OPERATING MANUAL
Savio UVinex ™ systems provide unparalleled water clarity for your
pond. UVinex ™ offers a safe, chemical free solution for eliminating
green water. By adding a UVinex ™ system you'll also enhance the
filtration capabilities of your Savio Skimmerfilter. ®
System
i
For use with the S
av
uv clarifier
Standard Skimmerfilters Only
o
PROTECTIVE COATING FROM BULB.
Read entire instructions prior to assembly and operation.
DO NOT REMOVE PLASTIC
SUV050A
SUV026A
SUV018A
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Savio UVinex SUV050A
Summary of Contents for Savio UVinex SUV050A
- Page 1 For use with the S Standard Skimmerfilters Only Savio UVinex ™ systems provide unparalleled water clarity for your pond. UVinex ™ offers a safe, chemical free solution for eliminating green water. By adding a UVinex ™ system you’ll also enhance the filtration capabilities of your Savio Skimmerfilter.
- Page 2 Uvinex Components The Uvinex System Should come fully Assembled. Do not disassemble. Examine all parts while unpacking. Carefully inspect Uvinex bulb for damage incurred during shipping. If unit appears damaged, contact the dealer you purchased it from for a replacement. Do not use if damage if evident.
- Page 3 Junction Screws RU119 Junction Cap Top RU120 Cap Seal Screw Ring Male RU125 RU122 Cord Seal RU124 Grommet Metal ORing RU126 RU127 Junction Cap Bottom RU121 Rubber ORing RU128 Screw Ring Female RU123 Replacement Bulb RU1805 RU2605 RU5005...
- Page 4 Uvinex Installation If installing a single UV, you may use either the left or right skimmer UV mount on the standard skimmerfilter. If using the compact skimmer filter only use the center UV mount. If using a single UV, a baffle block can be used to prevent water movement through unused UV chamber.
-
Page 5: Recommended Flow Rates
Recommended Flow Rates For green water clarification, the pump needs to flow the total volume of pond water past the UV no less than every two hours. In full size Skimmerfilters ® two UVs may be used for increased clarification. 18 Watt UVinex ™... -
Page 6: Important Safety Instructions
• UV lamps are made from glass and must always be handled with caution. • Closely supervise children around all pond equipment. • The Savio UVinex ™ system is for use solely in Savio Skimmerfilters ® . Do not use in any other environment. -
Page 7: Troubleshooting
Remedies Faults Possible Causes Trouble Shooting Faults Possible Cause Remedies UVinex ™ system not a) UV is not plugged in. a) Connect UV plug to a working outlet. oprating. b) GFCI switch (ground fault b) Reset GFCI. If this occurs circuit interrupt) has often consult an electrician. -
Page 8: Warranty
Savio Engineering, does not assume liability for consequential damage caused by the failure of the Savio UVinex ™ system. Removal of cord or ground pin voids warranty.
