Summary of Contents for Hakko Electronics Matala HK-25L
-
Page 2: Cautions For Use
WARNING IMPORTANT SAFEGUARDS READ AND FOLLOW ALL SAFETY INSTRUCTIONS. DANGER aeration following water (Figure 1) Figure 1 CAUTIONS FOR USE... -
Page 3: Pump Casing
PUMP CASING INSTRUCTIONS NOTES 1. INSTALLATION 2. GROUNDING must DANGER nominal 110-120 . Carefully read the speci cation on the nominal volt circuit as indicated on the sticker! For Canada, USA : the nominal volt circuit is 110-120 volt. Australia is 240 volt. 220 volt for other countries. Grounding for plug F Grounding for plug G Grounding for plug I... -
Page 4: Operation And Maintenance
3. OPERATION AND MAINTENANCE ASSEMBLY AND OPERATIONAL INSTRUCTIONS. aerations aeration... - Page 5 Construction HK-25L...
- Page 6 Construction HK-25LP...
- Page 8 Construction HK-40LP...
- Page 9 Construction HK-100L, HK-120L...
- Page 10 Construction HK-150L, 200L, 250L...
-
Page 11: Maintenance
MAINTENANCE... - Page 12 /25LP /40LP /25LP /40LP /40LP Model HK-60L HK-80L HK-100L HK-120L HK-25L / 25LP HK-40L / 40LP Specification Item Max flow(115V/60Hz) 1.1 / 32 2.5 / 70 2.9 / 82 3.5 / 100 4.2 / 119 4.8 / 137 (cfm) / (lpm) Max flow(230V/50Hz) 1.1 / 31 2.3 / 65...
- Page 13 List of repair parts Actuating Rod HK-150L HK-AA100 HK-200L HK-AA250 HK-250L 1 pcs per set HK-150L HKCHB150250 Chamber Block 2 pcs per set HK-200L HK-250L Includes: Casing Block Diaphragm Mounting Block Filter Pad HK-150L HKF 250 HK-200L HK-250L 1 pcs per set Model HK-150L HK-200L...
- Page 14 MATALA WATER TECHNOLOGY CO.,LTD. GUARANTEE PROVISIONS 1) This Hakko air pump/compressor has a limited guarantee for year from the date of purchase provided that: [a] It is operated in accordance with the instruction manual. [b] Any repairs to the Hakko air pump , which must be accompanied by this certificate are undertaken or authorized by the dealer or distributor from whom it was purchased.
- Page 15 HK-100L and HK-120L Trouble shooting...
- Page 16 Matala LINEAR AIR PUMP DIAPHRAGM REBUILD INSTRUCTIONS Matala 40, 60, 80 shown Your new diaphragm kit includes two diaphragms. Each diaphragm consists of two halves. Also included is a bag with new nuts and washers. Tools you will need: Flat head screw driver, Phillips head screw driver, Adjustable wrench. 1) Remove top filter cover and filter pad.
- Page 17 5) Inspect motor for burned wire, torn rubber hoses, fine metal dust. Clean gently with damp paper towel. 6) Repair only one diaphragm at a time. Remove the black J-tube from diaphragm outlet. Once removed, just push the top of tube to the side out of the way. 7) Use a Phillips screw driver and remove the 4 screws which connect the diaphragm to the motor plate.
- Page 18 10) Inspect one new diaphragm. There are two halves for each diaphragm. Notice that the half with the round soft rubber looks different on each side. One side has a rectangular impression. This impression must line up with the magnet screw. There is also an oval peg on the hard black plastic part which must align properly with the motor plate.
- Page 19 13) Screw the 4 screws in just a little at a time while gradually increasing the torque. Progress around the screws gradually tightening evenly until both halves are fully connected and tight with the motor plate. 14) Replace the black J-Tube over the diaphragm outlet. Use existing clip to secure tube to outlet. Repeat these instructions for the second diaphragm starting at #6.
- Page 20 130507...
