MANUALE UTENTE – USER'S MANUAL
CO20HQ/CO40HQ
Colonne sonore – Column speakers

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CO40HQ and is the answer not in the manual?

Questions and answers

Related Manuals for PROEL CO40HQ

Summary of Contents for PROEL CO40HQ

  • Page 1 MANUALE UTENTE – USER’S MANUAL CO20HQ/CO40HQ Colonne sonore – Column speakers...
  • Page 3 1. PRECAUZIONI D’USO ............................3 2. DESCRIZIONE ..............................3 3. INSTALLAZIONE ..............................4 4. CARATTERISTICHE TECNICHE ..........................5...

  • Page 4: Precauzioni D'uso

    Diffusori a colonna utilizzabili esclusivamente in impianti di diffusione sonora a tensione costante (70/100V). GARANZIE E RESI: I diffusori a colonna CO20HQ/CO40HQ sono provvisti della garanzia di funzionamento e di conformità alle proprie specifiche, come dichiarate dal costruttore. La garanzia è di 24 mesi dalla data di acquisto. I difetti rilevati entro il...

  • Page 5: Installazione

    3. INSTALLAZIONE 1. In presenza di ascoltatori seduti, per ottenere il miglior effetto sonoro, è necessario fissare il diffusore con la parte inferiore ad un’altezza di 1,5 m da terra mentre nel caso di ascoltatori in piedi, l’altezza consigliata è di 1,7 m.

  • Page 6: Caratteristiche Tecniche

    CO40HQ Potenza in uscita Impedenza 100V Ω Bianco 40 W Ω 40 W 20 W Ω Giallo 20 W 10 W Ω Verde 10 W Ω Marrone 2.5 W Rosso comune Nel caso di installazione di più colonne sonore nello stesso ambiente, prestare attenzione alla corretta messa in fase elettrica delle stesse.
  • Page 7 Risposta in frequenza CO20HQ CO40HQ La Proel SpA persegue una politica di costante ricerca e sviluppo, di conseguenza si riserva il diritto di apportare miglioramenti ai prodotti esistenti, senza preavviso e in qualunque momento. REV. 00 / 22-08...
  • Page 8 1. SAFETY INSTRUCTIONS ............................8 2. DESCRIPTION ..............................8 3. INSTALLATION ..............................9 4. TECHNICAL SPECIFICATIONS ..........................10...

  • Page 9: Safety Instructions

    Are to be considered out of warranty all those defects due to an improper use or tampering acts. PROEL S.P.A. is not responsible for any damage that occurs due to a wrong unit installation.

  • Page 10: Installation

    3. INSTALLATION 1. In order to obtain the maximum sound effect, it is necessary to fix the speaker’s base 1.5 m above the ground if there is a sitting audience. In case of a standing audience, the base should be fixed 1.7 m above the ground.

  • Page 11: Technical Specifications

    CO40HQ Output power Impedance 100V Ω White 40 W Ω Blue 40 W 20 W Ω Yellow 20 W 10 W Ω Green 10 W Ω Brown 2.5 W common If more column speakers are installed in the same area, verify that their electrical phasing is correct.
  • Page 12 Frequency response CO20HQ CO40HQ According to its corporate policy of continuous research and development, Proel SpA reserves the right to modify and improve its products at any time and without notice. REV. 00 / 22-08...
