- Page 1 o m p u t i n g u r f a c e The CS-2 Processor Module S1002–10M128.02...
- Page 2 No licence or other rights are granted in respect of any rights owned by any of the organisations mentioned herein. This document may not be copied, in whole or in part, without the prior written consent of Meiko World Incor- porated.
-
Page 3: Table Of Contents
Location ........Using the Meiko Beta Phase Controller . . - Page 4 External Connections ......At the Rear of the Power Supply Unit . . . At the Rear of the Module .
- Page 5 MK403 Vector Processor Board ....Field Upgradeable Components ....MBus/VPU Processor Modules .
-
Page 7: Safety Precautions
Safety Precautions Federal Communications Commission (FCC) Notice Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to op- erate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. -
Page 8: General Precautions
RAM (or NVRAM). Lithium batteries are not customer replaceable. If they are mishandled there is a danger that they may explode. Always consult Meiko if you suspect that the battery needs replacing. Never dispose of lithium batteries in a fire or attempt to dismantle. - Page 9 When using the Genie fork lift you must first attach the two lift-clamp assemblies to either side of the module. Unscrew the securing screw that holds the telescopic section of the lift-clamp closed. Insert the rear locating pins into the holes at the rear edge of the module (the open end of the box section should face the front of the module).
- Page 10 S1002–10M128.02...
-
Page 11: Overview
Overview The Processor Module is a physical enclosure for up to 4 processor boards. Sup- porting infrastructure within the module consists of cooling fans, power supply, and connections to the CS-2 data network, the CS-2 control network, and exter- nal SCSI peripheral buses. Up to 4 SCSI disk devices may also be fitted within the module and connected to the processor boards in one of three standard con- figurations (all disks connected to one board, two disks to each of two boards, or one disk per board). - Page 12 S1002–10M128.02...
-
Page 13: Module Packaging
Module Packaging CS-2 modules are shipped in units of 1 to 4. The packaging consists of a wood base, packing foam, antistatic bag, and enclosing triple wall card outer. Packing Dimensions All dimensions are approximate. Packing dimensions (single module): Height 74 cm (29”) Width 34 cm (13.5”) -
Page 14: Unpacking
Module weight (without processor boards or peripherals): Module weight 43.5 Kg (96 lbs) Processor board weights (all processor options fitted): MK401 (Dino) 2 Kg (4.4 lbs) MK405 (Quatro) 3 Kg (6.6 lbs) MK403 (VPU) 2.7 Kg (6.0 lbs) Backplane boards: MK515 Controller 0.15 Kg (0.33 lbs) MK516 SCSI card... - Page 15 • To unpack each module first cut the banding and remove the outer card carton by lifting it clear of the module. • Remove the protective foam from the top and front of the module. • Remove the antistatic bag by pulling upwards. •...
- Page 16 S1002–10M128.02...
-
Page 17: Installing The Processor Module
Installing the Processor Module You must read this chapter thoroughly and completely before using your CS-2 module. Location The processor module must be located in a CS-2 Bay. This provides a firm level support for the module and has been designed to maximise the flow of cooling air through the module. -
Page 18: Using The Meiko Beta Phase Controller
The bay may carry a number of Beta Phase connections to the module. These connectors must be opened using the Meiko Beta Phase Controller before the module tray is pushed into position. Warning – Failur e to open the Beta Flex connectors befor e pushing the mod- ule trays into position will damage your equipment. -
Page 19: Power Connections
Harvey Hubble to UK 13 A outlet. • Harvey Hubble to US 15 A outlet. Where several processor modules are used Meiko may also supply a mains dis- tribution board. This connects eight modules to one power supply outlet. •... -
Page 20: Operation
first switching on, or changes fr om green to red during operation. Switch the power supply off, disconnect fr om the main supply , and contact Meiko for advice. Removable Panels Warning – Ensure the power supply is switched off and disconnected from the main supply befor e removing the module’... -
Page 21: External Connections
At the Rear of the Power Supply Unit 1×25-way D-type connector: RS232 connector for module control card diagnostics. This connection is for use by Meiko’s trained engineers only. 2 ×9-way D-type connectors: X-CAN and G-CAN connectors. The X-CAN is the middle connector — this is used to connect the modules within a cluster (up to 3 bays/24 module sys- tems). -
Page 22: At The Rear Of The Module
At the Rear of the Module Upper 8 cards slots: Up to eight module switch cards (MK511 or MK512) are fitted in the upper card slots. Lower 5 card slots: Up to 4 module SCSI cards (MK516) and 1 module control card (MK515) may be fitted to the lower card slots. -
Page 23: Module Identification Number
pattern may be changed by the user under software control. When power is first applied to the boards all red LEDs should illuminate, fade, and then display a ran- dom pattern. Below each matrix of red LEDs are 3 more LEDs. The green and amber lights are driven by the processor board’s CAN interface —... -
Page 24: Operating Conditions
Module Dials 0 – 3 0 0 0 0 0 8 0 0 4 0 0 C 4 – 7 0 0 2 0 0 A 0 0 6 0 0 E 8 – 11 0 0 1 0 0 9 0 0 5 0 0 D 12 –... - Page 25 Figure 3-1 The CS-2 Processor Module Switch Cards Module SCSI Cards Module Controller Module Id Switches Main Fuse Fan Fuses On/Off Switch Disk Fuses Installing the Processor Module...
- Page 26 Figure 3-2 The MK510 Processor Module Backplane (not user serviceable) 8 switch card slots Fuses Module controller slot 4 SCSI card slots S1002–10M128.02...
-
Page 27: Installing Processor Boards
Installing Processor Boards Warning – The procedures in this chapter must only be undertaken by trained engineers. Warning – You must disconnect the power supply befor e installing pr ocessor boards into the pr ocessor module. Three types of processor board are available: •... -
Page 28: Installation
Installation The same installation procedure is used to install all three board types. Insert the board so that it fits into the guide rails at the top and bottom of the mod- ule, ensuring that the component side is to the left (viewed facing the module). Gently push the board squarely on the front panel. -
Page 29: Mbus Processor Modules
Figure 4-1 MK401 Components Keyboard Fuse Ethernet Fuse SCSI Bus Fuse Boot ROM NVRAM 3×SBus Sots H8 ROM 2×MBus Slots 2 × 8 memory slots Elan Communications Processor Rear Connectors Take care not to damage the component or its neighbours when installing or re- moving these devices. -
Page 30: Sbus Modules
As newer higher performance SPARC modules become available, Meiko will of- fer these as field upgrade options. Simply unplug the old unit and replace with the new. SBus Modules Three SBus slots are provided and these may be fitted with standard SBus mod- ules. -
Page 31: Boot Rom
It is held in a DIL socket and is easily replaced. Note however that the information within the NVRAM can only be restored by Meiko’s engineers. The NVRAM contains lithium batteries which have special handling and dispos- al requirements —... -
Page 32: Front Panel Connections
Front Panel Connections Removable panels provide access to connectors on the optional SBus boards. Figure 4-3 MK401 Front Panel Connections Removable Panels SCSI A SCSI B Ethernet Keyboard 2 × RS232 SCSI Terminator Switch RS232 Connections The two RS232 channels are connected as follows. Signal ground is pin 7, chas- sis ground in pin 1. -
Page 33: Adding Scsi Peripherals
Table 4-1 RS232 Channel A Pinout. Signal Input/Output Pin number Table 4-2 RS232 Channel B Pinout. Signal Input/Output Pin number DCDB Adding SCSI Peripherals The MK401 includes two SCSI-2 controllers — both SCSI buses are available via connections on the front panel or via the processor module backplane. Up to 3 additional SCSI buses can be added using standard SBus cards, and these are available via connections on the SBus cards. -
Page 34: External Indicators
If either the front panel connections or the backplane connections are used, or no devices are attached at all, then the on-board termination must be turned on. Only when both front-panel and backplane connectors are used together should the on- board termination switches be turned off, and in this case the SCSI bus must be terminated at both ends. -
Page 35: Mbus Processor Modules
— push the processor into the connector on the MK405 and se- cure into position with a screw at each corner. As newer higher performance SPARC modules become available, Meiko will of- fer these as field upgrade options. Simply unplug the old unit and replace with the new. -
Page 36: Memory
The processor slots are numbered from 0 to 3, from right to left (when viewed from the front) as shown in Figure 4-5. Figure 4-5 MK405 Processor Numbering Slot 3 Slot 2 Slot 1 Slot 0 Front Memory Up to 16 single in-line memory modules (SIMMs) may be fitted to the MK405 board (JEDEC 36 bit SIMMs). -
Page 37: Boot Rom
They are held in a DIL sockets and are easily replaced. Note however that the information within the NVRAM can only be restored by Meiko’s engineers. The NVRAM contains lithium batteries which have special handling and dispos- al requirements —... -
Page 38: Mk403 Vector Processor Board
MK403 Vector Processor Board Field Upgradeable Components The MK403 has the following field upgradeable components (see Figure 4-7): • Superscalar SPARC processor module fitted to MBus slot. • Three SBus slots. • Two VPU slots. • Boot ROM. • H8 ROM. •... -
Page 39: Mbus/Vpu Processor Modules
MBus/VPU Processor Modules Early VPU boards are fitted with standard MBus SPARC modules and two VPU modules — these plug into the MBus/VPU slots on the MK403 mother board. Later shipments include a single cache coherent processor board that includes both the dual VPU processors on a single plug-in board;... -
Page 40: Nvram
Precautions on page ii. Fuses One fuse is used to protect the external keyboard/mouse. This fuse is 250 mA quick blow, Meiko part number 22–fu400–02e250. External Connections External connections are provided for a keyboard/mouse (8 pin circular socket), RS232 interfaces (2 channels provided by one 25-way D-type connector), and two independent SCSI buses (each via a 50-way connector). -
Page 41: Rs232 Connections
RS232 Connections The two RS232 channels are connected as follows. Signal ground is pin 7, chas- sis ground in pin 1. Table 4-3 RS232 Channel A Pinout. Signal Input/Output Pin number Table 4-4 RS232 Channel B Pinout. Signal Input/Output Pin number DCDB External Indicators Two LEDs (one green, one amber) are included on the front panel. - Page 42 The green LED flashes at a slow steady rate (once per second) when operating normally. A quicker flash rate (2 ×normal) indicates that the SPARC processor is not responding; a very quick flash rate (3 ×normal) indicates that the H8 proces- sor on the module controller is not responding.
-
Page 43: Installing Backplane Boards
Installing Backplane Boards Warning – The procedures in this chapter must only be undertaken by trained engineers. Warning – You must disconnect the power supply befor e installing boards into the processor module. A number of boards can be connected to the rear of the processor module. Along the top edge of the module backplane are connectors for up to 8 switch cards. -
Page 44: Mk511/2 Module Switch Cards
Insert the card into the card guides ensuring that the component side of the card faces the right. Firmly push the card into the position ensuring that the card mates correctly with the backplane connection. After installing a module controller card you must reinstall the blanking plate. MK511/2 Module Switch Cards Up to 8 module switch cards can be connected to the module backplane to pro- vide a first layer of switching. -
Page 45: External Indicators
Reset Switch NVRAM RS232 Meiko may upgrade the H8 ROM from time to time. The non-volatile RAM (NVRAM) holds system configuration information, such as the number of module switches. The NVRAM contains Lithium batteries which have special handling and disposal requirements — your attention is drawn to the General Precautions on page ii. -
Page 46: External Connections
External Connections Two 3 pin connectors are provided for Meiko engineering use. They are used for bench testing of the board, and allow power and diagnostic RS232 connections to be made. MK516 SCSI Cards Transfers up to 5 SCSI buses from the processor module backplane to external connectors. - Page 47 Figure 5-2 MK516 Components Bus 4 Fuses Bus 0 Termination Resistors for Bus 0 (3 packages) Installing Backplane Boards...
- Page 48 S1002–10M128.02...
-
Page 49: Installing Scsi Devices
Installing SCSI Devices Warning – The procedures in this chapter must only be undertaken by trained engineers. The MK401 processor board is equipped with two independent SCSI-2 control- lers and includes 3 SBus slots that may be used to add additional SCSI control- lers. -
Page 50: Installing The Disk Devices
Disk devices mounted within the processor module are wired directly to the rib- bon cable connectors. This wiring is added during manufacture of the module; two connection options are available: • One disk per processor board — each of the four disks is connected to SCSI bus 0 on the processor board. -
Page 51: External Indicators
External Indicators Three LEDs show from the front of the disk carrier. The green LED is the power light, the red LED is the activity light, and the yellow is the fail indicator. The activity signal is also displayed on the module’s LED panel using the small cir- cular red LED. - Page 52 S1002–10M128.02...
