Bracket to enclosure screws... -
Page 4: Prepare The Bike
PREPARE THE BIKE Remove the outer fairing and old audio equipment. Move any wiring harnesses that would interfere with the new SinisterSound enclosures toward the radio.Installation of SinisterSound Enclosures If you already have an Amplifier go to the Installation of SinisterSound Fairing Kit section. If you are installing an Amplifier or Head Unit, continue. -
Page 5: Installation Of Sinistersound Fairing Kit
INSTALLATION OF SINISTERSOUND FAIRING KIT Place speaker covers between inner fairing and mounting brackets. Use included thread cutting nuts. Mount the larger stainless brackets as shown. Look for the pin on the brake side. Attach the enclosures to the brackets using the 4 supplied screws. P A G E ! O F ! R E V 0 0 1... - Page 6 If you already have an amplifier and head unit, continue to step 4. If you are installing a head unit or an amplifier, skip step 4 and go to the Installation of Head Unit section or Installation of Amplifier section. Connect your speaker pods to your amplifier using the appropriate output connections per amplifier instructions Continue to the Testing and Tuning section.
-
Page 7: Installation Of Head Unit
INSTALLATION OF HEAD UNIT Follow the instructions included with your head unit. We recommend the Kenwood Marine KMR-M series head unit. INSTALLING THE PAC HANDLE-BAR AUDIO CONTROL INTERFACE Connect the Yellow, Black and Red wires from the head unit harness to the Yellow, Black and Red wires of the PAC Harness. Connect the Blue/White (Ant. -
Page 8: Installation Of Amplifier
INSTALLATION OF AMPLIFIER IMPORTANT: You must use a radio with no CD player like the Kenwood KMR-M322BT or the KMR-M325BT. That way the amplifier will still fit in fairing in front of the radio. Largest amp size needs to stay at or under 8.25" wide. We recommend the Arc Audio Moto600.4 for this bike. - Page 9 ARC AUDIO MOTO 600.4 Remove the fuse from the SinisterSound power and ground cable. Connect the SinisterSound power and ground cable to the amplifier and route towards the battery through the cable channel under the tank. Connect the RCA harness to the amplifier Input port and the RCA’s to the output ports of the head unit.
-
Page 10: Diamond Audio Amplifier Wiring And Settings
DIAMOND AUDIO AMPLIFIER WIRING AND SETTINGS DIAMOND AUDIO MICRO 2V2 Remove the fuse from the SinisterSound power and ground cable. Connect the SinisterSound power and ground cable to the amplifier and route towards the battery through the cable channel under the tank. Connect the RCA harness to the amplifier Input port and the RCA’s to the output ports of the head unit. - Page 11 DIAMOND AUDIO MICRO 4V2 Remove the fuse from the SinisterSound power and ground cable. Connect the SinisterSound power and ground cable to the amplifier and route towards the battery through the cable channel under the tank. Connect the RCA harness to the amplifier Input port and the RCA’s to the output ports of the head unit.
-
Page 12: Soundigital Amplifier Wiring And Settings
SOUNDIGITAL AMPLIFIER WIRING AND SETTINGS SOUNDIGITAL 400.2D EVO Remove the fuse from the SinisterSound power and ground cable. Connect the SinisterSound power and ground cable to the amplifier and route towards the battery through the cable channel under the tank. Connect the RCA harness to the amplifier Input port and the RCA’s to the output ports of the head unit. -
Page 13: Testing And Tuning
TESTING AND TUNING Turn bike ignition switch to Accessory. Choose a music source and play. We recommend setting the head unit volume to 70% then slowly increase the gain until you start to hear distortion. Then back the gain off a few clicks. About Adjusting the Gain (from Arc Audio Manual): “Because of the wide range of head unit output configurations all ARC Audio amplifiers have an adjustable input sensitivity or “Gain”. -
Page 14: Finishing The Installation
FINISHING THE INSTALLATION After all audio equipment is installed, move all wires out of the way. Make sure hooks that hold the fairing near the headlight and pins on the bottom are clear. Replace outer fairing. ! BE CAREFUL ! This model Road Glide does not have brass inserts.
