- Page 1 ZeNeo U S E R G U I D E...
-
Page 2: Maintenance
T A B L E O F C O N T E N T S GET STARTED What’s in the box Overview Charging Basic operations Wearing Shortcuts PAIRING Pairing Firmware update ACTIVITY TRACKING Activity Goals Heart rate Sleep Stopwatch Timer CONNECTED FEATURES Calls Voice command... - Page 3 1 . W H A T ’ S I N T H E B O X ZENEO CHARGER + USB CABLE GET STARTED GUIDE 2 . O V E R V I E W Speaker Touchscreen Microphone - 3 -...
- Page 4 Once ZeNeo is fully charged, the battery indicator will be full. It takes about 1 hour and a half to fully charge ZeNeo. When the battery level gets low, a battery indicator will appear. Check ZeNeo battery level at any time from the shortcuts interface or by going to the Watch Settings menu >...
-
Page 5: Basic Operations
I CHANGE THE WATCH FACE To change your ZeNeo watch face, press firmly on the current watch face, swipe left or right to go through the different watch faces available and tap on the one you want to select and use. - Page 6 5 . WEARING I DAILY WEAR For all-day wear, we recommend you to wear ZeNeo a finger’s width above your wrist bone. I EXERCISE & WORKOUT During our workout, we suggest you to wear ZeNeo higher on your wrist for recording more accurate heart-rate reading.
- Page 7 Search for the MyKronoz App in the App store or Google Play store, download and install the App on your mobile device. Open the MyKronoz App on your mobile device. Sign up if you are a new member or login with your existing account. After entering your personal information, tap Set up.
- Page 8 To pair your device with your phone, put the QR code on ZeNeo into the viewfinder (MyKronoz App) • When ZeNeo is successfully paired, you will be notified on your mobile phone’s screen. Tips & tricks Normal pairing: Tap on the center of the watch face screen 3 times to reveal the QR code on the watch screen.
-
Page 9: Firmware Update
MyKronoz will provide regular firmware updates which you will need to install in order to access our latest upgrades and features for your watch. With ZeNeo, all these updates need to be done by OTA (Over The Air) and through the mobile app. Updates are performed over the air using the mobile app. - Page 10 To sync your data manually, slide your finger down the screen. ZeNeo has the ability to store up to 7 days of your activity data. Then, you will have to synchronize your ZeNeo with your mobile app in order to avoid loss of data.
- Page 11 • Long press the screen data for which you want to adjust your goal and confirm On each activity screen of your ZeNeo, a progress bar will show how close you are to your daily goal. Once you hit one of your daily goals, ZeNeo will gently vibrate and display a Goal achieved interface.
-
Page 12: Manual Mode
Setting automatic HR monitoring on a very regular basis will impact the battery life. HEART RATE ALERT ZeNeo can also alert you when your heart rate is going above or below preset limits. You can customize those limits directly from the watch > Go to the Settings menu > Click on Activity >... - Page 13 1 2 . SLEEP ZeNeo tracks the hours slept and the quality of your sleep. START/EXIT SLEEP MODE MANUALLY • Press the sleep app icon of the ZeNeo main menu • Press on the Start icon to enable sleep monitoring •...
-
Page 14: To Use The Timer
At the end of countdown, your watch will alert you with sound and vibration. 1 5 . CALLS The ZeNeo calls features allow you to dial a number, see the caller ID & calls history, answer and reject an incoming call directly from your wrist. - Page 15 1 6 . VOICE COMMAND The voice command allows you to remotely control your phone, search for information or send a quick command. To enjoy this feature, make sure that the BT 3.0 is connected with your smartphone (refer to 6. Pairing section for more details). SEND A VOICE COMMAND •...
- Page 16 • Enable ”Show in Notification Centre” to receive the notification on ZeNeo. ZeNeo shows the 20 most recent notifications and 3 screens of detailed information for each notification. For some very popular applications, ZeNeo displays the original application icon. For other applications, ZeNeo displays a generic icon.
- Page 17 Following this procedure, your ZeNeo will display the weather forecast of your select location. ZeNeo will display the weather forecasts of the present day and upcoming 3 days on a second page. To change the temperature unit, go in the Watch settings > click on Activity > select Units or from the mobile app, go to the Settings menu >...
- Page 18 2 1 . CAMERA REMOTE ZeNeo can be used as a remote control to take pictures and selfies from your smartphone. This feature is useful when you want to take a group picture or when you want to take a selfie.
- Page 19 Go into the Music app on your ZeNeo • Play, pause, skip tracks and adjust volume straight from your wrist On your ZeNeo, you can see information about the track currently playing, like the artist or track name (Android only). 2 3 . ANTI-LOST This alert notifies you with a vibration or a sound (depending on your watch settings) when your ZeNeo is going out of range (BT range 10 m) of your phone.
- Page 20 Then confirm To dismiss the alarm, press the button. For each alarm, ZeNeo will vibrate and ring continuously for 1 minute. You can snooze your wake up alarms several times. The snooze length can be set in the advanced settings from the mobile app or in the watch settings.
- Page 21 To dismiss the reminder, press the button. ZeNeo will gently vibrate and display the corresponding reminder icon to alert you. A single press on the ZeNeo button helps dismisses the reminder. If not dismissed, the same alert will repeat every 2 minutes.
- Page 22 Snooze Adjust the snooze time Ringtone Set the ringtone (Android only) You can also find other settings such as do not disturb mode, inactivity alert and time format setting in the MyKronoz App. - 22 -...
- Page 23 UNPAIR If you want to pair your ZeNeo with another smartphone, pair another MyKronoz device, give it to another person or return it, go to the MyKronoz App > Settings menu > Click on Paired watches > Click on Unpair.
- Page 24 3 0 . TECH SPECS Dimensions 52,6 x 23,8 x 12,3 mm Weight 26 g Display size and resolution IPS-LCD 1.14” / 134 x 240 px Material Polycarbonate, aluminium, silicone Battery type Lithium polymer 220 mAh Battery life Up to 4 days Bluetooth®...
-
Page 25: About This Manual
Any damage caused by misuse is not covered by the warranty. Unplug ZeNeo when it is fully charged. ZeNeo unit and charging dock contain strong magnets that may interfere with pacemakers, credit cards, watches and other magnet-sensitive objects. -
Page 26: Safety Instructions
Before using the device, read these instructions carefully. • ZeNeo has built-in batteries. Do not disassemble the battery on your own. KRONOZ LLC is not responsible for any damage or personal injury caused by the removal of the battery or any component. -
Page 27: Fcc Notice
REGULARY NOTICE FCC STATEMENT This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions : this device may not cause harmful interference, and this device must accept any interference received, including interference that may cause undesired operation. CAUTIONS Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate this equipment. -
Page 28: Rf Exposure Statements
-低功率射頻電機須忍受合法通信或工業、科學及醫療用電波輻射性電機設備之干擾。 ACCESS TO THE REQUIRED INFORMATION ON THE E-LABEL Users can access the E-Label screen on ZeNeo by going to Settings > General > Regulatory. No special access codes or permissions are required to go through the above steps beyond entering a user-defined password to protect against unauthorized access to the device. -
Page 29: Disposal And Recycling Information
DISPOSAL AND RECYCLING INFORMATION After the implementation of the European Directive 2012/19/EU in the national legal system, the following applies : electrical and electronic devices may not be disposed of with domestic waste. Consumers are obliged by law to return electrical and electronic device at the end of their service lives to the public collecting points set up for this purpose or point of sale. - Page 30 J O I N U S M Y K R O N O Z m y k r o n o z . c o m...
