evaton technologies mCVC User Manual

Introduction

Thanks
Convertor Eurorack module from Evaton Technologies!
I especially want to thank you for purchasing one of the first
µCVC's. The µCVC was first introduced at ContinuuCon 2017.
Since then, a bunch of folks have been interested in the µCVC,
and I have been building them by hand while I'm in the process
of bringing a contract manufacturer on line.
At this time, this user manual is far from complete; please
check back at
manual. This "Early Adopter" edition of the manual covers just
the basics. Please refer to the EaganMatrix / Continuum Editor
manual for more details of how to configure the µCVC to work
with your modular system. The µCVC behaves just like the full
size CVC referenced in the manual, except that it only tracks a
single finger, instead of four. Or two fingers, if you configure a
pair of µCVCs for duophonic mode.
Specifications
• Width: 6 HP
• Height: 3U
• Depth: 50mm
• Power: +12V @ 9.0 mA, -12V @ 9.0 mA
• CV Output: +/- 10VDC pk-pk
• Format: Euro modular
• Expandability: Can be daisy-chained with a second unit for duophonic play.
• Construction: Made in USA of RoHS-compliant components
• Compatibility: Continuum (Full or Half Size) and ContinuuMini
µCVC
User Manual
Early Adopter Revision
for purchasing the
www.evatontechnologies.com
Pittsburgh, PA 15220-2718
http://www.evatontechnologies.com/
µCVC Continuum
for updates to the
200 School St
Voltage
