WHAT'S IN THE BOX
• LED ULTRA-SLIM FLOOD LIGHT FIXTURE
• 2 X EXPANSION BOLTS
WHAT YOU'LL NEED
• SCREWDRIVER / POWER DRILL
• WIRE CUTTERS
• IP65 J-BOX
• WIRING SUPPLIES AS SPECIFIED BY
ELECTRICAL CODE
WARNING
To avoid the risk of fire, explosion, or electric shock, this product
should be installed, inspected, and maintained by a qualified
electrician only, in accordance with all applicable electrical codes.
Be certain electrical power is OFF before and during installation
and maintenance.
Make sure the supply voltage is the same as the rated luminaire
voltage.
Do not operate in ambient temperatures above those indicated
on the luminaire nameplate.
FLS1 SERIES
ULTRA SLIM
FLOOD LIGHTS
INSTALLATION INSTRUCTIONS
For use with:
FLS1-304KN-1
|
FLS1-504TR-1
|
IMPORTANT
Before assembling your fixture,
please make sure that you carefully
read through this instruction sheet.
Consider having your fixture installed
by a qualified licensed electrician.
GENERAL INFORMATION
This LED Flood Light uses the latest in
solid state lighting technology for
long life, low maintenance, and high
efficiency. The same as traditional
HID lighting. Suitable for use in the
following locations: ambient
temperature of -40° and wet
locations.
The fixtures can be installed using
two installation methods, dependent
on the model you purchased: via
junction box mount or direct surface
mounting.
FLS1-304TR-1
FLS1-804TR-1
PREMISE LED Inc.
80-86 Carrier Drive
Toronto, ON Canada
M9W 5R1
PREMISELED.COM
1
Advertisement
Table of Contents
Related Manuals for Premise FLS1 Series
Summary of Contents for Premise FLS1 Series
-
Page 1: General Information
FLS1 SERIES ULTRA SLIM FLOOD LIGHTS INSTALLATION INSTRUCTIONS For use with: FLS1-304KN-1 FLS1-304TR-1 FLS1-504TR-1 FLS1-804TR-1 IMPORTANT Before assembling your fixture, please make sure that you carefully read through this instruction sheet. WHAT’S IN THE BOX Consider having your fixture installed by a qualified licensed electrician. - Page 2 INSTALLING VIA TRUNNION MOUNT For Trunnion Mount models: 1. Using the trunnion mount holes as a guide, mark the installation points. 1. Use expansion bolts (included) to secure the fixture onto the mounting surface at the marked installation points. 3. Keep enough length wires to ensure adjusting angle unhindered.
- Page 3 INSTALLING VIA KNUCKLE MOUNT For Knuckle Mount models: 1. Pull the connecting wire through the knockout of the junction box. 1. Screw the fixture into the junction box and tighten the mounting nut with a 30-gauge wrench. 3. Connect wires into wiring terminal; white wire to “Neutral”...
