Summary of Contents for Boss Audio Systems PowerSports RGB LED CONTROLLER
- Page 1 USER’S MANUAL RF WIRELESS REMOTE RGB LED CONTROLLER...
- Page 3 RF Wireless Remote Ad van ce d LED Controller Instructions • 22 Dynamic Modes • Card Type RF Remote • 20 Static Colors • Ultra Slim Design • Very Smooth Effects • Dynamic Demo Mode • Speed Adjustable • Easy Remote Pairing •...
- Page 4 Functions...
- Page 5 1. Turn On/Standby Mode Press this key to turn on unit or switch to Standby Mode. 2/8. Dynamic Mode Adjust Switch to Dynamic Mode from static color, or switch between Dynamic Modes. 3/9. Dynamic Speed Adjust Adjust Dynamic Playing Speed. Press SPEED+ to increase speed and press SPEED- to decrease.
- Page 6 10. Demo Mode Pressing this key will switch to Demo Mode. In Demo Mode, it plays 12 Dynamic Modes in loop, each mode repeats 3 times. Installing 1. Power Supply Operational voltage is 12V DC, negative ground. The DC jack’s inner pole (or red cable) is positive and sleeve (or black cable) is negative.
-
Page 7: Operation
CAUTION! Do not short circuit or overload the LED outputs, this may lead to permanent damage! LED CONTROLLER RF Remote / Easy Color / Switchable Peak Output Current : 3x4A Common Node Operation 1. Using Remote Controller Please pull out the battery insulation tape before using. The RF wireless remote signal can pass through barrier, so it’s not necessary to aim at the main unit when operating. - Page 8 For proper receiving remote signal, please do not install the main unit in closed metal parts. 2. Pairing New Remote The remote and main unit is 1 to 1 paired as default. Furthermore, main unit can be paired to 3 remote controllers and each remote controller can be paired to any main unit.
- Page 9 2). Press ‘ON/OFF’ and ‘MODE+’ Key together 5 seconds after powering on. After this operation, the main unit will recognize any remote control. To pair the main unit back to specific remote, please repeat the ‘pairing New Remote’ operation. 4. Switch Output Color Sequence The controller’s default output signal sequence is Common-Green-Red-Blue.
-
Page 10: Specifications
Specifications Dynamic mode 22 modes Static Color 20 colors PWM Grade 256 levels Brightness Grade 5 levels Speed Grade 10 levels Demo Mode Direct Color Select Output Color Switchable Yes, 6 options Operational Voltage 12V DC, negative ground Output Current 3x4A peak, 3x2A constant Remote Frequency 433.92MHz... - Page 11 NOTES...
- Page 12 USER’S MANUAL RF WIRELESS REMOTE RGB LED CONTROLLER BOSS Audio Systems 3451 Lunar Court • Oxnard, CA 93030 www.bossaudio.com 800-999-1236 US Toll-free 805-751-4853 Customer Service Tech Support: www.bossaudio.com/support/technical-support 0419...
