- Page 1 Door Access Terminal User Manual...
-
Page 2: Table Of Contents
Door Access Terminal User Manual Table of contents Door Access Terminal User Manual ......................3 Product description ..........................3 Basic Parts ............................4 User Interface............................4 Operating indicator ..........................5 User card presentation ........................5 Passage Allowed ..........................5 Passage denied ..........................6 Signal not activated ........................ -
Page 3: Door Access Terminal User Manual
SI-1236 Trzin, Slovenia System: Metra Access Control System Product Group: Door Access Terminal ELDLISS, ELDLISU, ELDLISS_G01, ELDLISU_G01 (ISO14443A/B, ISO 15693) Types: ELDLLFS, ELDLLFU (LF Multitag) ELDLLGS, ELDLLGU, ELDLLGS_G01, ELDLLGU_G01 (Legic) ELDLMFS, ELDLMFU (Mifare, ISO14443A/B) ELDLSDS, ELDLSDU, ELDLSDS_G01, ELDLSDU_G01 (SkiData) -
Page 4: Basic Parts
Door Access Terminal User Manual Basic Parts description description OK signal OPERATE (Power) signal NO signal Antenna field Standard models are supplied with front mask in gray colour. For additional colours contact Metra sales. User Interface Door Access Terminal user interface uses optical signals ( ) and an acoustic beeper signal to inform the user about operation progress. -
Page 5: Operating Indicator
Door Access Terminal User Manual Operating indicator When the unit is running a blue OPERATE signal light is flashing. User card presentation Approach the card to the antenna field. Reading distance is 3 – 5 centimetres from the device surface. Hold the card in field for a few moments for Door Access Terminal to read and process the card. -
Page 6: Passage Denied
Door Access Terminal User Manual Passage denied If the card is rejected (passage not allowed) “NO” optical signal is flashing and interrupted acoustic signal is activated for 2 seconds. Door remains locked. Remove the card form the antenna filed. ... -
Page 7: Latch/Unlatch Function
Door Access Terminal User Manual STEP 2: When the MASTER card is recognized, “OK” optical signal lights up and short acoustic signal is activated. The door is unlocked. Remove the card form the antenna filed. Latch/Unlatch function Latch/unlatch functionality allows user to permanently open the door lock for prolonged period of time. -
Page 8: Master Card Presented
Door Access Terminal User Manual Master card presented NOTE Latch/Unlatch function with Master card is always possible and it cannot be disabled! STEP 1: Approach the MASTER card to the antenna field. Reading distance is 3 – 5 centimetres from the device surface. -
Page 9: Alarm Signalization
Door Access Terminal User Manual Alarm signalization When Alarm is triggered the interrupted acoustic signal and “NO” optical signal are activated. Alarm can be triggered (if selected in operating parameters) by various actions. To activate door brake-in or door opened too long time alarm the door must be equipped with tamper sensor.
