CONNECTIONS
Point to Point connection: Up to 120 meters transmission distance over single cable (High quality
cable can reach 150 meters).
NOTE
Only one power adapter is needed for the transmitter, please use 8 core network cable follow the
standard of EIA-568B.
FAQ
Q: TV display "Waiting for connection" on the right corner?
A: Please check if the power supply of TX (Sender) is connected, and make sure all cables are
connected well and firmly.
Q: TV display "Please check the TX input signal" '?
A: 1) Please check and make sure there is a HDMI signal input to the transmitter unit.
2) Try to connect the signal source to display device directly to see if there is signal output from
source device, or change the source device, HDMI cable and try again.
Q: Display not fluent, not stable?
A: 1) Please check and make sure the cable length is within the required range
2) Press the "reset" button on the TX/RX front panel to restart the units.
