Summary of Contents for Dyconn DMS-172
- Page 1 PDF provided by Conference Room AV Dyconn Rover Mobile 42" to 60" TV Mount Stand w/ Glass Shelf...
- Page 3 Images may be different from actual product Disclaimer It is Dyconn’s intention to have all the correct information present within this manual. Although we try our best, Dyconn makes no claim that the information comprised herein covers all conditions or details in connection with installation or use of this product.
-
Page 4: Specifications
Please read the following Instructions before installing This warning notifies you of the possibilities of personal injury or damage to equipment if you do not follow the corresponding instructions. Do not exceed maximum weight capacity for the mobile stand. Do not mount a display larger than the recommended monitor sizes. -
Page 5: Product Dimensions
Product Dimensions... -
Page 6: Parts List
Parts List... -
Page 8: Installation Instructions
Installation Instructions 1) Place the 2” swivel casters (26) onto the base (3) so that their holes are aligned. Thread the hex screws M6x8mm (27) through the washers (25), the swivel casters and into the base. Tighten the screws using the M5 Allen wrench (15) until they are firmly in place. - Page 9 1) First, remove the bracket cover from the pillar. Place the pillar (3) onto the base so that the holes are aligned. Thread the hex screws M8x15mm (10) through the bracket at the bottom of the pillar and into the base using the M5 Allen Wrench (15). Tighten screws until the pillar is firmly secured to the base.
- Page 10 3) After the base and pillar are secured, proceed to reattach the bracket cover (6) over the bracket at the bottom of the pillar.
- Page 11 1) Align the holes of the universal adaptor (2) with the holes on the back of the display. For recessed mounting holes, use spacers (17). 2) Use the screws that suit your display’s specifications (20, 22, 24) and thread them through the washer (18), the universal adaptor, spacer (if needed), and into the back of the display.
- Page 12 Make sure to lock the wheels before attaching the display. Disconnect power before removing the display from Mobile Stand. You will need assistance with this step. Failure to do so could result in serious injury or damage to equipment. 1) Carefully lift the display and attach the hooks on the universal adaptor to the pillar.
- Page 13 2) As you attach the display, make sure that it is level. Once the display is level, slightly push the display forward until the rivet screws of universal bracket are inserted into the pillar bracket. 3) First, place the washers onto the rivets and follow by attaching the M8 nuts (8). Tighten the nuts using the spanner (7).
- Page 14 1) Place the LT bracket (4) onto glass shelf (5). Thread screws M5x12mm (12) through the bracket and into the glass shelf. Tighten the screws using a Philips Screwdriver. Do not over tighten the screws; doing so could result in severe damage to equipment or cause severe personal injury. 2) Hook on the assembled Glass Shelf onto the pillar bracket slot.
- Page 15 Dyconn disclaims any liability for modification, improper installations, or installations over specified weight range. Dyconn will not be liable for any damages arising out of the use of, or inability to use of Dyconn products. Warranty specification is subject to change without prior...
