JumpSeat
®
Parts Included
7/16" Nut Driver
(Concrete)
9/16" Nut Driver
(Wood)
Tools Required
Seat
1/4"
Masonry
Drill Bit
Power Drill
Movable Base
Fixed Base
1
2
1/4"x
5/8"
Concrete Anchors
3
Concrete
Anchor Caps
5
5/32"/ 4mm
Allen Wrench
Hardware Included
2
2
3/8"x
1/2"
Lag Screw
4
Lag Screw
Caps
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for sedia systems JumpSeat Series
Summary of Contents for sedia systems JumpSeat Series
- Page 1 JumpSeat ® Movable Base Seat Fixed Base Parts Included 1/4"x 5/8" 3/8"x 1/2" Concrete Anchors 7/16" Nut Driver Lag Screw (Concrete) Lag Screw Concrete Caps Anchor Caps 1/4" 9/16" Nut Driver 5/32"/ 4mm Masonry (Wood) Allen Wrench Drill Bit Power Drill Tools Required Hardware Included...
- Page 2 JumpSeat ® Floor Installation Concrete Floor Wood Floor Mininmum 7" Minimum 7" From Wall From Wall • Position base on oor and mark hole locations. • Position base on oor and mark hole locations. • Punch or cut carpet to avoid runs. •...
