Summary of Contents for HYT TR-50 Series
-
Page 3: Brief Introduction
TR-50 Theory of Operation Brief Introduction ① L E D I n d i c a t o r ⑥ T X A n t e n n a ⑦ A C P o w e r I n l e t C o n n e c t o r ②... - Page 4 TR-50 Theory of Operation 5. Rx Antenna Connector N/F type RF connector. 6. Tx Antenna Connector N/F type RF connector. Applied as antenna port when duplexer is installed. 7. AC Power Inlet After correctly connecting AC power supply, turn on the switch to enter AC power supply mode.
-
Page 5: Theory Of Operation
TR-50 Theory of Operation Theory of Operation I. Power Control The control board draws a general 13.8V dc power supply, which is converted through U1, a 3-terminal regulator, to 8.0V dc for the receiver and transmitter. Fig. 1 Power Supply Block Diagram II. - Page 6 TR-50 Theory of Operation V. AF Amplification The receive audio is routed to another AF amplifier NJM386M, which is convenient for the users to monitor the activities of current channel. VI. Definition for control ports The definition of all the pins goes as follows: 1 .
-
Page 7: Alignment & Calibration
TR-50 Theory of Operation Alignment & Calibration Required Test Instrument DC power supply 1 set 1 ） Output range: 12~15 VDC (Minimum); output current: 3 A or more 2 ） Specified output: 13.8 VDC 3 ） The output should be stable, with minimal ripple & noise. 2. - Page 8 TR-50 Theory of Operation Receiver: 455.0125MHz 455.0125MHz CTCSS ： 67.0Hz operation system: 455.0125MHz WIN98SE RJ45 Operation CDCSS 0 25 ： /WIN2000 Programming Frequency Transmitter: Programming port software: 465.0125MHz HT-50E 465.0125MHz CTCSS ： 67.0Hz 465.0125MHz CDCSS 0 25 ： Turn to CH1 enter duplex mode.
- Page 9 TR-50 Theory of Operation Sensitivity squelch Turn to CH1, transceiver: Duplex operate BPF:0.3~3KHz Antenna Check -119 ± 3 dBm sensitivity duplex AF OUT: Sensitivity mode 1KHz/150mV squelch off: -120 ± 3 dBm...
- Page 10 TR-50 Theory of Operation TR-50U（ （ （ （ 7） ） ） ） Part List 1 Ref. Part No. Description Location Sum. Symbol. 01031002 Resistor 0603 10 01033932 Resistor 0603 39K 01051022 Resistor 0805 1K 01051032 Resistor 0805 10K 01051032 Resistor 0805 10K 01051032 Resistor 0805 10K 01051202...
- Page 11 TR-50 Theory of Operation 18002802 TR-50 CNPCB FR4 1.2T/2L/1 1206 T0610155 TMCSA1A155MTR.1.5UF/10V.M Ta-capacitor1206 T0616106 TMCMA1C106MTR 10uF 16V Ta-capacitor1206 T0616106 TMCMA1C106MTR 10uF 16V Ta-capacitor1206 T0635104 TMCSA1V104MTR.0.1uF 35V.M...
-
Page 12: Assembly And Disassembly For Repair
TR-50 Theory of Operation Assembly and Disassembly for repair Disassemble the main unit 1. Remove with tool the four screws on the rear side of main unit, and the four on the bottom of the main unit together with the rubber gasket. Pull out the outer cover. 2. -
Page 13: Exploded View
TR-50 Theory of Operation Exploded View... -
Page 14: Part List
TR-50 Theory of Operation Part List 2 Material Name Material No. 14090360 M3×6 Screw (zinc-plated, black) 1413200A TR50 Cover 1613000A TR50 Rubber foot mat 14090360 Screw ( zinc-plated, black) × 14090420 Screw M4 × 19130030 Fan 12V 0.17A Machine Screw M2 ×... - Page 15 TR-50 Theory of Operation Packing Upper Liner of Owner’s Manual Pearl Cotton 珍珠棉上内衬 说明书 H Y T Lower Liner Pearl Cotton 珍珠棉下内衬 TR-50中继台主机 Main Unit Packing Box 包装箱...
-
Page 16: Specifications
TR-50 Theory of Operation Specifications Frequency Range 146.0000MHz-174.0000MHz 440.0000MHz-470.0000MHz Channel Frequency Capacity ≤ ± 5 PPM Valid Transmit Power ≤ 5 W Transmitter Spurious Radiation ≤ 5 0uW Modulation Limit ± 5.0KHz Occupied Bandwidth ≤ 8 .5KHz Adjacent Channel Power Rejection ≥...
