PB*4VI512LFTB4
(EN) INSTRUCTION MANUAL
IOAA-710 / 8051807
(05.2016 / v1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PB 4VI512LFTB4 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Amica PB 4VI512LFTB4 Series

Summary of Contents for Amica PB 4VI512LFTB4 Series

  • Page 1 PB*4VI512LFTB4 (EN) INSTRUCTION MANUAL IOAA-710 / 8051807 (05.2016 / v1...

  • Page 2: Basic Information

    DEAR CUSTOMER, The plate is exceptionally easy to use and extremely efficient. After reading the instruction manual, operating the cooker will be easy. Before being packaged and leaving the manufacturer, the plate was thoroughly checked with regard to safety and functionality. Before using the appliance, please read the instruction manual carefully.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS Basic Information....................2 Safety instructions.....................4 Description of the appliance..................9 Installation......................10 Operation.......................13 Cleaning and maintenance..................24 Troubleshooting......................26 Specification......................28 Warranty and after sales service................29...

  • Page 4: Safety Instructions

    SAFETY INSTRUCTIONS Warning: The appliance and its accessible parts become hot during use. Care should be taken to avoid touching heating elements. Children less than 8 years of age shall be kept away unless continuously supervised. This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or...
  • Page 5 SAFETY INSTRUCTIONS Warning: If the surface is cracked, switch off the ap- pliance to avoid the possibillity of electric shock. Metallic objects, such as knives, forks, spoons and lids should not be placed on the hob surface since they can get hot. After use, switch off the hob element by its control and do not rely on the pan detector.
  • Page 6 SAFETY INSTRUCTIONS • Be fo re using the ceramic plate for the first time read the Operating Manual carefully as thus you can ensure safe operation and avoid damage to the plate. • If the ceramic plate is operated near a radio, TV set or other emitting device, please check whether the touch panel works correctly.
  • Page 7 SAFETY INSTRUCTIONS • Use only flat-bottom pots and saucepans on your ceramic plate, without sharp edges or burrs as otherwise the plate may get permanently damaged. • The heating surface of the ceramic plate is resistant to thermal shock. It is neither hot nor cold-sensitive.
  • Page 8 HOW TO SAVE ELECTRICITY UNPACKING Using the electricity in a re- The appliance was protected sponsible manner not only from damage at the time of saves money, but also helps transport. After unpacking, protect the environment. So please dispose of all ele- let’s save electricity! This is ments of packaging in a way how it’s done:...

  • Page 9: Description Of The Appliance

    DESCRIPTION OF THE APPLIANCE Description of PB*4VI512LFTB4 plate Inductive hotplate Booster (rear right) Inductive hotplate Booster (rear left) Inductive hotplate Booster (front left) Inductive hotplate Booster (front right) Control panel On/off sensor field Higher heat setting sensor field / Cooking zone selection sensor field Heat setting display with decimal point Lower heat setting sensor field / Lower timer setting sensor field Timer on/off sensor field / Higher timer setting sensor field...

  • Page 10: Installation

    INSTALLATION Making the worktop recess l Worktop thickness should be 28 - 40 mm, while its width at least 600 mm. The worktop must be flat and level. Edge of the worktop near the wall must be sealed to prevent ingress of water or other liquids.
  • Page 11 INSTALLATION Fig.2 5 10mm ÷ 25mm 30mm Installing hob in kitchen cabinet worktop. 500x10mm 5 10mm ÷ Installing hob in kitchen worktop above oven with ventilation. 500x20mm Do not install the hob above the oven without ventilation.
  • Page 12 INSTALLATION Installing PB*4VI512LFTB* hob - bracket • Use four “A” brackets for 38 mm thick worktops. Fit the hob into worktop opening as shown on figure 3 and 4. To properly secure hob in 28 mm thick worktop, use four 15x15x50 mm wooden blocks in addition to “A”...

  • Page 13: Operation

    OPERATION Before first use • carefully clean the ceramic plate treating it as a glass surface, • when used for the first time the plate can give off a bit of a smell so switch on the ventilation system or open the window, •...
  • Page 14 OPERATION Pot detector The pot detector is installed in plates equipped with the inductive field system. During opera- tion the pot detector automatically starts or stops the production of heat once a pot is put or removed from the plate, saving energy. •...
  • Page 15 OPERATION Selection of cookware for inductive hotplates Appropriate quality of pots conditions the performance of your plate. • Always use high quality pots with ideally flat bottoms as it prevents points of too high tem- perature forming on the bottom and consequently sticking of the cooked food. Pots and pans with thick metal sides guarantee perfect distribution of heat.
  • Page 16 OPERATION Selection of cookware for inductive hotplates Cookware marking Check if there is a sign on the label informing that the pot is suitable for use on inductive plates. Use magnetic pots (from enamelled sheet metal, ferrite stainless steel, cast iron), check them by trying to attach magnet to the pot bottom (has to cling).
  • Page 17 OPERATION Control panel • All the indicators will go on for a brief moment when the cooktop is connected to the mains. The appliance is ready to work. • The cooktop is equipped with an electronic touch button control panel. Press the suitable button for at least 1 second to activate the requested function.
  • Page 18 OPERATION Setting the heating power As long as ‘0’ remains displayed in the burner display (3) and the respective digit is blinking, you can set the required heating power by pressing touch buttons “+” (2) or “-“ (4). In order to protect the supply mains, the induction hob can operate at the maximum power of 3500 W.
  • Page 19 OPERATION Unlocking the cooktop Touch the key button (8) to turn off the lock. The lock becomes inactive the moment the respec- tive LED goes off. A brief tune sounds when the button is released. “0” must be apparent in all the displays, or the heating power must be set for at least one of the burners in order to unlock the cooktop.
  • Page 20 OPERATION Automatic warming • The selected burner must be set at “0” heating power. • The heating power will switch to 9 the moment button (4) is pressed. • Then, press “+” button (2) for the respective burner. “A” will light up in the display. •...
  • Page 21 OPERATION • Press “+” (5) or “-“ (4) buttons to set the requested cooking time (range of 01 to 99 minutes). The clock will activate in a couple of seconds. The respective burner’s LED will go on. All the burners must work simultaneously in the clock time setting mode. Cooking time can be input quickly by keeping the “+”...
  • Page 22 OPERATION Changing the preset cooking time The preset cooking duration can be changed at any time. • Select the required burner with burner selector (2). The decimal point in the display starts blinking. • Press clock on / off button (5) to turn on the clock. The selected burner indicator is blin- king.
  • Page 23 OPERATION Clock in alarm function The cooking time clock can be used as an extra alarm if the burners uptime is not in auto- matic time control mode. Activating the alarm If the cooktop is switched off, proceed as follows: •...

  • Page 24: Cleaning And Maintenance

    CLEANING AND ROUTINE MAINTENANCE Daily cleaning and proper maintenance have crucial impact on the durability of your ce ra- mic plate. Clean the ceramic plate observing the same rules as for glass. Never use abrasive or aggressive cleaning agents, scrubbing powders or scratch- ing sponges.
  • Page 25 CLEANING AND ROUTINE MAINTENANCE Never apply cleaning agent on a hot hotplate. Attention! Leave the cleaning agent to dry and then wipe If from any reason you are not able it off with a damp cloth. Any residuals of clean- to control the switched on plate, ing agents should be wiped off with a damp switch off the main switch or screw...

  • Page 26: Troubleshooting

    EMERGENCY PROCEDURE Every time when emergency situation occurs you should: • switch off the working assemblies of the plate • disconnect power supply • call in the service • as some minor faults can be removed by the user in accordance with the be low specified instructions, before calling the Customer Service please go thro ugh the Table checking every point.
  • Page 27 EMERGENCY PROCEDURE PROBLEM CAUSE ACTION 7.Residual temperature - power supply fa ilu re, the -the residual temperature in- in di ca tor is not lighted ap plian ce has been di scon- di ca tor will work again after although the hot pla tes are nec ted from the mains swit ching the control panel still hot...

  • Page 28: Specification

    TECHNICAL DATA Rated voltage 230V 1N~50 Hz PB*4VI512LFTB4 Rated power: - inductive hotplate Booster: 2300/3000 W Ø 220 mm front left - inductive hotplate Booster: 1500/2300W Ø 220 mm rear right - inductive hotplate Booster: Ø 180 mm 1085/1400W Dimensions 576 x 518 x 50;...

  • Page 29: Warranty And After Sales Service

    WARRANTY Warranty Warranty services according to the warranty card. The producer shall not be held liable for any damages caused by improper operation of the product. Please enter the type and factory number of the plate from the rating plate Type...........
