SSV Works WP-RZ3BS10 Installation Instructions

Installation Instructions:
To prepare for your installation you will need to remove the seats , center console and rear plastic panel from the vehicle.
Begin by unlatching the seats from the vehicle, next remove the center hump using the flathead screw driver on the 5 plastic pops
and the T-30 torx for the 2 bolts.
Remove the rear panel that sits behind the seats using a T-30 to remove the 7 torx bolts, and a flathead screwdriver to remove the 4
plastic pops. Once the panel is loosened, you will need to unplug the computer harness then "push" the panel down behind the
seat belt retractors, after it is free from behind the top panel pull up and away from the vehicle .
Once the panel is out you will need to remove the 2 seat belt bolts that hold the center seat belt receivers
Using the hardware provided loosely install the long
bottom
bracket onto the subwoofer enclosure
The 2 holes in the top of the bracket should line up with
the 2 holes in the vehicle crossbar behind the plastic panel,
you may need to shift the enclosure left or right to be sure
these line up
WP-RZ3BS10
RZR 1K Powered Subwoofer
Tools Needed For Installation
Torx T-30 5/32" hex driver
Drill with 1/4" drill bit 7/16" wrench
Flathead screwdriver
Phillips Screwdriver
Wire Crimpers / Strippers
Place the enclosure in the vehicle, bottom first then rotate Place the enclosure in the vehicle, bottom first then rotate
into place, be sure the top bracket is behind the upper
plastic panel of the vehicle.
Once the enclosure is in position you can loosely install the
bottom bracket
