- Page 1 EM3288 Hardware Manual V2.0 Boardcon Embedded Design www.boardcon.com...
- Page 2 1.3. Limited Warranty Boardcon warrants this product to be free of defects in material and workmanship for a period of one year from date of buy. During this warranty period Boardcon will repair or replace the defective unit in accordance with the following process: A copy of the original invoice must be included when returning the defective unit to Boardcon.
-
Page 3: Table Of Contents
Your Idea Customize the embedded system based on Content 1 EM3288 Introduction ........................3 1.1 Summary ..........................3 1.2 Rockchip RK3288 Features ....................3 1.3 EM3288 Specifications ......................4 1.4 PCB Dimension ........................5 1.5 Block Diagram ........................6 1.6 CPU Introduction ........................6 2 Peripherals Introduction ......................... -
Page 4: Em3288 Introduction
This document (V2) is based on EM3288 V7(MINI3288 version: V4). 1.1 Summary EM3288 is based on the Rockchip RK3288, Quad Core Cortex-A17 @1.8GHz. RK3288 is powerful on multithreaded computing operation, graphics processing and video decoding ability. It supports Mali-T760 MP4 Graphics Processing, OpenGL ES1.1/2.0/3.0, OpenVG1.1, OpenCL, Directx11, and can 4Kx2K achieve 4kx2k H.264 and 10 bits of H.265 video decoding, 500% performance boost... -
Page 5: Em3288 Specifications
Your Idea Customize the embedded system based on 1.3 EM3288 Specifications Ethernet USB Host HDMI Power in Line in Dual-USB DC 5V/3A Audio out Host Micro SD LVDS Li-battery optional RGB LCD SATA-Power MIPI SATA optional optional WiFi&BT 4G&GPS Debug... -
Page 6: Pcb Dimension
Your Idea Customize the embedded system based on SD card 1x Micro SD card slot WiFi & Bluetooth AP6236 module. WiFi - 2.4GHz, 802.11b/g/n. Bluetooth4.0. Quectel EC20, PCIe connector SATES ST-91-U7 Camera Supporting MIPI camera, and most of USB CMOS camera on the market, Real Time Clock, powered by external lithium battery Button Power, Recover... -
Page 7: Block Diagram
8-pin Recover 40-pin LVDS header header connector connector LVDS/RGB LCD&Touch MIPI PHY GPIO1 IRIN&GPIO2 Key_in Power_key Power (Jack) DC 5V/3A EM3288 CPU Board Lithium battery Default not supported Rockchip3288 Cortex-A17 @1.8GHz UART0 HDMI1.4/2.0 HDMI Bluetooth Dual Debug serial port UART2... - Page 8 Your Idea Customize the embedded system based on Pin Definition Signal Signal Signal Signal (J1) (J1) (J2) (J2) MIPI_TX/RX_D2 SPI0_UART TX_C VCC_SYS 4_RXD MIPI_TX/RX_D1 SPI0_UART TX_0- 4_TXD MIPI_TX/RX_D3 TX_C+ VCC_SYS TX_0+ TS0_SYNC MIPI_TX/RX_D3 UART1_CT nRESET UART1_RT DVP_PWR MDI0+ UART1_RX TX_1- HSIC_STROBE MDI1+ _TS0_D0...
- Page 9 Your Idea Customize the embedded system based on LCD_HSYNC CIF_D6 SDIO0_CMD SDMMC_D2 LCD_CLK CIF_D9 SDIO0_D0 SDMMC_D1 SDMMC_DE LCD_DEN CIF_D8 SDIO0_D1 LCD_D0_LD0 CIF_PDN0 SDIO0_D2 SDMMC_D3 LCD_D1_LD0 SDMMC_P CIF_D10 SDIO0_D3 LCD_D2_LD1 GPIO0_B5_ CIF_HREF SDIO0_CLK LCD_D3_LD1 CIF_VSYNC BT_WAKE LCD_D4_LD2 GPIO7_B7_ CIF_CLKOUT SDIO0_WP LCD_D5_LD2 WIFI_REG_O CIF_CLKIN I2S_SDI...
-
Page 10: Peripherals Introduction
MIPI_TX/RX_ VCC_IO SPI0_CLK PWR_KEY MIPI_TX/RX_ GPIO7_C5_ 2 Peripherals Introduction 2.1 Power (P6, J17) EM3288 Power Supply – 5V DC power supply or external Li+ battery 5V/3A DC power supply (P6) ⚫ Signal Description Signal Description VDD5V Main power supply. DC 5V power in... -
Page 11: Ethernet (Jp1)
Ground VBAT Li-Battery 2.2 Ethernet (JP1) 10 9 RK3288 has integrated Gigabit Ethernet MAC. EM3288 adopts RTL8211E as the Ethernet chip. RJ45 connector Feature Supports 10/100/1000-Mbps data transfer rates with the RGMII interfaces ⚫ Supports both full-duplex and half-duplex operation ⚫... -
Page 12: Usb Host (P2, P3)
2.3 USB HOST (P2, P3) EM3288 provides 3x USB2.0 Host. One is a single USB (P2), and the other is a double-USB (P3). The 3-ch USB HOST interfaces are extended by AU6256 which is a fully compliant with the USB 2.0 hub specification and is designed to work with USB host as a high-speed hub. -
Page 13: Usb Otg (J8)
Your Idea Customize the embedded system based on 2.4 USB OTG (J8) EM3288 OTG is a Micro USB2.0 port, it is used to download image and ADB transfer file. Feature Compatible with USB OTG2.0 specification ⚫ Supports USB 2.0 High Speed (480Mbps), Full Speed (12Mbps) and Low Speed (1.5Mbps) ⚫... -
Page 14: Hdmi (Ph1)
Customize the embedded system based on 2.6 HDMI (PH1) EM3288 HDMI2.0 supports maximum 4Kx2K display, and it also enables HDMI/LCD audio and video synchronization output. The HDMI interface is the regular 19pins HDMI type A, with width 13.9mm and thickness 4.45mm. -
Page 15: Vga (J20)
1. The audio default output from HDMI. No sound in headphone if not remove HDMI. 2. Default recording via MIC1 if the Line_in jack is not plugged in. 2.8 VGA (J20) EM3288 adopts standard 15-pin female VGA connector, and SDA7123 3-Channel 10 Digit Video D/A converter. Signal... -
Page 16: Lvds (Con3)
Serial Data LCD_HSYNC LCD Horizontal Sync LCD_VSYNC LCD Vertical Sync 2.9 LVDS (CON3) EM3288 supports 10.1-inch HD capacitive LCD, up to 1280 x 800 resolution. Feature Comply with the TIA/EIA-644-A LVDS standard ⚫ Combine LVTTL IO, support LVDS/LVTTL data output ⚫... -
Page 17: Mipi (Con5)
TSXP TSYM TSYP 2.11 MIPI (CON5) EM3288 supports MIPI Camera. Features Embedded 3 MIPI PHY, MIPI 0 only for TX, MIPI 1 for TX and RX, MIPI 2 only for RX ⚫ Support 4 data lane, providing up to 6Gbps data rate ⚫... -
Page 18: Gps (Mu4)
Your Idea Customize the embedded system based on VCCA_18 DC 1.8V Ground LCD1_BL Backlight LCD1_BL_EN Backlight enable CIF_CLKOUT Camera clock I2C3_SCL I2C clock line I2C3_SDA I2c date line TOUCH_RST Touch screen reset TOUCH_INT Touch screen int Ground CLKN MIPI clock - CLKP MIPI clock + Negative Transmission... -
Page 19: Wifi&Bluetooth (U11)
Your Idea Customize the embedded system based on supply GPSVDDIO IO Supply Voltage VDD_GPS Supply voltage GPSRST Reset Ground GPS_RFIN GPS signal input Ground Output Voltage RF Not connect RFVCC section Not connect Not connect Not connect Not connect 2.13 WiFi&Bluetooth (U11) view AP6236 is a low-power consumption module which has incorporated Wi-Fi and Bluetooth into one chip. -
Page 20: Debug Uart (J10)
Your Idea Customize the embedded system based on Internal regulators XTAL_OUT Crystal output WIFI_REG_ON power enable / disable WIFI_HOST_WAK External Interrupt WIFI_D2 WiFi data Input / Keypad input WIFI_D3 WiFi data WIFI_CMD WiFi command WIFI_CLK WiFi clock WIFI_D0 WiFi data WIFI_D1 WiFi data Ground... - Page 21 Your Idea Customize the embedded system based on 21 23 25 27 29 31 33 35 37 39 9 11 13 15 17 19 21 23 25 8 10 12 14 16 18 20 22 24 26 28 30 32 34 36 38 40 GPIO (CON4) Signal Description...
-
Page 22: Control (J2)
Ground VCC_IO 3.3V VCC_IO 3.3V Ground Ground VCC5V VCC5V 2.16 Control (J2) The Pin6 of J2 is IR_IN. The EM3288 supports IR data receiver. The signals are transmitted directly to the CPU. Signal Description Signal Description VCC_IO 3.3V Ground KEY_IN... - Page 23 Your Idea Customize the embedded system based on Size: 51 x 30 x 4.9mm ⚫ Weight: 9.8g ⚫ Bandwidth: 1.4/3/5/10/15/20MHz ⚫ Temperature Range: -40°C ~ +80°C ⚫ Supply Voltage: 3.0V~3.6V, 3.3V Typical ⚫ 3GPP TS27.007 and Enhanced AT Commands ⚫ 4G connector (CON2) Signal Signal...
-
Page 24: Sata & Sata_Power (J14, J18)
Your Idea Customize the embedded system based on Ground Ground Ground 2.19 SATA & SATA_Power (J14, J18) On-board 7-pin SATA Interface, equipped with a HS USB to SATA bridge JM20329. It requires 5V power supply. The SATA only supports mobile hard disk, not desktop hard disk. Features Compliance with Gen1i/Gen1m of Serial ATA II Electrical Specification 2.5 ⚫... -
Page 25: Product Configurations
Customize the embedded system based on 3 Product Configurations 3.1 Standard Contents Qty. Item Description (PCS) EM3288 board Standard Content (2GB RAM, 4GB eMMC, WiFi&BT) Android BSP, Ubuntu BSP, Documents, tools, Schematic TF Card / CD-ROM Drawing, Datasheets Ethernet cable Serial Cable...
