Summary of Contents for MyKronoz ZeNano

  • Page 1 English QuIck Start GuIDE...

  • Page 2: Table Of Contents

    OVERVIEW SPECIFICATIONS TURNING ON/OFF CHARGING USB CABLE NAVIGATE THE TOUCHSCREEN BLUETOOTH PAIRING BLUETOOTH CALLS MAIN FEATURES HOW TO WEAR ZENANO...

  • Page 3: Overview

    1. OVERVIEW 3.5mm Headphones Hanger Hole On/off sleep/wake Speaker Micro USB charging Volume Key Reset Key...
  • Page 4 Icon Definition Battery indicator New message alarm is on Vibrate Bluetooth Earphone...

  • Page 5: Specifications

    2. SPECIFICATIONS ZeNano Bluetooth ® Version: V2.1 talk time : 4 hours 10.2mm 38.0mm Standby time: 120 hours Battery type: Li-ion 300mah LcD Size: 1.54 inch - 240*240 pixel Height: Width: 3 capacity (Memory): 256 Mb 51.6mm Depth: Video format: aVI/MP4/3GP...
  • Page 6 Bluetooth Dialer anti-Lost function Pedometer Phone book: 1000 Message format: SMS uSB connection: micro 5pin, uSB 1.1 accessories included : clip and intra-auricular earphones this product is not waterproof International Warranty: 1 year ZePlug / AC Charger Supply voltage:110-220V Frequency: 50/60Hz Input: 0.15a Output voltage: 5V Output: 700ma...
  • Page 7 Warning about operation this Mykronoz product is designed for receiving calls. We recom- mend using it for short phone calls to preserve battery charge, as its size and weight are optimised for daily use. If Bluetooth® fails to work when synchronising, try resetting the product and/or recharging it before trying again.

  • Page 8: Turning On/Off

    3. TURNING ON/OFF When using ZeNano for the first time, please connect it to the charger at least one hour to get ZeNano fully charged. the ZeNano software will be updated from time to time. Some new applications will be added or improved, so the manual might be different from the actual functions.

  • Page 9: Charging

    4. CHARGING this ZeNano uses a rechargeable battery. New battery will achieve the best performance after two or three complete charge and discharge cycles. We recommend using the device until the battery is off and automatically shut down. During charging, the device may get warm, this is normal.
  • Page 10 • after charging is complete, the indicator will become green. Low Battery warning When battery is low, the indicator on the screen will show that the battery is going off and the ZeNano will alert you. If not connected to a power source, ZeNano will automatically shut down.

  • Page 11: Usb Cable

    5. USB CABLE 1. connect ZeNano data cable to the uSB port of the desktop or notebook. 2. connect the other end of the cable to the micro uSB port of the ZeNano (on the right side) 3. By connecting with uSB port, the user can charge or transfer data to other desktop or notebook.

  • Page 12: Navigate The Touchscreen

    6. NAVIGATE THE TOUCHSCREEN Flick right or left on the bottom of the screen...

  • Page 13: Bluetooth Pairing

    7. BLUETOOTH PAIRING When using ZeNano for the first time, you must pair it with your phone as the synchronization of message, call history, audio, phone- book, smart features (Notification of SMS, Calls, Calendar) and the Anti-lost function will work only after ZeNano is paired with your phone.
  • Page 14 3. Switch on the Bluetooth function on your phone 4. In your phone’s Bluetooth settings, look for ZeNano and select it 5. If asked enter 0000 6. the Bluetooth icon will turn blue on your ZeNano display, and your phone will indicate “Connected” to confirm successful pairing.

  • Page 15: Bluetooth Calls

    Bluetooth pairing with your phone, Bluetooth call feature is on. On ZeNano homepage, dial a phone number using your phone or ZeNano dialer, press the Call key to call out. the user can also make a call from the Phonebook**. On the homepage, press the Phonebook key to find the appropriate contact, press the Call key to dial the corresponding contact.
  • Page 16 Added features during a call Options Description Hold Hold the current call End single call End the current call Mute cut the microphone while receiving a call Dialer pad Dial the number if needed...

  • Page 17: Main Features

    9. MAIN FEATURES * Note: these features are only available with android V2.3-V4.2 smartphone. Please go to android Market, download ZeNano aPk and install it. ** Note: these features are only available with android V2.3-V4.2 and iOS 4.0+ smartphone.
  • Page 18 If the message is not finished or sent, it can be saved as a a draft within the option Save Draft. • text input: ZeNano menu interface offers English and Spanish input methods. this device also provides the following input modes : QWErtY keyboard, alphanumeric keyboard, hand writing.
  • Page 19 • English lowercase: this device provides small letters input method. It can carry out multiple keys to enter the required letters. Enter one character per key once. • Punctuation: this input method switches to punctuation. click on the symbol you want to insert. Inbox the user can view, reply to the received message, call the sender number, forward, delete, extract, mark as unread, advanced options...
  • Page 20 (missed, dialed, received calls) and also dial a call or send a message. 9.3 AUDIO the music in your phone will be synchronized to ZeNano.In the settings list, the user can playback/pause the current audio file, choose the last or next.
  • Page 21 9.4 PHONEBOOk** after Bluetooth connection with your phone, click on Phonebook. Your phonebook will be synchronized to ZeNano. Once you enter the Phonebook interface, you can enter a name to find a contact. after pressing Options key, the user can implement the following operations : •...
  • Page 22 9.5 FM RADIO use ZeNano to listen to radio, plug the earphone cord into the device’s headset jack or use built-in loudspeaker. • channel list: displays the list of radio stations saved. the user can select the station of its choice from the list.
  • Page 23 Switch the Bluetooth ON/OFF Visibility When visibility is turned on, ZeNano Bluetooth device name can be found by other devices. When turned off, ZeNano cannot be found by other devices. My Name Displays the Bluetooth device name ZeNano by default...
  • Page 24 9.7 VOICE RECORDER Recorded files are saved by default in the root directory «Audio» folder. In the recording file list interface press Options to select audio, play, rename, attach, forward, delete, delete all files, settings, and other options. If the recording had been carried out, by pressing Options , the user can implement the following operations: •...
  • Page 25 9.8 ALARM You can set up 5 alarm times. the user can choose whether to turn on the alarm, set the alarm time, alarm mode and alarm cycle. 9.9 SETTINGS Watch settings • time and date: Set the time, date, time and date formats.
  • Page 26 Restore factory settings this feature requires a password support (Initial password is 0000). ZeNano will restore to the factory default state. this operation will remove all information saved in the device. 9.10 ANTI-LOST When your paired phone leaves the Bluetooth operating range (10...
  • Page 27 9.11 PEDOMETER Pedometer records the time and the steps the user walks while wearing ZeNano. Once you set the pedometer on, it will record the times the user moves its arms forward and backward while wearing ZeNano. 9.12 REMOTE* the smart features are listed under this menu.

  • Page 28: How To Wear Zenano

    10. HOW TO WEAR ZENANO You can unclip ZeNano from the bracelet by grabbing the bottom of the removable screen and pulling it up.
