- Page 1 VoIP SIP Phone VIP – 254T / 254PT SIP Server Install Procedure www.planet.com.tw Copyright © PLANET Technology Corporation. All rights reserved.
- Page 2 Scenarios explain: SIP Proxy Mode We're using the free SIP proxy server FWD & EasyCall to perform the calling party. Please refer to the following descriptions and insert proper SIP registration information into the VIP-254T for establish the voice communications. www.planet.com.tw 2 / 12...
- Page 3 Domain Server: fwd.pulver.com fwd.pulver.com Proxy Server: fwd.pulver.com fwd.pulver.com Realm 2 Active : On Display Name: 655768 655768 Line Number : 655768 655768 Register Name: 655768 655768 Register Password: xxxxxx xxxxxx Domain Server: sip.easycall.pl sip.easycall.pl Proxy Server: sip.easycall.pl sip.easycall.pl www.planet.com.tw 3 / 12...
- Page 4 Proxy Server: 210.66.155.70 210.66.155.70 After confirming the After confirming the modification you ’ ve done, modification you ’ ve done, Please click on the Submit Please click on the Submit button to apply settings. button to apply settings. www.planet.com.tw 4 / 12...
- Page 5 Browser to Save & Reboot menu to reboot the Browser to menu to reboot the Save & Reboot machine to make the settings effective. machine to make the settings effective. www.planet.com.tw 5 / 12...
- Page 6 When Registered success, you can try dial 613, connect to FWD ECHO TEST, to test the SIP communication. Step 1. Pickup up the handset. Step 2. Press the keypad, input Step 3. You can hear around three times back tone. Step 4. Then you’ll hear the echo test voice. www.planet.com.tw 6 / 12...
-
Page 7: Switch The Realm (Registration Proxy Server)
1 ＊ : Realm 1 ---- FWD 2 ＊ : Realm 2 ---- EasyCall 3 ＊ : Realm 3 ---- Planet PBX For example: 1.From FWD switch realm to EasyCall The default is Realm 1, Input the 2 (Follow by the key) from keypad and hang up ＊... -
Page 8: For Example
. From EasyCall switch realm to PLANET IPX-2000 Just now have Realm at EasyCall account, Input the 3＊ from keypad and hang up the handset. It will switch to PLANET PBX, and it can make a sip calls via PLANET PBX. Step 1. Pick up the handset Step 2. - Page 9 www.planet.com.tw...
