Strand NEO Series Quick Start Install Manual

NEO Playback & Submaster Wings
Introduction
Adding to our NEO family of products are the NEO Fader wings. NEO Fader wings can be used to provide additional physical fader playback and
submasters, depending upon model, to your NEO lighting control console.
The interconnection between each wing and the control console is via a USB connection and can be powered either directly from your NEO console
or plugged directly into a common power outlet through an optional power supply (model number 91009, sold separately).
This guide is for users to quickly connect and begin using either fader wing with a NEO console. Please read the information in this guide and retain
these instructions for future reference.
Warnings and Notices
When using electrical equipment, basic safety precautions should always be followed including the following:
a. READ AND FOLLOW ALL SAFETY INSTRUCTIONS.
b. Do not use outdoors.
c. Do not use near gas or electric heaters.
d. The use of accessory equipment not recommended by the manufacturer may cause an unsafe condition.
e. Do not use this equipment for other than intended use.
f. Refer service to qualified personnel.
SAVE THESE INSTRUCTIONS.
WARNING: You must have access to a main circuit breaker or other power disconnect device before installing any wiring. Be sure that
power is disconnected by removing fuses or turning the main circuit breaker off before installation. Installing the device with power on may
expose you to dangerous voltages and damage the device. A qualified electrician must perform this installation.
WARNING: Do not open the console. There are no user serviceable parts inside. This equipment is designed to operate from the mains
electrical supply and contains voltages, which, if touched, may cause death or injury. It should only be operated in accordance with the
instructions provided and for the purpose of a lighting control system.
WARNING: Avoid spilling liquid on the equipment If this should happen, switch the equipment off immediately at the mains. To reduce the
risk of fire or electric shock, do not expose the equipment to rain or moisture. For indoor use only.
WARNING: Refer to National Electrical Code® and local codes for proper use specifications.
WARNING: This equipment is intended for use in accordance with the National Electric Code® and local regulations. It is also intended for
installation in indoor applications only. Before any electrical work is performed, disconnect power at the circuit breaker or remove the fuse
to avoid shock or damage to the control. It is recommended that a qualified electrician perform this installation.
WARNING: The devices described herein are not user-serviceable and should NOT be opened or remove any covers. Refer service to
qualified personnel.
WARNING: This equipment is designed and manufactured to comply with international safety standards IEC950, UL1950, CS950 and is
intended for use as part of a lighting control system. It must not be used for other purposes where there is a risk of safety to persons. The
equipment contains power voltages, socket outlets will be installed near the equipment and be easily accessible.
Included Items
Each fader wing includes a USB cable (1.5 meter), power cable (1.5 meter), dust cover (not shown) and quickstart & install guide (this document). If
you are missing any component, please contact your local dealer for assistance.
Product Support
Should you have any questions or require assistance with the products described in this guide, please contact your Authorized Strand Dealer or
Strand technical support team at 1.214.647.7880 or 1.800.4STRAND or visit us at www.strandlighting.com.
85-6415C (10 July 2019)
QuickStart & Install Guide
