    Installation Guide Penta 720-800A modular I/O Base unit, 2U 19” chassis Contents GENERAL DESCRIPTION. Accessing the Penta 720 cards. Operation Rear panel layout. Dual SFP optical I/O mini-module, 720-150 Terminal Connections. I/O CARD CONNECTIONS. 8 channel analogue AD card and 8 channel analogue DA card Dual SDI/HD/3G embedder/deembedder card w.
  • Page 2 Installation guide Penta 720-800A Base unit IMPORTANT SAFETY INSTRUCTIONS READ AND KEEP THESE INSTRUCTIONS WARNING – when using electric products, basic precautions should be followed, including the following: Read all of the safety and installations instructions and explanation of graphic symbols before using the product.
  • Page 3 Installation guide Penta 720-800A Base unit The product must be grounded. If it should malfunction or breakdown, grounding provides a path of least resistance for electric current to reduce the risk of electric shock. This product is equipped with a power supply cord having an equipment-grounding conductor and a grounding plug.
  • Page 4: General Description

    User guide Penta 720-800A Base unit General description. The 720-800A base unit is the basic chassis of the Penta 720 Modular I/O audio router unit. It consists of a 19” wide, 2U high sub rack, equipped with a basic I/O and router main board and a backplane to accommodate a total of 8 I/O cards providing flexible and versatile I/O structure for various router and I/O applications.
  • Page 5: Operation

    User guide Penta 720-800A Base unit Operation The Penta 720 is operated via the Network port using the Penta manager control program, or via the NTP Router Control System RCCore, when the unit is a part of an integrated routing system. On the front panel there are LED indicators showing the status of the unit, and on the rear panel there is “reconfig”...
  • Page 6 User guide Penta 720-800A Base unit The selection of either of the two recovery modes are fixed after selection. The purpose of the recovery mode is to download new firmware to the unit running only the fixed internal boot code in a simple default configuration if download of firmware is not working in normal operating mode of the unit.
  • Page 7 User guide Penta 720-800A Base unit Doc no. 720-8001-A-4 Rev. date 131030 Page 7 of 13...
  • Page 8: Rear Panel Layout

    User guide Penta 720-800A Base unit Rear panel layout. Rear panel layout Rear panel layout Card slot 1 to card slot 8 Mini module slot Mains inlet 2. Mains inlet 1. The base unit is equipped with one power supply unit mounted with two redundant power supplies.
  • Page 9: Dual Sfp Optical I/O Mini-Module, 720-150

    User guide Penta 720-800A Base unit Dual SFP optical I/O mini-module, 720-150 The Dual SFP optical module, can be installed with one or two “Small form-factor pluggable” (SFP) transceiver modules. The SFP modules are standard types which support various types of optical interfaces with LED or Laser diodes and various wave lengths.
  • Page 10 User guide Penta 720-800A Base unit AES/EBU input/output 25 pole D-sub connectors. Female connector for AES/EBU input and output connections The top connector provides the connection for the first 4 AES/EBU input and output channels. The lower connector provides the connection for the last 4 AES/EBU input and output channels, providing a total of 8 AES/EBU I/O channels.
  • Page 11: I/O Card Connections

    User guide Penta 720-800A Base unit I/O Card connections. 8 channel analogue AD card and 8 channel analogue DA card Analouge I/O 25 pole D-sub connectors. The two optional analogue card for the Penta 720, 720-130A, 8 ch. AD Card 192 kHz and •...
  • Page 12: Dual Sdi/Hd/3G Embedder/Deembedder Card W. Src

    User guide Penta 720-800A Base unit Dual SDI/HD/3G embedder/deembedder card w. SRC BNC video I/O connectors The optional SDI/HD/3G embedder/deembedder card for the Penta 720 720-210A, Dual SDI/HD/3G embedder/deembedder card • w. SRC Is interfaced via 4 BNC connectors on the card, which are accessible from the rear panel of the Penta 720 chassis.
  • Page 13: Electrical Specifications

    User guide Penta 720-800A Base unit Electrical specifications. Power consumption ............90 VA max. Input voltage ..............90 – 260 VAC 100 – 240 VAC Nominal, 47 - 63 Hz Mains fuse, mounted in IEC connector......1 A, T1AH/250V Safety compliance............. EN 60950-1:2006 Power supply cord must be min.
