Boss Audio Systems MRF90 Manual

MRF90
Floating, Water-Resistant
Radio Frequency Wireless Remote With White LED LIGHT
Compatible with MR2180UA, MR1650UA, MR1630UA
MRF90
Floating, Water-Resistant
Radio Frequency Wireless Remote With White LED LIGHT
1. What's Included
1.
RF Receiver x 1pcs
2.
RF Remote Control
3.
Long Lasting 3V Lithium Battery x 1pcs
4.
User Manual x 1pcs
5.
Weather-Resistant Plastic Remote Holder x 2 PCS
6.
Weather-Resistant Self-Tapping Screws x 4 pcs
7.
Double sided Mounting Tape x 2 pcs
8.
Lanyard x 1pcs
2. Connecting the RF Receiver
Connect the MRF90 black box receiver to the RF
remote port connector at the back of the unit securely.
Make sure the pins are aligned properly when pugging
in, and the connection is secure, use tape to secure
the connection if needed. When installing the receiver
do not put it in any metal shielding for better reception.
Main Unit
RF Receiver
3. Key Functions
x 1pcs
1.
Press MODE button to change mode.
2.
Press and hold Light (
LED light.
3.
Press DISP button to view clock, and other available
information.
4.
Use Volume up (
5.
Use Volume down (
6.
Press (
/track up in different modes. Or hold this button to tune
up/fast channel up/fast forward, etc in different modes.
7.
Press (
/track down in different modes. Or hold this button to tune
down/fast channel down/fast rewind, etc in different modes.
8.
Press BAND button to change different band in the
AM &FM mode(if available).
9.
Press POWER(
4. Installing/Replacing the Battery
1.
On the back of the Remote, remove the
like pictures below, gently with a coin.
2.
Obtain one fully charged Cr2430. Be sure to install
the new battery the same way as the old battery.
3.
Install the battery cover back into place, being
careful to align it with the rubber seal.
CR2430 Battery Specification (Coin Type
sealed, Primary Lithium Battery)
Nominal Capacity
Nominal Voltage
Standard Discharge Current
Max. Discharge Current
Temperature Range
Weight
Dimensions
Remove The Battery Out
1
3
1
4
2
6
7
5
8
9
) button to use the white
) to raise the sound volume.
) to lower the sound volume.
) button to seek up/select the higher channel
) button to seek down/select the lower channel
) once to turn on or off the unit
280mAh
3V
0.3mA
Continuous 6mA
Pulse 50mA
-10°C ~
4.0g
Height (H)
3.0mm
Diameter(D) 24.5mm
2 3
.
battery
Crimp-
+60°C
