- Page 1 EasyGrinder Instruction manual Grinder for combs and cutters for sheepshearing Edition/Index: EASYGRINDER/B 03-11...
-
Page 2: Table Of Contents
6.1 Grinding combs 6.2 When is the comb sharp? 6.3 Grinding cutters 6.4 When is the cutter sharp? 7 Emery setting procedure 8 Maintenance 9 Trouble shooting 10 Disposal and material groups 11 Illustration spare parts Instruction manual / EasyGrinder... -
Page 3: Generalities
Heiniger stands for quality for more than 60 years. Your EasyGrinder is exclusively conceived for grinding combs and cutters for sheep shearing. With just a little care and attention, the EasyGrinder will give you many years of excellent services. The guarantee conditions are included in the general terms and conditions of the manufacturer;... -
Page 4: Information Symbols
Operation of the equipment is only permitted by personal expected to do their work reliably. Persons, whose reactivity is affected by drugs, alcohol or pharmaceuticals are not perwithted to operate the equipment. Instruction manual / EasyGrinder... -
Page 5: Power Supply
▪ Damaged or loose fasteners, nuts, bolts, screws, etc. ▪ Incorrectly or badly set emeries. 2.5 Children WARNING! Never leave the equipment unsupervised and use it very carefully when children or persons who cannot judge the dangers are nearby. Instruction manual / EasyGrinder... -
Page 6: Specifications And Spare Parts
23 kg 3.2 Spare parts list ( Illustration at the end of the manual) POS DESCRIPTION TOTAL Spare parts to EasyGrinder Motor to EasyGrinder with switch and flange Fixation flange Support EasyGrinder Pendulum hook Pendulum upright Mounting bracket Collar Ø10 Threaded pin M 5 X 8 Washer Ø... -
Page 7: Transport And Accepting Delivery
POS DESCRIPTION TOTAL Spare parts to EasyGrinder Guard ring Cover behind Guard cover LS-screswTORX M5 x 16 KAFLOK PH-screw M5x10 Spacer hexagonal M5x35 Hexagonal screw Verbus Ripp M8x25 Hexagonal rip nut M8 Centerin bush complete Grinding disc Ø370 Emery paper self-adhesive medium... -
Page 8: Assembly And Function
6 Operation. 5.2 Disc guard The EasyGrinder is fitted with a guard enclosing the disc to protect the user during use. It is necessary to remove the outer part of the guard to remove or to change the emery papier. -
Page 9: Operation
▪ Always hold the upper part of the pendulum at the pendulum hook with your spare hand (fig. 4) ▪ Use the whole width of the emery paper. ▪ Always take 3 teeth off the edge of the disc (fig. 3) ▪ Use very firm even pressure during the whole grinding. Instruction manual / EasyGrinder... -
Page 10: When Is The Comb Sharp
(fig. 6). The light will shine on a rounded/blunt edge but will not shine on a sharp edge. NOTE You must grind your combs until the blunt edge is sharp (fig. 5). If in doubt, grind it again. Instruction manual / EasyGrinder... -
Page 11: Grinding Cutters
7 Move the cutter several times over the disc with the grinding movement (fig. 8). If the pendulum hook is too far inside, the cutter will rub on the upper side (fig. 9). If the Instruction manual / EasyGrinder... -
Page 12: When Is The Cutter Sharp
(fig. 12), check that the whole surface of the cutter is ground and there are no dull patches. If in doubt, grind it again. fig. 12 Instruction manual / EasyGrinder... -
Page 13: Emery Setting Procedure
Place the centering bush on the fixation flange of the disc. Take a new original Heiniger emery paper and take off the protective film. Put the new emery papier by the glue side inside, on the fitted centering bush, on the cleaned grinding disc. -
Page 14: Trouble Shooting
Stick new emery 3. Disc buckled 3. Replace disc 4. Motor shaft deformed 4. Replace motor Emeries 1. Wrong emery used 1. Use only original Heiniger won't stick emery paper. to discs 2. Processing temperature under 2. Augment processing 5°C. -
Page 15: Disposal And Material Groups
1, 2, 3, 4, 5, 6, 7, 8, 9, 11, 12, 13, 14, 16, 17, 18, 21, 22, 23, 24, 25, 26, 29 Aluminium 1, 19, 20, 26, 27, 29 Copper 1, 10 Polyethylene 1, 10 Rubber 10, 15 11 Illustration spare parts Instruction manual / EasyGrinder... - Page 16 Date of purchase Stamp and signature In case of claim, please return your Heiniger machine with the instruction manual and the warranty card at the end directly to your local distributor. Please do not cut off the warranty card from the instruction manual, or do not send it directly to Heiniger.
