Please read the manual carefully prior to use
Thank you for choosing ZASS heater. ZASS is a domestic appliance manufacturing and
export business. ZASS convection heater of Continental style, a new product based on
high-tech R & D, featuring a novel style, quick heating, high thermal efficiency, security, no
noise, no open flame, long life and simple maintenance, has become a favorite product of
consumers both home and abroad, with its perfect combination of development trend of
electrical appliance in Europe with domestic consumption fashion. The European convection
heater features a heating element with aluminum heat sink, long-life, safe, reliable
multi-temperature control security settings, tip-over power off settings, metal housing,
universal casters, types of wall-hanging and ceiling-hang, power line, operation control panel
and work settings, etc. The heating element with aluminum heat sink generates heat rapidly
after power is on, allowing a quick air circulation flow, so that room temperature may rise
quickly to achieve desired heating effect.
Service Manual
ZKG 01 W/B
Ⅰ．Product profile
display
screen
operation key
black crystal glass
Feet
Advertisement
Related Manuals for Zass ZKG 01 W/B
Summary of Contents for Zass ZKG 01 W/B
- Page 1 ZKG 01 W/B Ⅰ．Product profile Thank you for choosing ZASS heater. ZASS is a domestic appliance manufacturing and export business. ZASS convection heater of Continental style, a new product based on high-tech R & D, featuring a novel style, quick heating, high thermal efficiency, security, no...
- Page 2 Ⅱ．Product features 1． High-quality heating element with aluminum hear sink: made of advanced technology, fast heat, big thermal area, rapid temperature rise, stable performance, no oxygen consumption, no light consumption. 2． Options of common type and remote control type. 3． Display panel of digital screen, infrared remote control, easy and simple. (Remote type) 4．...
- Page 3 connected to power The heating unit heater ( heating film the back of protect grid of the of the heater) may damage fall. Please confirm heating unit not damaged d from prior to each use. o not use the electric heater the heating element broken.
-
Page 4: Wall Mount Instructions
Steps for castor installation: Put t he product upside down on a soft cotton cloth or carpet. stand correspond location lower part of the product as shown above, Mount the in the of the and then the random screw the bottom product a screwdriver and ly supplied... - Page 5 2. Aim the 4 holes in the back of the machine to the 4 hooks on the wall bracket and push it on, and then slide into the slot to click on, as shown below. 3. Fix the wall bracket lock piece onto the bracket with screws, slide the lock piece into the locking slot on the back of the machine, and then tighten up the screw, as shown in the picture below.
- Page 6 User Manual for ZKG Series...
- Page 7 Guidelines: Mon. Comfortable Tue. Wed. Economical Thu. Frost-free Fri. Sat. Anionic Sun. Weekly Mode Heating Mode A 24hour circle, with each gap between dots representing half an hour Child Lock Temperature Clock Working Status: being heating if displayed, off if not displayed.
- Page 8 Remote Control Interface 1. Turn on the power, press to get into standby, with the screen only showing the temperature (i.e. current ambient temperature), time (00:00), and function icons of “Comfortable, Economical, Frost-free, Anionic”. 2. How to set-up: Press the Program button to enter the configuration modes of “Weekly Mode ”...
- Page 9 or Weekly Mode When the icon is flashing, it is in Free mode standby, with the screen showing the temperature (i.e. current ambient temperature), time (00:00), and function icons of “Comfortable , Economical , Frost-free , Anionic ” on the right. No other icons are shown.
- Page 10 temperature, the product will automatically switch from Comfortable mode Economical mode , indicated by the icon change with flashing border. When the ambient temperature is 2˚C higher than the preset temperature, the product will stop heating (with the heating icon , and borders of the Comfortable and Economical icons stopping flashing).
- Page 11 central circle showing function icons e.g. Comfortable , Economical , or Frost-free , and then press the OK button to confirm. The border of Comfortable icon on the right side will flash, and then you can use the Up and Down buttons to select the mode you want for the time you set, i.e.
- Page 12 working temperature of the Comfortable mode. The product's Economy mode's default temperature is always 5ºC lower than the preset Comfortable mode's temperature, and the product's Frost-free mode's default temperature is 5ºC). When the ambient temperature is 2ºC higher than the preset temperature, the product stops heating, with the heating icon ，...
- Page 13 Ⅵ．Technical Data Type Voltage Frequency Power Category ZKG 01W/B 230V 50/60Hz 2000W The product is for household use only. Correct Disposal of this product This marking indicates that this product should not be disposed with other household wastes throughout the EU. To prevent possible harm to the environment or human health from uncontrolled waste disposal, recycle it responsibly to promote the sustainable reuse of material resources.
