WHAT'S IN THE BOX
• LED SECURITY LIGHT FIXTURE
WHAT YOU'LL NEED
• SCREWDRIVER / POWER DRILL
• WIRE CUTTERS
• WIRING SUPPLIES AS SPECIFIED BY
ELECTRICAL CODE
WARNING
Risk of fire/electric shock. Ensure that the
power is OFF before star:ng installa:on or
aZemp:ng any maintenance. Always
consult a qualified electrician
SC1-SERIES
SECURITY LIGHT
INSTALLATION INSTRUCTIONS
.
For use with:
SC1-244-1
IMPORTANT
Before assembling your fixture,
please make sure that you carefully
read through this instruc:on sheet.
Consider having your fixture installed
by a qualified licensed electrician.
INSTALLATION INFORMATION
For proper weatherproof func:on all
gaskets must be seated properly and
all screws inserted and :ghtened
firmly. Apply weatherproof silicone
sealant around the edge of the Back
Box and/or Junc:on Box. This is
especially important with an uneven
wall surface: ensure you silicone all
plugs and unused conduit entries.
PREMISE LED Inc.
80-86 Carrier Drive
Toronto, ON Canada
M9W 5R1
PREMISELED.COM
1
Advertisement
Related Manuals for Premise SC1 Series
Summary of Contents for Premise SC1 Series
- Page 1 INSTALLATION INFORMATION • LED SECURITY LIGHT FIXTURE For proper weatherproof func:on all gaskets must be seated properly and all screws inserted and :ghtened WHAT YOU’LL NEED firmly. Apply weatherproof silicone sealant around the edge of the Back Box and/or Junc:on Box. This is • SCREWDRIVER / POWER DRILL especially important with an uneven • WIRE CUTTERS wall surface: ensure you silicone all • WIRING SUPPLIES AS SPECIFIED BY plugs and unused conduit entries. ELECTRICAL CODE WARNING Risk of fire/electric shock. Ensure that the PREMISE LED Inc. power is OFF before star:ng installa:on or 80-86 Carrier Drive aZemp:ng any maintenance. Always Toronto, ON Canada consult a qualified electrician M9W 5R1 PREMISELED.COM...
- Page 2 HOW TO INSTALL THE SECURITY LIGHT 3. Connect the black supply wire to the black 1. Mount the crossbar plate to the junc:on fixture wire. Secure with the supplied wire nuts. box with the supplied screws. Connect the white supply wires to the white fixture wire and secure with the supplied wire 2. Place the gasket on the back of the fixture. nuts. Tuck all wires carefully into the j-box. The gasket should create a secure seal 4. Posi:on the fixture over the crossbar and secure against the moun:ng surface. the supplied long screw and rubber cover. WIRING INSTRUCTIONS The SC1-Series Security Light operates at 120V, 50 or 60Hz. 1. Connect the black fixture lead to the (+) LINE supply lead. 2. Connect the white fixture lead to the (-) COMMON supply lead. 3. Connect the bare copper GROUND wire from fixture to supply ground. TO ADJUST SETTINGS Adjustment seengs on the Security Light unit allow you to adjust TIME (how long to stay on afer mo:on is detected), SENSITIVITY (distance to detect mo:on) and LUX (ambient light level required before the fixture shall operate). TIME: Adjust from 10 seconds (-) / 4 minutes (half) / 8 minutes (+) SENS: Adjust detec:on distance from 0 feet (-) / 32 feet (half) / 65 feet (+) LUX: Adjust ambient light from no light (-) / dusk (half) / full daylight (+)
