PRESSURE TEST:
NOTE: Do not perform a pressure test unless machine is connected
to upper radiator hose.
1. Unclamp overflow lines.
2. Close red ball valve, open black ball valve.
3. Turn top dial to "Pressure Test".
4. Turn bottom dial to desired fluid type.
5. Turn pump switch on.
6. Slowly open ball valve on red service hose until desired pressure is obtained.
(See chart in manual for reference.)
7. To relieve the pressure in the system, turn the top dial to the "Remove Fluid" position.
WARNING: Do not exceed cap rating by more than 4psi. Relieve pressure in system
before disconnecting adapters.
DRAIN TANKS PROCEDURE:
DRAIN WASTE TANK
1. Turn bottom dial to "Drain Waste Tank" position.
2. Attach open-end adapter to red service hose.
3. Flip the right side switch to "Drain Waste Tank".
4. Pump will shut off automatically when complete.
DRAIN NEW TANK
1. Turn bottom dial to desired fluid type.
2. Attach open-end adapter to red service hose.
3. Turn pump switch on.
4. Turn pump switch off when complete.
COMPLETELY DRAIN NEW TANK
1. To do this, the "Waste Tank Drain Complete" LED must be OFF.
2. Turn top dial to "Remove Fluid" position.
3. Turn bottom dial to desired fluid type.
4. Flip the right side switch to "Drain Waste Tank".
5. Turn switch to "OFF" when complete.
